Product details

« Back to Listing

Z-Wave Smart Dimmer Socket

Brand Name: Philio
Product Identifier: PAD02
Product Version: HW: 1 FW: 1.02
Z-Wave Certification Number: ZC10-17045556
Z-Wave Certification Date: 4/21/2017
Use In: CEPT (Europe)
Z-Wave Protocol Implementation Conformance Statement:   View    Download

PAD02 is an E27(EU)/ E26(US) Edison screw based lamp socket, which provides electrical connection to the E14(EU)/ E12(US) Edison screw based lamps and support it in the lighting fixture. The use of socket allows lamps to be safely and conveniently replaced. You can On/Off the light by pressing the button briefly, or a long pressing to control the brightness of dimmable lightbulb.
This dimmer is a transceiver which is a security enabled device which based on Z-Wave Plus technology. Z-Wave PlusTM enabled devices displaying the Z-Wave PlusTM logo can also be used with it regardless of the manufacturer, and can also be used in other manufacturer’s Z- WaveTM enabled networks. Remote dim level control of the connected light is possible with other manufacturer’s wireless Controller. Since PAD02 supports Security Command Class, it can learn with a Secured enabled controller to fully utilize the device. Its functionality and supported command classes is identical when included as a secure and non-secure device.

Adding to Z- WaveTM Network
In the front casing, there is an on/off button with LED indicator below which is used to switch on and off, dim level, or carries out add, remove, reset or association. When first power is applied, its LED flashes on and off alternately and repeatedly at 0.5 second intervals. It implies that it has not been assigned a node ID and start auto inclusion.

Auto Inclusion
The function of auto inclusion will be executed as long as the dimmer does not have Node ID and just connect the dimmer to main power. Note: Auto inclusion timeout is 2 minute during which the node information of explorer frame will be emitted once every several seconds. Unlike “inclusion” function as shown in the table below, the execution of auto inclusion is free from pressing the On/Off button on the dimmer.

Product Features:   View Features
Z-Wave Plus Version: 1
SmartStart Compatible: No
Manufacturer Provided Product Manual: Download
Association Capabilities:   View Associations
Configuration Capabilities:   View Configuration Parameters
Z-Wave hardware platform: SD3502
Z-Wave version: 6.51.09
Z-Wave library type: Enhanced 232 Slave
Z-Wave Device Type: Light Dimmer Switch
Z-Wave Role Type: Always On Slave
Product Type ID: 0x0005
Product ID: 0x0031
Network Management Instructions:   View Network Management Info
Command Classes: View Command Classes
Associated Categories:   All Lighting Devices    Dimming Lighting Devices
Download Product Data in XML Format: Download
