Z-Wave In-Wall Dimmer


Brand Name: ZLINK
Product Identifier: WD-100
Product Version: HW: 255 FW: 50.03
Z-Wave Certification Number: ZC10-18025996
Z-Wave Certification Date: 2/7/2018
Use In: U.S. / Canada / Mexico
Z-Wave Protocol Implementation Conformance Statement:   View    Download

ZLINK’s WD-100 is a Z-Wave Plus certified device with S2 security and SmartStart features. You can now add this device securely and with ease using QR code on the product with compatible gateways supporting S2 and Smart Start. The elegant WD-100, with 7 LED dim level lights, communicates with other Z-Wave certified devices and updates your home into a smart home. WD-100 replaces a standard in-wall light switch turning it into a Z-Wave controlled network device with manual and remote control dimming and On/Off light control. ZLINK WD-100 supports, “Instant Feedback” of manual status to compatible gateways as well as Central Scene to allow setting multiple scene control throughout the home, with gateways supporting Central Scene. Each Z-Wave device serves as a node to repeat the signal in the network, thus, extending the overall Z-Wave mesh wireless network range.
Additional Features:
• Power 120 VAC, 60Hz, up to 600 watts
• Region US: 908.4, 916 MHz
• Works w/ most incandescent, dimmable CFL & LED lights
• 7 segment LED dim level indicator
• Remotely or manually turns ON or OFF, or DIM lights
• Fits standard wall plates (wall plate not included)
• Works with any certified gateway supporting Z-Wave

Product Features:   View Features
Z-Wave Plus Version: 1
Security S2 Classes: S2 Authenticated, S2 Unauthenticated
SmartStart Compatible: Yes
Manufacturer Provided Product Manual: Download
Association Capabilities:   View Associations
Configuration Capabilities:   View Configuration Parameters
Z-Wave hardware platform: ZM5202
Z-Wave version: 6.81.00
Z-Wave library type: Enhanced 232 Slave
Z-Wave Device Type: Light Dimmer Switch
Z-Wave Role Type: Always On Slave
Product Type ID: 0x4447
Product ID: 0x3034
Network Management Instructions:   View Network Management Info
Command Classes: View Command Classes
Associated Categories:   All Lighting Devices    Dimming Lighting Devices    Lighting Accessories
Download Product Data in XML Format: Download
