Product details


« Back to Listing


Curtain motor


Brand Name: Dooya
Product Identifier: DT82TV/F-1.2/14
Product Version: HW: 144 FW: 1.14:01.04
Z-Wave Certification Number: ZC10-18046083
Z-Wave Certification Date: 4/16/2018
Use In: U.S. / Canada / Mexico
Z-Wave Protocol Implementation Conformance Statement:   View    Download

DOOYA Z-Wave curtain motor is designed with exceeding commercial standards, with its exceptional quietness and user-friendly setup. Multiple control options enable the users to operate the curtain by remote, APP, or with hands. Pull to move function would be especially helpful and convenient to users who are not yet familiar with motorization. Durability in use guarantee a 10,000 times use. Additionally, the motor is more than what were mentioned above.

1. Quick set limits: the motor would set its limit positions automatically with a full ride opening and closing on the track.
2. Soft start & soft stop: A smooth running with a soft start and soft stop provide a premium visual effect.
3. Pull to move: Just do what you always did on a normal curtain, but you do not have to pull the fabric all the way to the end. Just one touch of pulling on the fabric, the motor will start running until it reaches its end.
4. If the power was gone, you can still operate the curtain as a normal curtain. When the power is back, all the settings are still there.
5. RF compatibility: Dooya Z-Wave curtain motor is also compatible with the whole range of Dooya RF remotes, various choices and a different combination would satisfy all kinds of different needs.

Product Features:   View Features
Z-Wave Plus Version: 1
Security S2 Classes: S2 Unauthenticated
SmartStart Compatible: No
Manufacturer Provided Product Manual: Download
Association Capabilities:   View Associations
Configuration Capabilities:   View Configuration Parameters
Z-Wave hardware platform: ZM5202
Z-Wave version: 6.71.01
Z-Wave library type: Enhanced 232 Slave
Z-Wave Device Type: Window Covering - Pos/End Aware
Z-Wave Role Type: Always On Slave
Product Type ID: 0x0103
Product ID: 0x0090
Network Management Instructions:   View Network Management Info
Command Classes: View Command Classes
Associated Categories:   Window Covering
Download Product Data in XML Format: Download
