Brand Name: Jasco
Product Identifier: 14321/46564/ZW3010
Product Version: HW: 255 FW: 5.53
Z-Wave Certification Number: ZC10-19056491
Z-Wave Certification Date: 5/15/2019
Use In: U.S. / Canada / Mexico
Z-Wave Protocol Implementation Conformance Statement:
View
Download
In-Wall Smart Dimmer with QuickFit and SimpleWire enhancements. Revolutionary QuickFit design features a housing depth that is up to 20 percent smaller than the previous Z-Wave models. This reduced size coupled with the elimination of heat taps provides a better fit in older style boxes and multi-gang configurations. SimpleWire technology allows line and load to automatically be configured with auto-sensing line-load terminals. All of this is coupled with Z-Wave S2 and Smart Start allows for effortless installation while being safer than ever!
Z-Wave Plus Version: 1
Security S2 Classes: S2 Authenticated, S2 Unauthenticated
SmartStart Compatible: Yes
Manufacturer Provided Product Manual:
Download
Z-Wave hardware platform: ZM5202
Z-Wave version: 6.81.03
Z-Wave library type: Enhanced 232 Slave
Z-Wave Device Type: Light Dimmer Switch
Z-Wave Role Type: Always On Slave
Product Type ID: 0x4944
Product ID: 0x3236
Download Product Data in XML Format:
Download
