Product Recognition	—
Certification Number	ZC08-09090007
Name	1G Battery Controller
Long Description	Product electronics and software are identical to base EU product other than use of Hong Kong Zensys module and RF configuration; only RF performance need be verified. 1 GANG BATTERY CONTROLLER Fully portable, can be used from any location in the system Can be selected as the system's Primary Controller RF Range up to 75m (open field) Can control up to 64 devices in total Pre programmed with ALL OFF function and HOLIDAY MODE function Low battery indicator Long battery life of tp to 2 years (under normal operating conditions) STANDARD CARTON QUANTITY: 1 Supplied with wall and back box mounting brackets, batteries and all required fixings. Operating Frequency 919.8 MHz Select the appropriate 1 Gang Dimmer Fascia for your Battery Controller Module.
Brand	MK Electric
Product Identifier	LIB1H
OEM Version	A
Hardware Platform	ZM3102
Z-Wave Version	5.02 (PATCH 3)
Library Type	CONTROLLER_PORTABLE
Device Type	Not Z-Wave Plus
Manufacturer ID	0x0040
Product Type ID	0x0302
Product ID	0x0101
Frequency Plans	HK: 919.80MHz, 919.80MHz
Categories	All Lighting Devices, Lighting Accessories
Countries / Regions	Hong Kong
Controlled Command Classes	Identifier Name Key Version COMMAND_CLASS_SWITCH_MULTILEVEL Switch Multilevel 0x26 1 COMMAND_CLASS_MANUFACTURER_PROPRIETARY Manufacturer Proprietary 0x91 1 COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION Multi-Channel Association V1 0x8E 0 COMMAND_CLASS_MULTI_CHANNEL Multi-Channel V1 0x60 0 COMMAND_CLASS_MULTI_INSTANCE_ASSOCIATION Multi-Instance Association 0x8E 1 COMMAND_CLASS_SWITCH_ALL Switch All 0x27 1 COMMAND_CLASS_BASIC Basic 0x20 1 COMMAND_CLASS_SWITCH_MULTILEVEL_V2 Switch Multilevel V2 0x26 2 COMMAND_CLASS_MULTI_CHANNEL_V2 Multi-Channel V2 0x60 2 COMMAND_CLASS_MANUFACTURER_SPECIFIC Manufacturer Specific 0x72 1 COMMAND_CLASS_MARK Mark 0xEF 1 COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V2 Multi Channel Association V2 0x8E 2
