100 | Set 101 ~ 104 to default. | Set 101 ~ 104 to default. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 255 | Set 101 ~ 104 to default. |
|
101 | The interval time of sending the temperature reporting | The interval time of sending the temperature reporting. if setting to 0 then the temperature reporting is disabled 1. Valid values: 0x00-0x28DE80 2. The minimum interval time is 1 minutes. For example, if the value is set to be more than 1 and less than 60, the interval time is 1 minutes, if the value is set to be more than 60 and less than 120, the interval time is 2 minutes. | 0 | 4 | 0 | 0 | 7200 | From | To | Description |
|---|
0 | 0 | the temperature reporting is disabled | 1 | 2678400 | The interval time of sending the temperature reporting is 31 days（2678400 seconds） |
|
102 | The interval time of sending the humidity reporting. | The interval time of sending the humidity reporting. if setting to 0 then the humidity reporting is disabled 1. Valid values: 0x00-0x28DE80 2. The minimum interval time is 1 minutes. For example, if the value is set to be more than 1 and less than 60, the interval time is 1 minutes, if the value is set to be more than 60 and less than 120, the interval time is 2 minutes. | 0 | 4 | 0 | 0 | 7200 | From | To | Description |
|---|
0 | 0 | the luminance reporting is disabled | 1 | 2678400 | The interval time of sending the humidity reporting is 31 days（2678400 seconds） |
|
103 | The interval time of sending the luminance reporting. | The interval time of sending the luminance reporting. if setting to 0 then the luminance reporting is disabled 1. Valid values: 0x00-0x28DE80 2. The minimum interval time is 1 minutes. For example, if the value is set to be more than 1 and less than 60, the interval time is 1 minutes, if the value is set to be more than 60 and less than 120, the interval time is 2 minutes. | 0 | 4 | 0 | 0 | 7200 | From | To | Description |
|---|
0 | 0 | the luminance reporting is disabled | 1 | 2678400 | The interval time of sending the luminance reporting is 31 days（2678400 seconds） |
|
110 | Enable 111 ~ 114 temperature/humidity/luminance/ battery level change reporting. | Enable 111 ~ 114 temperature/humidity/luminance/ battery level change reporting. 0 = Unable 1 = Enable | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Unable | 1 | 1 | Enable |
|
111 | Configuration temperature change threshold. | Configuration temperature change threshold. Valid values: 1-500(unit 0.1℃) | 0 | 2 | 0 | 0 | 10 | From | To | Description |
|---|
1 | 500 | the temperature change threshold value(unit 0.1℃) |
|
104 | The interval time of sending the battery level reporting. | The interval time of sending the battery level reporting. if setting to 0 then the battery level reporting is disabled 1. Valid values: 0x00-0x28DE80 2. The minimum interval time is 1 minutes. For example, if the value is set to be more than 1 and less than 60, the interval time is 1 minutes, if the value is set to be more than 60 and less than 120, the interval time is 2 minutes. | 0 | 4 | 0 | 0 | 86400 | From | To | Description |
|---|
0 | 0 | the battery level reporting is disabled | 1 | 2678400 | The interval time of sending the battery level reporting is 31 days（2678400 seconds） |
|
113 | Configuration luminance change threshold. | Configuration luminance change threshold. Valid values: 1-65528(unit lx) | 0 | 2 | 0 | 0 | 150 | From | To | Description |
|---|
0 | 32766 | luminance change threshold is 0 to 32766 | -32767 | -1 | luminance change threshold is 32767 to 65528 |
|
114 | Configuration battery level change threshold. | Configuration battery level change threshold. Valid values: 1-100(unit %) | 0 | 1 | 0 | 0 | 10 | From | To | Description |
|---|
1 | 100 | battery level change threshold value(unit)% |
|
10 | Low Battery Power Level | Low Battery Power Level of alarm threshold values: the value range are 10~50 for percentage, so the Battery Low Power level can setting 10%~50%. | 0 | 1 | 0 | 0 | 10 | From | To | Description |
|---|
10 | 50 | Low Battery Power Level of alarm threshold values |
|
