Product Recognition | |
|---|
Certification Number | ZC10-18116315 |
|---|
Name | AC Master Lite |
|---|
Short Description | ZXT-510, AC Master Lite, is a Z-Wave plus compliant Z-Wave-to-IR Bridge to control split air conditioner by receiving Z-Wave command and translating to Infrared command. |
|---|
Long Description | ZXT-510, AC Master Lite, is a Z-Wave plus compliant Z-Wave-to-IR Bridge to control split air conditioner by receiving Z-Wave command and translating to Infrared command. With its comprehensive built-In and cloud-stored IR database (library). ZXT-510 can control different brands and models of air conditioners worldwide.
ZXT-510 is a security enabled Z-Wave plus device. A security Enabled Z-Wave Plus Controller must be used in order to fully utilize the product.
ZXT-510 is a Z-Wave slave device, it depends on gateway to setup particular AC brand with correct IR code. Different gateway has different user interface for setup. |
|---|
Brand | Remotec |
|---|
Product Identifier | ZXT-510EU |
|---|
OEM Version | HW: 0 FW: 1.04:01.07:182.03 |
|---|
Hardware Platform | SD3502 |
|---|
Z-Wave Version | 6.61.00 |
|---|
Library Type | SLAVE_ENHANCED_232 |
|---|
Device Type | Thermostat - HVAC |
|---|
Role Type | ROLE_TYPE_SLAVE_SLEEPING_LISTENING |
|---|
Manufacturer ID | 0x5254 |
|---|
Product Type ID | 0x0102 |
|---|
Product ID | 0x8290 |
|---|
User Icon | 0x1200 |
|---|
Installer Icon | 0x1200 |
|---|
Frequency Plans | EU: 869.85MHz, 868.40MHz |
|---|
Categories | Thermostats |
|---|
Countries / Regions | European Union |
|---|
Supported Command Classes | Identifier | Name | Key | Version |
|---|
COMMAND_CLASS_POWERLEVEL | Powerlevel | 0x73 | 1 | COMMAND_CLASS_THERMOSTAT_FAN_MODE_V4 | Thermostat Fan Mode V4 | 0x44 | 4 | COMMAND_CLASS_BATTERY | Battery | 0x80 | 1 | COMMAND_CLASS_APPLICATION_STATUS | Application Status | 0x22 | 1 | COMMAND_CLASS_BASIC | Basic | 0x20 | 1 | COMMAND_CLASS_SECURITY | Security S0 | 0x98 | 1 | COMMAND_CLASS_SENSOR_MULTILEVEL_V7 | Sensor Multilevel V7 | 0x31 | 7 | COMMAND_CLASS_THERMOSTAT_MODE_V3 | Thermostat Mode V3 | 0x40 | 3 | COMMAND_CLASS_THERMOSTAT_SETPOINT_V3 | Thermostat Setpoint V3 | 0x43 | 3 | COMMAND_CLASS_VERSION_V2 | Version V2 | 0x86 | 2 | COMMAND_CLASS_DEVICE_RESET_LOCALLY | Device Reset Locally | 0x5A | 1 | COMMAND_CLASS_ZWAVEPLUS_INFO_V2 | Z-Wave Plus Info V2 | 0x5E | 2 | COMMAND_CLASS_ASSOCIATION_V2 | Association V2 | 0x85 | 2 | COMMAND_CLASS_ASSOCIATION_GRP_INFO_V3 | Association Group Information V3 | 0x59 | 3 | COMMAND_CLASS_CONFIGURATION_V2 | Configuration V2 | 0x70 | 2 | COMMAND_CLASS_FIRMWARE_UPDATE_MD_V3 | Firmware Update Meta-Data V3 | 0x7A | 3 | COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2 | Manufacturer Specific V2 | 0x72 | 2 |
|
|---|
Documents | Category | Description | File |
|---|
Manual_Primary_Lang | Product or Owner's Manual | |
|
|---|
Features | Feature | Values |
|---|
Thermostat Modes | Value |
|---|
Heat | Cool | Auto | Resume | Fan Only | Dry Air | Away |
| Color | | Thermostat HVAC Systems Supported | | Firmware Updatable | Value |
|---|
Updatable by Consumer by RF |
| Sensors | | Battery Type | |
|
|---|
Association Groups | Group Number | Maximum Nodes Supported | End Point ID | Description |
|---|
1 | 1 | 0 | Z-Wave Plus Lifeline |
|
|---|
Configuration Parameters | |
|---|
Texts | ID | Description | Value |
|---|
2 | Exclusion | 1 Refer to your primary controller to enter into Exclusion Mode
2 When it is prompted to enter it, please triple click the “PROG” button within 1 second.
3. Green Indicator flashes TWICE then stay off | 5 | Factory Reset | Press and Hold ""PROG"" button for 3 seconds on AC Master Lite, the Green Indicator will light up. DO NOT Release the ""PROG"" Button until Green Indicator flashes TWICE.
Remark : Please use this procedure only when the network primary controller is missing or otherwise incoperable. | 1 | Inclusion | 1 Refer to your primary controller to enter into Inclusion Mode
2 When it is prompted to enter it, please triple click the “PROG” button within 1 second.
3. Green Indicator flashes TWICE then stay off | 4 | Device Wake-Up | Press the ""PROG"" button to wakeup the unit |
|
|---|
Supported Multilevel Sensors | Multilevel Sensor Type |
|---|
Air temperature |
|
|---|
Supports NWI | Yes |
|---|
Supports Explorer Frames | Yes |
|---|
Is Flirs | Yes |
|---|
Radio Range Z-Wave (m) | 40 |
|---|
