Manual_Primary_Lang

Product or Owner's Manual

1

5

0

Z-Wave Plus Lifeline.

2

5

0

Sensor Multilevel Temperature Report.

4

Configuration Bitmask

Configuration bitmask for various device configuration settings. Bit 0 - reserved. Bit 1 - If set to 1, sensor will send unsolicited temperature reports. Bits 2 to 15 - reserved

0

2

0

0

2

5

Battery Reporting Interval

The number wakeup intervals between autonomous battery reports.

0

2

0

0

8

6

Temperature Checking Interval

The number of seconds between temperature readings.

0

2

0

0

60

8

Temperature Calibration Offset

Adjust reported temperature by +/- 10 degrees Fahrenheit for calibration.

0

2

0

0

0

9

Mandatory Temperature Reporting Interval

Temperature will be reported regardless of differential from threshold.

0

2

0

0

7200

1

Wake Up Period

Number of seconds the sensor will stay in the Wake up state following a button press. The sensor will go to sleep if it receives a wake up no more information frame.

0

2

0

0

600

2

Low Battery Level

Low Battery Report threshold.

0

2

0

0

1755

7

Temperature Reporting Interval

The number wakeup intervals between autonomous temperature reports. These interval reports should be sent regardless of the setting of the temperature reporting threshold.

0

2

0

0

0

3

Temperature Reporting Threshold

The minimum temperature difference required to send a new ambient temperature report.

0

2

0

0

10

5

Factory Reset

NOTE: Only reset the sensor to factory default when the primary controller is missing or inoperable. Press and hold the button for 15 seconds. Release the button after 15 seconds and the LED will blink rapidly when the sensor has been reset to factory default.

4

Device Wake-Up

The temperature sensor will send wake up notifications when the button is pressed and the temperature sensor is already included in a Z-Wave network. It also sends wake up notifications based at time intervals specified in the wake up set command.

1

Inclusion

Put the Z-Wave controller into add mode (refer to controller documentation for more information). Press the button on the sensor to add to the Z-Wave network. The LED on the sensor will go solid white when the sensor has been successfully added.

2

Exclusion

Put the Z-Wave controller into remove mode (refer to the controller documentation for more information). Press the button on the sensor to remove from the Z-Wave network. The LED on the sensor will blink white when the sensor has been successfully removed.
