COMMAND_CLASS_SOUND_SWITCH

Sound Switch

0x79

1

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4

Firmware Update Meta-Data V4

0x7A

4

COMMAND_CLASS_SCENE_ACTUATOR_CONF

Scene Actuator Conf

0x2C

1

COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_SWITCH_BINARY

Switch Binary

0x25

1

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_CONFIGURATION

Configuration

0x70

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_TRANSPORT_SERVICE_V2

Transport Service V2

0x55

2

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_SECURITY_2

Security S2

0x9F

1

COMMAND_CLASS_SUPERVISION

Supervision

0x6C

1

COMMAND_CLASS_SCENE_ACTIVATION

Scene Activation

0x2B

1

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

Adv_Manual

Advanced Information Product Manual

Manual_Primary_Lang

ClareOne Siren Product Manual.pdf

Manual_English

ClareOne Siren Product Manual.pdf

Z-Wave Scene Type

Firmware Updatable

2

5

0

Retransmit

0x0000

Retransmit a Basic Set, Switch Binary Set, Sound Switch Tone Play Set to the nodes associated.

1

5

0

Lifeline

0x0001

Lifeline group. Device Reset Locally Notification: Issued when Factory Reset is performed. Sound Switch Tone Play Report: Issued when a tone has started playing. Sound Switch Configuration Report: Issued when volume or default tone has changed. Basic Report: Issued when a tone changed and Configuration parameter 80 set enable. Switch Binary Report: Issued when a tone changed and Configuration parameter 80 set enable. Configuration Report: Issued when Confiugration Set 255 to reset configuration parameter.

80

Parameter 3

This parameter is used to configure command to report to lifeline when tone changed.

1

1

0

2

2

255

Parameter 4

Reset Configuration Parameter to factory setting OR Factory Reset the product.

1

4

0

1431655765

0

8

Where to find S2 DSK on product

QR/PIN code can be found on the product.

2

Classic Exclusion

1. Make sure the product is powered. 2. Set your main controller into its 'remove product' mode. Refer to its manual if you are unsure of how to perform. 3. Click button once. 4. Wait for the removing process to end. 5. Confirm the removing result. Successful removing will be confirmed by the Z-Wave controller’s message or LED status. If removing is successful, Network LED will slow flash 3 times and then off. Ifits Network LED allways stays off state, it indicates removing is unsuccessful.Repeat the above steps or contact us for further support if needed.

5

Factory Reset Procedure

Reset procedure allows to restore theproduct back to its factory settings, which means all information about the Z-Wave controller anduser configuration will be deleted. 1. Make sure the product is powered. 2. Press and hold the buttonfor at least 20s, and then Factory Reset is performed.The product will issue a Device Reset Locally Command via its Lifeline to notify the Lifeline destination that the product has been reset to its factory default state. And it will perform the reset operation regardless of whether or not the delivery of the Device Reset Locally Notification is successful. 3. Pay attention to the Network LED state change. After few seconds the product will be reset and restarted, which is signaled with the Network LED slow flash 3 times and then off.

1

Classic Inclusion

1.Power the product. 2. Set your main controller into its 'add product' mode. Refer to its manual if you are unsure of how to perform. 3.Click button once.Network LED will flash quickly which indicates entering inclusion mode, and Node Info will be issued for adding. 4.If your controller supports S2 security, and you want to add the product into S2 Authenticated network, please scanthe QR code or enter the PIN code (the underlined 5-digits of the DSK) when prompted. [IMPORTANT] QR/PIN code can be found on the product. A full DSK string can be found on the packaging. 5. Wait for the adding process to end. 6. Confirm the adding result. Successful adding will be confirmed by the Z-Wave controller’s message or LED status.If adding is successful, Network LED will light stays on and then off. If its Network LED slow flash 3 times and then off ,it indicates adding is unsuccessful.The product will auto-reset and then activate SmartStart. Repeat the above steps or contact us for further support if needed.
