| 10 | Temperature Reporting Filter | The Temperature Reporting Filter configuration command sets upper and lower bounds of the ambient temperature reporting. | 0 | 2 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 31868 | Byte 1: 0 -124F (lower bound), Byte 2: 0-124F (upper bound) |
|
| 1 | Temperature Reporting Threshold | The Temperature Reporting Threshold Configuration Set Command sets the reporting threshold for changes in the ambient temperature as detected by the thermostat. | 0 | 1 | 0 | 0 | 2 | |
| 9 | Thermostat Recovery Mode | The Thermostat Recovery Mode configuration command sets the HVAC recovery mode type. The recovery mode determines when additional HVAC stages are turned off as the ambient temperature returns to the target temperature. | 0 | 1 | 0 | 0 | 2 | | From | To | Description |
|---|
| 1 | 2 | 1 = Fast, 2 = Economy |
|
| 2 | HVAC Settings | The HVAC Settings Configuration Report Command returns the current HVAC configuration. The HVAC settings must be fixed before the thermostat is joined to the Z-Wave network. | 0 | 4 | 0 | 0 | 0 | | From | To | Description |
|---|
| 1 | 2147483647 | Byte 1: normal (1) or heat pump (2). Byte 2, Bits 7-4: Gas (1) or Electric (2). Byte 2, Bits 3-0: # of Auxiliary Stages. Byte 3: # of Heat Pump Stages. Byte 4: # of Cool Stages. |
|
| 11 | Simple UI Mode | Enables or disables Simple UI mode on thermostat via RadioBus Read/Set UI command. | 0 | 1 | 0 | 0 | 1 | | From | To | Description |
|---|
| 0 | 1 | 0 = Normal Mode, 1 = Simple Mode |
|
| 8 | Thermostat Differential Temperature | The Thermostat Differential Temperature configuration command sets the differential temperature for multi-stage HVAC systems. | 0 | 2 | 0 | 0 | 4 | | From | To | Description |
|---|
| 2 | 6 | The thermostat differential temperature is in units of 0.5 degrees Fahrenheit. | | 0 | 1 | 0x00 (Heat) or Cool (0x01) |
|
| 3 | Utility Lock | The Utility Lock Configuration Set command enables or disables the utility lock. If the utility lock is enabled, the setpoint cannot be modified directly via the thermostat screen. | 0 | 1 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 255 | 0 = Disabled, 1 - 255 = Enabled |
|
| 4 | C-Wire/Battery | The C-Wire / Battery Status Configuration Report Command returns the status of the thermostat power source. The power state is fixed when the thermostat joins the network. | 0 | 1 | 0 | 0 | 0 | | From | To | Description |
|---|
| 1 | 2 | 1=C-Wire, 2=Battery |
|
| 5 | Humidity Reporting Threshold | The Humidity Threshold Configuration Set Command sets the reporting threshold for changes in the relative humidity as detected by the thermostat. | 0 | 1 | 0 | 0 | 5 | | From | To | Description |
|---|
| 0 | 3 | 0 = Disabled, 1 = 3% RH, 2 = 5% RH, 3 = 10% RH |
|
| 6 | Auxiliary/Emergency Mode | The Auxiliary/Emergency configuration command enables or disables auxiliary / emergency heating in the thermostat. | 0 | 1 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 1 | 0 = Disabled, 1 = Enabled |
|
| 7 | Thermostat Swing Temperature | The Thermostat Swing Temperature configuration command sets swing temperature on the thermostat. | 0 | 1 | 0 | 0 | 2 | | From | To | Description |
|---|
| 1 | 8 | 1 = 0.5ºF, 2 = 1.0ºF, 3 = 1.5ºF, 4 = 2.0ºF, 5 = 2.5ºF, 6 = 3.0ºF, 7 = 3.5ºF, 8 = 4.0ºF |
|
