COMMAND_CLASS_SENSOR_BINARY

Sensor Binary

0x30

1

COMMAND_CLASS_SCENE_ACTUATOR_CONF

Scene Actuator Conf

0x2C

1

COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_CONTROLLER_REPLICATION

Controller Replication

0x21

1

COMMAND_CLASS_APPLICATION_STATUS

Application Status

0x22

1

COMMAND_CLASS_TIME_PARAMETERS

Time Parameters

0x8B

1

COMMAND_CLASS_SWITCH_BINARY

Switch Binary

0x25

1

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_CRC_16_ENCAP

CRC16 Encapsulation

0x56

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_SWITCH_MULTILEVEL_V3

Switch Multilevel V3

0x26

3

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_MANUFACTURER_SPECIFIC

Manufacturer Specific

0x72

1

COMMAND_CLASS_SCENE_ACTIVATION

Scene Activation

0x2B

1

COMMAND_CLASS_MULTI_CMD

Multi-Command

0x8F

1

COMMAND_CLASS_SENSOR_BINARY

Sensor Binary

0x30

1

COMMAND_CLASS_CLIMATE_CONTROL_SCHEDULE

Climate Control Schedule

0x46

1

COMMAND_CLASS_SENSOR_ALARM

Sensor Alarm

0x9C

1

COMMAND_CLASS_SENSOR_MULTILEVEL_V5

Sensor Multilevel V5

0x31

5

COMMAND_CLASS_NODE_NAMING

Node Naming

0x77

1

COMMAND_CLASS_THERMOSTAT_FAN_MODE

Thermostat Fan Mode

0x44

1

COMMAND_CLASS_USER_CODE

User Code

0x63

1

COMMAND_CLASS_DOOR_LOCK_V2

Door Lock V2

0x62

2

COMMAND_CLASS_ALARM_V2

Alarm V2

0x71

2

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3

Multi-Channel Association V3

0x8E

3

COMMAND_CLASS_CONTROLLER_REPLICATION

Controller Replication

0x21

1

COMMAND_CLASS_CLOCK

Clock

0x81

1

COMMAND_CLASS_BATTERY

Battery

0x80

1

COMMAND_CLASS_APPLICATION_STATUS

Application Status

0x22

1

COMMAND_CLASS_TIME

Time

0x8A

1

COMMAND_CLASS_THERMOSTAT_OPERATING_STATE

Thermostat Operating State

0x42

1

COMMAND_CLASS_SWITCH_BINARY

Switch Binary

0x25

1

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_HAIL

Hail

0x82

1

COMMAND_CLASS_CRC_16_ENCAP

CRC16 Encapsulation

0x56

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_THERMOSTAT_MODE_V2

Thermostat Mode V2

0x40

2

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_WAKE_UP_V2

Wake Up V2

0x84

2

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_BARRIER_OPERATOR

Barrier Operator

0x66

1

COMMAND_CLASS_SWITCH_MULTILEVEL_V3

Switch Multilevel V3

0x26

3

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_MULTI_CHANNEL_V4

Multi-Channel V4

0x60

4

COMMAND_CLASS_THERMOSTAT_SETPOINT

Thermostat Setpoint

0x43

1

COMMAND_CLASS_METER_TBL_MONITOR

Meter Table Monitor

0x3D

1

COMMAND_CLASS_MANUFACTURER_SPECIFIC

Manufacturer Specific

0x72

1

COMMAND_CLASS_SWITCH_COLOR

Switch Color

0x33

1

COMMAND_CLASS_CENTRAL_SCENE_V3

Central Scene V3

0x5B

3

COMMAND_CLASS_METER_PULSE

Meter Pulse

0x35

1

COMMAND_CLASS_CONFIGURATION_V2

Configuration V2

0x70

2

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2

Firmware Update Meta-Data V2

0x7A

2

COMMAND_CLASS_METER_V2

Meter V2

0x32

2

COMMAND_CLASS_MULTI_CMD

Multi-Command

0x8F

1

COMMAND_CLASS_SCHEDULE_ENTRY_LOCK_V3

Schedule Entry Lock V3

0x4E

3

Manual_Primary_Lang

Product or Owner's Manual

Color

Communications Connections

Communications Protocol

Firmware Updatable

Sensors

Supported Notification Types

1

1

0

Z-Wave Plus Lifeline

23

Controller Inclusion

To include a Z-Wave product into the network, you can use the UI and follow the on- screen instructions that read as follows: Select Add device -> Pick the device to be included in the network from the list -> Follow the steps for inclusion of the device -> Once the device is detected, save the name of the device and the device completes the configuration process.

3

Learn Mode (adding another controller)

To include the controller into an existing Z-Wave network, use the UI and follow the steps below. Click on Settings -> Z-Wave Settings -> Advanced, select 'Copy Z-Wave network from a primary controller. This will shift the controller to have a secondary controller role and will receive data from the primary controller in the network.

24

Controller Exclusion

To exclude a Z-Wave product into the network, you can use the UI and follow the on- screen instructions that read as follows: Navigate to the device -> Select the delete device option -> Choose to un-pair and follow the instructions.

5

Factory Reset

If this controller is the primary controller for your network, resetting it will result in the nodes in your network being orphaned and it will be necessary after the reset to exclude and re-include all of the nodes in the network. If this controller is being used as a secondary controller in the network, use this procedure to reset this controller only in the event that the network primary controller is missing or otherwise inoperable. To reset the controller, press the reset button for 6 times in 6 seconds. This will reset it to factory default.
