51 | Disable 700ms Delay | Removes the 700ms delay after tapping up or down. Note: This will remove multi-tap scene control. However, you will still have scene control when you tap up/down 1x, hold up/down, or press the config button. | 1 | 1 | 0 | 1 | 1 | From | To | Description |
|---|
0 | 0 | No Delay (ie: Removes 700ms delay) | 1 | 1 | Delay (700ms) |
|
52 | Smart Bulb Mode | Puts the device into smart bulb mode, which allows you to put a smart bulb on your switch. In this mode, the switch will act as a remote and not cut power to the smart bulb, but rather it will send central scene commands to the hub to turn on/off the smart bulb. | 1 | 1 | 0 | 1 | 0 | From | To | Description |
|---|
0 | 0 | Non-Smart Bulb Mode | 1 | 1 | Smart Bulb Mode |
|
1 | Dimming Speed | How fast or slow the light turns on when you hold the switch (ie: dimming from 10-20%, 80-60%, etc). Example of how the values work: 0 - Instant On, 1 = 1 second, 100 = 100 seconds. This parameter can be set without a HUB from the Configuration Button. Finally, if you are using a, "dumb" switch in a 3-Way setting, this parameter will not work if you manually press the dumb switch (it will only work if you press the smart switch). | 0 | 1 | 0 | 100 | 3 | From | To | Description |
|---|
1 | 100 | Seconds |
|
8 | Auto Off Timer | Automatically turns the switch off after x amount of seconds. Example of how the values work: 0 = Disabled, 1 = 1 second, 32767 = 32767 seconds. | 0 | 2 | 0 | 32767 | 0 | From | To | Description |
|---|
0 | 0 | Disabled | 1 | 32767 | Seconds |
|
4 | Ramp Rate (Z-Wave) | How fast or slow the light turns on when you bring your switch from On to Off or Off to On remotely. Example of how the values work: 0 = Instant On, 1 = 1 second, 100 = 100 seconds. Entering the value of 101 = Keeps the switch in sync with Parameter 1. | 0 | 1 | 0 | 101 | 101 | From | To | Description |
|---|
0 | 100 | Seconds | 101 | 101 | Keeps in sync with Parameter 1 |
|
2 | Dimming Speed (Z-Wave) | How fast or slow the light turns dim when you adjust the switch remotely (ie: dimming from 10-20%, 80-60%, etc). Example of how the values work: 0 = Instant On, 1 = 1 second, 100 = 100 seconds. Entering the value of 101 = Keeps the switch in sync with Parameter 1. | 0 | 1 | 0 | 101 | 101 | From | To | Description |
|---|
101 | 101 | Keeps in sync with Parameter 1 | 0 | 100 | Seconds |
|
3 | Ramp Rate | How fast or slow the light turns on when you press the switch 1x to bring from On to Off or Off to On. Example of how the values work: 0 = Instant On, 1 = 1 second, 100 = 100 seconds. Entering the value of 101 = Keeps the switch in sync with Parameter 1. | 0 | 1 | 0 | 101 | 101 | From | To | Description |
|---|
101 | 101 | Keeps in sync with Parameter 1 | 0 | 100 | Seconds |
|
5 | Minimum Dim Level | Minimum level the light switch will dim to (great for fixing flickering bulbs). Example of how the values work: 1= 1%, 2 = 2%, 45 = 45%. This parameter can be set without a HUB from the Configuration Button. | 0 | 1 | 0 | 45 | 1 | From | To | Description |
|---|
1 | 45 | Percent |
|
6 | Maximum Dim Level | Maximum level the light switch will dim to. Example of how the values work: 55 = 55%, 56 = 56%, 100 = 100%. This parameter can be set without a HUB from the Configuration Button. | 0 | 1 | 0 | 100 | 100 | From | To | Description |
|---|
55 | 100 | Percentage |
|
7 | Invert Switch | Inverts the switch (Tap Down = On, Tap Up = Off). Example of how the values work: 0 = Disabled, 1 = Enabled. This parameter can be set without a HUB from the Configuration Button. | 0 | 1 | 0 | 1 | 0 | From | To | Description |
|---|
0 | 0 | Disabled | 1 | 1 | Enabled |
|
9 | Default Level (Local) | Default dim level for the switch when pressed locally (at the switch). This is useful if you'd like your switch to turn on to a certain level when manually pressing the switch during certain times. For example, you could have your switch turn on to 10% brightness during the hours of 10pm - 6am when you manually press it. Example of how the values work: 0 = Switch will return to level it was prior to being off, 1 = 1%, 100 = 100%. This parameter can be set without a HUB from the Configuration Button. | 0 | 1 | 0 | 100 | 0 | From | To | Description |
|---|
1 | 100 | Percentage | 0 | 0 | Switch returns to level it was prior to being turned off |
|
10 | Default Level (Z-Wave) | Default dim level for the switch when powered on via a Z-Wave command. This is useful if you'd like your switch to turn on to a certain level when remotely controlling the switch during certain times. For example, you could have your switch only turn on to 10% brightness during the hours of 10pm - 6am when you remotely control it. Example of how the values work: 0 = Switch will return to level it was prior to being off, 1 = 1%, 100 = 100%. This parameter can be set without a HUB from the Configuration Button. | 0 | 1 | 0 | 100 | 0 | From | To | Description |
|---|
0 | 0 | Switch returns to level it was prior to being turned off | 1 | 100 | Percentage |
|
11 | Power On State | When power is restored, the switch reverts to either On, Off, or Last Level. Example of how the values work: 0 = Off, 1-100 = Specific % On, 101 = Returns to Level before Power Outage. This parameter can be set without a HUB from the Configuration Button. | 0 | 1 | 0 | 101 | 0 | From | To | Description |
|---|
0 | 0 | When Power is restored, switch is OFF | 1 | 100 | When Power is restored, switch turns ON to a certain dim level | 101 | 101 | When Power is restored, switch reverts to last status |
|
17 | LED Indicator Timeout | Changes the amount of time the RGB Bar shows the Dim level if the LED Bar has been disabled. Example of how the values work: 0 = Always off, 1 = 1 second after level is adjusted, 10 = 10 seconds after level is adjusted. | 0 | 1 | 0 | 10 | 3 | From | To | Description |
|---|
0 | 0 | Always Off | 1 | 10 | Seconds after level is adjusted |
|
