7 | Invert Switch | Inverts the switch (Tap Down = On, Tap Up = Off). Example of how the values are used: 0 = Disabled, 1 = Enabled. This parameter can be changed at the config button. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Disabled | 1 | 1 | Enabled |
|
8 | Auto Off Timer | Automatically turns the switch off after x amount of seconds. Example of how the values are used: 0 = Disabled, 1 = 1 second, 32767 = 32767 seconds. | 0 | 2 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 32767 | automatically turns off after so many seconds |
|
17 | Timeout for LED Notifications | Changes the amount of time the RGB Bar shows the Dim level if the LED Bar has been disabled. Example of how the values are used: 0 = Always off, 1 = 1 second after level is adjusted, 10 = 10 seconds after level is adjusted. | 0 | 1 | 0 | 0 | 3 | From | To | Description |
|---|
0 | 0 | Always Off | 1 | 10 | Seconds after Dim Level is Adjusted |
|
1 | Dimming Speed | How fast or slow the light turns on when you hold the switch (ie: dimming from 10-20%, 80-60%, etc). Example of how the values are used: 0 = Instant On, 1 = 1 second, 100 = 100 seconds. This parameter can be changed at the config button. NOTE IF USING A DUMB SWITCH: This parameter will not work when pressing the dumb switch manually. | 0 | 1 | 0 | 0 | 3 | From | To | Description |
|---|
0 | 100 | Seconds |
|
4 | Ramp Rate (Z-Wave) | How fast or slow the light turns on when you turn on or off the switch remotely to bring from On to Off or Off to On. Example of how the values are used: 0 = Instant On, 1 = 1 second, 100 = 100 seconds. A value of 101 keeps this parameter in sync with Parameter 1. | 0 | 1 | 0 | 0 | 101 | From | To | Description |
|---|
101 | 101 | Keeps in sync with Parameter 1 | 0 | 0 | Instant On | 1 | 100 | Seconds |
|
3 | Ramp Rate | How fast or slow the light turns on when you press the switch 1x to bring from On to Off or Off to On. Example of how the values are used: 0 = Instant On, 1 = 1 second, 100 = 100 seconds. A value of 101 keeps this parameter in sync with Parameter 1. | 0 | 1 | 0 | 0 | 101 | From | To | Description |
|---|
101 | 101 | Keeps in sync with Parameter 1 | 0 | 0 | Instant On | 1 | 100 | Seconds |
|
10 | Default Level (Z-Wave) | Default dim level for the switch when controlled remotely (via an app or voice control). Example of how the values are used: 0 = Switch will return to level it was prior to being off, 1 = 1%, 100 = 100%. This parameter can be changed at the config button. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
1 | 100 | Percentage | 0 | 0 | Previous Level |
|
11 | Power On State | When power is restored, the switch reverts to either On, Off, or Last Level. Example of how the values are used: 0 = Off, 1-100 = Specific % On. Entering a value of 101 = Returns the switch to the Level before the Power Outage. This parameter can be changed at the config button. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
101 | 101 | Turns On to Last Percentage Level | 0 | 0 | Off | 1 | 100 | Turns On to a Specific Percentage Level |
|
5 | Minimum Dim Level | Minimum level the light switch will dim to (great for fixing flickering bulbs). Example of how the values are used: 1= 1%, 2 = 2%, 45 = 45%. This parameter can be changed at the config button. | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
1 | 45 | Percentage |
|
6 | Maximum Dim Level | Maximum level the light switch will dim to. Example of how the values are used: 55= 55%, 56 = 56%, 100 = 100%. This parameter can be changed at the config button. | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
55 | 100 | Percentage |
|
9 | Default Level (Local) | Default dim level for the switch when pressed locally (at the switch). Example of how the values are used: 0 = Switch will return to level it was prior to being off, 1 = 1%, 100 = 100%. This parameter can be changed at the config button. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Previous Level | 1 | 100 | Percentage |
|
2 | Dimming Speed (Z-Wave) | How fast or slow the light turns on when you dim the switch remotely (ie: dimming from 10-20%, 80-60%, etc). Example of how the values are used: 0 = Instant On, 1 = 1 second, 100 = 100 seconds. A value of 101 keeps this parameter in sync with Parameter 1. | 0 | 1 | 0 | 0 | 101 | From | To | Description |
|---|
1 | 100 | Seconds | 101 | 101 | Keeps in sync with Parameter 1 | 0 | 0 | Instant On |
|
