| Product Recognition | — |
|---|
| Certification Number | ZC08-13060011 |
|---|
| Name | Door-Window Sensor |
|---|
| Long Description | This device is an accessory of the Z-Wave system and enable detection of opened or closed access locations in your home.
Features:
* Detects when your door/window is opened or closed
* Magnetic separation trigger function
* Hidden tamper prevention Trigger
* Low battery detection
* External Switch
* 100ft line of sight
* LED Status Indicator
* Operating temp: -15oC~60oC
* Working Voltage: 3V
* Dimensions: 87*25*21mm |
|---|
| Brand | Vision |
|---|
| Product Identifier | ZD2102JP |
|---|
| OEM Version | v04 |
|---|
| Hardware Platform | ZM4101 |
|---|
| Z-Wave Version | 6.11.01 |
|---|
| Library Type | SLAVE_ENHANCED |
|---|
| Device Type | Not Z-Wave Plus |
|---|
| Manufacturer ID | 0x0109 |
|---|
| Product Type ID | 0x2001 |
|---|
| Product ID | 0x0104 |
|---|
| Frequency Plans | JP: 922.50MHz, 923.90MHz, 926.30MHz |
|---|
| Categories | Sensors |
|---|
| Countries / Regions | Japan |
|---|
| Controlled Command Classes | | Identifier | Name | Key | Version |
|---|
| COMMAND_CLASS_BASIC | Basic | 0x20 | 1 |
|
|---|
| Documents | |
|---|
