Z-Wave Plus Lifeline Using meter report, report Meter data of Clamp 1, Clamp2.

2

5

0

Using meter report, report the Meter data of Clamp1.

3

5

0

Using meter report, report the meter data of Clamp2.

95

GMRTL3_W

Group3 Watt Trigger level value Set the trigger value (0~65535) of Meter report in the Parameter 2

0

2

0

0

50

91

GMRTL1_W

Group1 Watt Trigger level value Set the trigger value (0~65535) of Meter report in the Parameter 2

0

2

0

0

50

101

GRCCS1

GRCCS – Group1 Report Command Class Setup Group1 report CRC16( Group report crc16 enable/disable) 0x00 Group report CRC16 Disable 0x01 Group report CRC16 Enable Meter Report Scale Select( select the scale which is used for Meter report event) 0x00 Meter report command scale (kWh) 0x02 Meter report command scale (Watt)

0

4

0

0

0

102

GRCCS2

GRCCS – Group2 Report Command Class Setup Group2 report CRC16( Group report crc16 enable/disable) 0x00 Group report CRC16 Disable 0x01 Group report CRC16 Enable Meter Report Scale Select( select the scale which is used for Meter report event) 0x00 Meter report command scale (kWh) 0x02 Meter report command scale (Watt)

0

4

0

0

2

103

GRCCS3

GRCCS – Group3 Report Command Class Setup Group3 report CRC16( Group report crc16 enable/disable) 0x00 Group report CRC16 Disable 0x01 Group report CRC16 Enable Meter Report Scale Select( select the scale which is used for Meter report event) 0x00 Meter report command scale (kWh) 0x02 Meter report command scale (Watt)

0

4

0

0

2

111

GRIC1

Set the Interval time of Report group1 (60~65535 second)

0

4

0

0

720

113

GRIC3

Set the Interval time of Report group3 (60~65535 second)

0

4

0

0

720

92

GMRTL1_kWh

Group1 kWh Trigger level value Set the trigger value (0~65535) of Meter report in the Parameter 2

0

2

0

0

50

93

GMRTL2_W

Group2 Watt Trigger level value Set the trigger value (0~65535) of Meter report in the Parameter 2

0

2

0

0

50

94

GMRTL2_kWh

Group2 kWh Trigger level value Set the trigger value (0~65535) of Meter report in the Parameter 2

0

2

0

0

50

96

GMRTL3_kWh

Group3 kWh Trigger level value Set the trigger value (0~65535) of Meter report in the Parameter 2

0

2

0

0

50

112

GRIC2

Set the Interval time of Report group2 (60~65535 second)

0

4

0

0

720

2

AMRC

AMRC (Automatically meter report control) is the report mode setting for Meter data. 00b : Clear Meter Report. 01b : Report the event in case value is bigger than Parameter 91~96. Report interval is 31 seconds after triggering. 10b : Automatic Report with the set interval in Parameter 111~113.

0

1

0

0

2

3

MRCS

Meter report clamp select (MRCS) sets the Meter data which is reported by “Get command” of Meter Command Class that does not use “Multi Channel Command Encapsulation Command” (without Destination End Point). 0x01 : Clamp1 meter data 0x02 : Clamp2 meter data 0x03 : Sum of the Meter data’s Clamp 1, 2

0

1

0

0

1

255

Reset

Reset to the default configuration parameter 2 : Initialize Parameter 2 3 : Initialize Parameter 3 91 : Initialize Parameter 91 92 : Initialize Parameter 92 93 : Initialize Parameter 93 94 : Initialize Parameter 94 95 : Initialize Parameter 95 96 : Initialize Parameter 96 101 : Initialize Parameter 101 102 : Initialize Parameter 102 103 : Initialize Parameter 103 111 : Initialize Parameter 111 112 : Initialize Parameter 112 113 : Initialize Parameter 113 255 : Reset all parameters to the default

0

1

0

0

255

1

Inclusion

A. Confirm that a device must be wireless access to Z-Wave network. (Fn Display: Green LED OFF) B. Set “NW Inclusion” or “Node Add” by controller. C. Press Fn switch 3 times in a row to include device to Z-Wave network. (Fn Display: Green LED blinking) Press Fn switch 3 times in a row to cancel during including Z-Wave network. (Fn Display: Green LED OFF) D. Confirm that a device is including to Z-Wave network. (Fn Display: Green LED blinking)

5

Factory Reset

Use this procedure only in the event that the network primary controller is missing or otherwise inoperable. Press Fn switch over 10~15 sec to initialize connecting network information.

2

Exclusion

A. Confirm that a device is including to Z-Wave network. (Fn Display: Green LED blinking) B. Set “Node remove” by controller. C. Press Fn switch 3 times in a row to cancel during including Z-Wave network. (Fn Display: Red LED blinking) If the controller is not on “Node remove” status, device will automatically cancel “Exclusion”. (Fn Display: Green LED ON) D. Confirm that it remove the device from Z-Wave network. (Fn Display Green LED - OFF)
