COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4

Firmware Update Meta-Data V4

0x7A

4

COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_PROTECTION_V2

Protection V2

0x75

2

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3

Multi-Channel Association V3

0x8E

3

COMMAND_CLASS_APPLICATION_STATUS

Application Status

0x22

1

COMMAND_CLASS_SWITCH_BINARY

Switch Binary

0x25

1

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_CONFIGURATION

Configuration

0x70

1

COMMAND_CLASS_CRC_16_ENCAP

CRC16 Encapsulation

0x56

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_TRANSPORT_SERVICE_V2

Transport Service V2

0x55

2

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_MULTI_CHANNEL_V4

Multi-Channel V4

0x60

4

COMMAND_CLASS_NOTIFICATION_V8

Notification V8

0x71

8

COMMAND_CLASS_SECURITY_2

Security S2

0x9F

1

COMMAND_CLASS_CENTRAL_SCENE_V3

Central Scene V3

0x5B

3

COMMAND_CLASS_SUPERVISION

Supervision

0x6C

1

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

COMMAND_CLASS_ASSOCIATION_GRP_INFO_V2

Association Group Information V2

0x59

2

COMMAND_CLASS_BASIC

Basic

0x20

1

Manual_Primary_Lang

Product Manual

Electric Load Type

Firmware Updatable

Z-Wave Scene Type

Color

1

1

0

Lifeline

0x0001

“Lifeline” reports the device status and allows for assigning single device only (main controller by default).

2

5

1

On/Off (1)

0x2001

Is used to turn the associated devices on/off reflecting input operation for 1st channel (uses Basic command class).

3

5

2

On/Off (S2)

0x2002

Is used to turn the associated devices on/off reflecting input operation for 2nd channel (uses Basic command class).

31

Alarm configuration - 2nd slot

This parameter determines to which alarm frames and how the device should react. The parameters consist of 4 bytes, three most significant bytes are set according to the official Z-Wave protocol specification. Default value [0x05, 0xFF, 0x00, 0x00] (Water alarm, any notification, no action). The 4 bytes must be converted to a single decimal value to be entered in the gateway sending the configuration parameter value. Example: Event: Home Security (0x07) Status: Motion Detected (0x08) Parameter: None (0x00) Action: turn ON (0x01)=0x07080001 which is 117964801 decimal to be entered in the gateway.

1

4

0

2147483647

100597769

1

Remember relays state

This parameter determines the state of relays after power supply failure (e.g. power outage). For auto OFF and flashing modes the parameter is not relevant and the relay will always remain switched off.

1

1

0

2

1

24

Inputs orientation

This parameter allows reversing operation of S1 and S2 inputs without changing the wiring. Use in case of incorrect wiring.

1

1

0

1

0

25

Outputs orientation

This parameter allows reversing operation of Q1 and Q2 outputs without changing the wiring. Use in case of incorrect wiring.

1

1

0

1

0

152

First channel - reaction to input change in delayed/auto OFF modes

This parameter determines how the device reacts when changing state of S1 input in timed modes for first channel.

1

1

0

2

0

153

Second channel – reaction to input change in delayed/ auto OFF modes

This parameter determines how the device reacts when changing state of S2 input in timed modes for second channel.

1

1

0

2

0

154

First channel – time parameter for delayed/auto OFF and flashing modes

This parameter allows to set time parameter used in timed modes for first channel. For delayed/ auto OFF modes it determines duration, for flashing mode it determines cycle period.

1

2

0

32000

5

157

S1 input – Switch OFF value sent to 2nd association group

This parameter defines value sent with Switch OFF command to devices in 2nd association group when using S1 input.

1

2

0

255

0

150

First channel – operating mode

This parameter allows to choose operating mode for channel controlled with Q/Q1 output. For timed modes (value 1, 2 or 3), time is set with parameter 154 and reaction to input change is set with parameter 152.

1

1

0

3

0

155

Second channel – time parameter for delayed/auto OFF and flashing modes

This parameter allows to set time parameter used in timed modes for second channel. For delayed/auto OFF modes it determines duration, for flashing mode it determines cycle period.

1

2

0

32000

5

160

S2 input – Switch OFF value sent to 3rd association group

This parameter defines value sent with Switch OFF command to devices in 3rd association group when using S2 input.

1

2

0

255

0

156

ParaS1 input – Switch ON value sent to 2nd association group

This parameter defines value sent with Switch ON command to devices in 2nd association group when using S1 input.

1

2

0

255

255

158

S1 input – Double Click value sent to 2nd association group

This parameter defines value sent with Double Click command to devices in 2nd association group when using S1 input.

1

2

0

255

99

163

Q2 output type

This parameter determines type of Q2 output.

1

1

0

1

0

159

S2 input – Switch ON value sent to 3rd association group

This parameter defines value sent with Switch ON command to devices in 3rd association group when using S2 input.

1

2

0

255

255

161

S2 input – Double Click value sent to 3rd association group

This parameter defines value sent with Double Click command to devices in 3rd association group when using S2 input.

1

2

0

255

99

162

Q/Q1 output type

This parameter determines type of Q/Q1 output.

1

1

0

1

0

164

Lock simultaneous switching of Q1 and Q2 outputs

When the lock is enabled, both outputs cannot be turned on at the same time.

1

1

0

1

0

1

Classic Inclusion

To add the device to the Z-Wave network manually: 1. Power the device. 2. Set the main controller in (Security/non-Security Mode) add mode (see the controller’s manual). 3. Quickly, three times click button connected to S1/S2 or the maintenance button. 4. LED will start blinking yellow, wait for the adding process to end. 5. If you are adding in Security S2 Authenticated, input the underlined part of the DSK (label on the bottom of the box). 6. Adding result will be confirmed by the Z-Wave controller’s message and the LED: • Green – successful (non-secure, S0, S2 non-authenticated), • Magenta – successful (Security S2 Authenticated), • Red – not successful.

2

Classic Exclusion

To remove the device from the Z-Wave network: 1. Power the device. 2. Set the main controller into remove mode (see the controller’s manual). 3. Quickly, three times click the maintenance button. 4. LED will start blinking yellow, wait for the removing process to end. 5. Successful removing will be confirmed by the Z-Wave controller’s message and red LED colour.

5

Factory Reset Procedure

1. Press and hold the maintenance button to enter the menu. 2. Release button when the device glows yellow. 3. Quickly click the button to confirm. 4. After few seconds the device will be restarted, which is signalled with red LED colour.

8

Where to find S2 DSK on product

If you are adding in Security S2 Authenticated, input the underlined part of the DSK (label on the bottom of the box).
