1 | Door window state | This parameter allows to set in what state is door window when the magnet is close to the sensor. 0 - closed when magnet near 1 - opened when magnet near | 0 | Yes | 1 | 0 | 1 | 0 | From | To | Description |
|---|
0 | 0 | closed when magnet near | 1 | 1 | opened when magnet near |
|
11 | 2nd association group triggers | Parameter defines events which result in sending on-off commands to devices added to the 2nd association group. These commands are sent alternately to switch the devices on and off. 0 - switch after opening and closing 1 - switch after opening (parameter 12) 2 - switch after closing (parameter 13) | 0 | Yes | 1 | 0 | 2 | 0 | From | To | Description |
|---|
1 | 1 | switch after opening (parameter 12) | 2 | 2 | switch after closing (parameter 13) | 0 | 0 | switch after opening and closing |
|
31 | Tamper - reporting alarm cancellation | Reporting cancellation of tamper alarm to the controller and 3rd association group. 0 - do not send tamper cancellation report 1 - send tamper cancellation report | 0 | Yes | 1 | 0 | 1 | 1 | From | To | Description |
|---|
1 | 1 | send tamper cancellation report | 0 | 0 | do not send tamper cancellation report |
|
50 | Interval of temperature measurements | This parameter defines how often the temperature will be measured. The shorter the time, the more frequently the temperature will be measured, but the battery life will shorten. 0 - temperature measurements disabled 5-32400 - time in seconds | 0 | Yes | 2 | 0 | 32400 | 300 | From | To | Description |
|---|
0 | 0 | temperature measurements disabled | 5 | 32400 | time in seconds |
|
52 | Interval of temperature reports | This parameter determines how often the temperature reports will be sent to the main controller (regardless of parameters 50 and 51). 0 - periodic temperature reports disabled 300-32400 - time in seconds | 0 | Yes | 2 | 0 | 32400 | 0 | From | To | Description |
|---|
0 | 0 | periodic temperature reports disabled | 300 | 32400 | time in seconds |
|
53 | Temperature offset | The value to be added to the actual temperature, measured by the sensor (temperature compensation). - 1000–1000 (-100–100C, 0.1C step) | 0 | Yes | 2 | -1000 | 1000 | 0 | From | To | Description |
|---|
-1000 | 1000 | (-100–100C, 0.1C step) |
|
54 | Temperature alarm reports | Temperature alarms reported to the Z-Wave controller. Thresholds are set in parameters 55 and 56. 0 - temperature alarms disabled 1 - high temperature alarm 2 - low temperature alarm 3 - high and low temperature alarms enabled. | 0 | Yes | 1 | 0 | 3 | 0 | From | To | Description |
|---|
2 | 2 | low temperature alarm | 0 | 0 | temperature alarms disabled | 1 | 1 | high temperature alarm | 3 | 3 | high and low temperature alarms enabled |
|
55 | High temperature alarm threshold | If temperature is higher than set value, overheat notification will be sent and high temperature scene will be triggered (if activated). 1-600 (0.1-60C, 0.1C step) | 0 | Yes | 2 | 1 | 600 | 350 | From | To | Description |
|---|
1 | 600 | (0.1-60C, 0.1C step) |
|
56 | Low temperature alarm threshold | If temperature is lower than the set value, underheat notification will be sent and low temperature scene will be triggered (if activated). 0-599 (0-59.9C, 0.1C step) | 0 | Yes | 2 | 0 | 599 | 100 | From | To | Description |
|---|
0 | 599 | (0-59.9C, 0.1C step) |
|
2 | Visual LED indications | This parameter defines events indicated by the visual LED indicator. Disabling events might extend battery life. 1 - indication of opening-closing status change 2 - indication of wake up (1 x click or periodical) 4 - indication of device tampering NOTE Parameter 2 values may be combined, e.g. 1+2=3 means that in -dications for opening/ closing and waking up are enabled. | 0 | Yes | 1 | 0 | 7 | 6 | From | To | Description |
|---|
2 | 2 | indication of wake up (1 x click or periodical) | 4 | 4 | indication of device tampering | 1 | 1 | indication of opening-closing status change |
|
3 | Associations in Z-Wave network Security Mode | This parameter defines how commands are sent in specified association groups: as secure or non-secure. Parameter is active only in Z-Wave network Security Mode. It does not apply to 1st group Lifeline. 0 - none of the groups sent as secure 1 - 2nd group On-Off sent as secure 2 - 3rd group Tamper sent as secure 3 - 2nd and 3rd group sent as secure | 0 | Yes | 1 | 0 | 3 | 3 | From | To | Description |
|---|
0 | 0 | none of the groups sent as secure | 1 | 1 | 2nd group On-Off sent as secure | 2 | 2 | 3rd group Tamper sent as secure | 3 | 3 | 2nd and 3rd group sent as secure |
|
51 | Temperature reports threshold | This parameter defines the change of temperature in comparison with last reported, resulting in temperature report being sent to the main controller. 0 - temperature reports based on threshold disabled 1-300 - temperature threshold (0.1-30C, 0.1C step) NOTE Parameter 51 is active only if parameter 50 is not set to 0. Temperature measurement is performed before sending any report (regardless of parameter no. 50). Excessive reporting can affect battery lifetime. Reporting on the basis of temperature change (parameter no. 51) is recommended. | 0 | Yes | 2 | 0 | 300 | 10 | From | To | Description |
|---|
0 | 0 | temperature reports based on threshold disabled | 1 | 300 | temperature threshold (0.1-30C, 0.1C step) |
|
