2 | Acoustic and visual signals On / Off in case of flooding | The parameter allows for deactivation visual and acoustic alarm. Parameter allows for increasing a battery life. Setting changes will not affect the sensor’s communication with the main controller - commands to association groups, alarms and reports will still be sent. | 0 | 1 | 0 | 0 | 3 | From | To | Description |
|---|
1 | 1 | acoustic alarm inactive, visual alarm active | 2 | 2 | acoustic alarm active, visual alarm inactive | 3 | 3 | acoustic and visual alarms active | 0 | 0 | acoustic and visual alarms inactive |
|
7 | Requested dimming level / roller blind opening level when sending turn on / open command to 2nd association group devices | Determines the requested “on” level to be sent to devices from 2nd association group upon flood event. | 0 | 2 | 0 | 0 | 255 | From | To | Description |
|---|
1 | 99 | requested level | 255 | 255 | turn a device on |
|
1 | Alarm cancellation delay | Determines time period (in seconds) by which a Flood Sensor will retain the flood state after the flooding itself has ceased. The sensor will keep on reporting flooding to the main controller. This parameter setting does not affect acoustic and visual alarms, which turn off immediately after flooding ceases. | 0 | 2 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 3600 | in seconds, each 1s |
|
9 | Deactivate turning off devices in 2nd association group & alarm cancellation in 3rd group | This setting decides whether device turn off commands and alarm cancellation notifications will be sent to devices in 2nd and 3rd association groups (respectively) Setting the parameter’s value to 0 disables sending these two commands to associated devices. This means that these devices WILL NOT be informed when the flooding has ceased. It is still possible to cancel alarms in 3rd association group by choosing second (green) menu position (see “Menu & visual indications” on page 10). | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | alarm (flooding) cancellation inactive | 1 | 1 | alarm (flooding) cancellation active |
|
10 | Temperature measurement interval | Time interval (in seconds) between consecutive measurements of battery level and temperature (done by built-in temperature sensor). If the temperature differs from previously reported by a value determined in parameter 12, it will be reported to the Z-Wave controller. In battery mode more significant battery level changes will be reported. Short time intervals mean more frequent communication, which results in shortened battery life. After consecutive FAILED and SUCCESSFUL communication attempts, the Sensor will go to standby mode. | 0 | 4 | 0 | 0 | 300 | From | To | Description |
|---|
1 | 65535 | in seconds |
|
50 | Low temperature alarm threshold | The parameter stores a temperature value, below which visual indicator blinks with a colour determined by a parameter 61 settings. By default the visual indicator blinks blue. | 0 | 2 | 0 | 0 | 1500 | From | To | Description |
|---|
-10000 | 10000 | each 0.01°C |
|
51 | High temperature alarm threshold | The parameter stores a temperature value, above which visual indicator blinks with a colour determined by the parameter 62 settings. By default the visual indicator blinks red. | 0 | 2 | 0 | 0 | 3500 | From | To | Description |
|---|
-10000 | 10000 | each 0.01°C |
|
61 | Low temperature alarm indicator colour | Parameter stores RGB colour value (see the note below for details). | 0 | 4 | 0 | 0 | 255 | From | To | Description |
|---|
0 | 16777215 | Red 16711680; Green 65280; Blue 255; Yellow 16776960; Turquoise 65535; Orange 16750848; White 16777215; Indicator turned off 0 |
|
62 | High temperature alarm indicator colour | Parameter stores RGB colour value (see the note below for details). NOTE The main controller interprets colours as a sum of its component colours value. Each colours value is a number from 0 to 255. Indicated colour = 65536 RED + 256 GREEN + BLUE Colour Decimal value Red 16711680 Green 65280 Blue 255 Yellow 16776960 Turquoise 65535 Orange 16750848 White 16777215 Indicator turned off 0 | 0 | 4 | 0 | 0 | 16711680 | From | To | Description |
|---|
0 | 16777215 | Red 16711680; Green 65280; Blue 255; Yellow 16776960; Turquoise 65535; Orange 16750848; White 16777215; Indicator turned off 0 |
|
63 | Temperature indication using LED visual indicator | Parameter determines visual indicator’s operation. Setting to 0 turns the temperature LED indication off, saving battery life. | 0 | 1 | 0 | 0 | 2 | From | To | Description |
|---|
0 | 0 | visual indicator does not indicate the temperature | 1 | 1 | visual indicator indicates the temperature (blink) every Temperature Measurement Interval (parameter 10, constant current and battery) and Wake Up Interval (battery mode) | 2 | 2 | visual indicator indicates the temperature continuously, only in constant power mode |
|
73 | Temperature measurement compensation | Parameter stores a temperature value to be added to or deducted from the current temperature measured by internal temperature sensor in order to compensate the difference between air temperature and temperature at the floor level. | 0 | 2 | 0 | 0 | 0 | From | To | Description |
|---|
-10000 | 10000 | °C |
|
74 | Alarm frame sent to 1st and 4th Association Group activation | (MOVEMENT_TAMPER / BUTTON_TAMPER) The device is able to report tamper alarms resulting from sensor’s tilt/movement or TMP button state change (e.g. taking off the top cover). | 0 | 1 | 0 | 0 | 2 | From | To | Description |
|---|
0 | 0 | tamper alarms inactive | 1 | 1 | button tamper alarm active | 2 | 2 | movement tamper alarm active | 3 | 3 | button and movement tampers alarm active |
|
75 | Alarms signalization duration | The device is capable of automatically turning off alarm signalization after a certain amount of time. Long lasting alarm may reduce batter life, when constantly signalized. The parameter determines time after which alarm will become “quiet” - still active but the device will go into battery saving mode. Visual or acoustic alarm will be reactivated after time specified in the parameter 76. When alarm status ceases, alarm will be turned off immediately. NOTE Parameter 75 is ignored when parameter 2 is set to 0. | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | alarms active indefinitely | 1 | 65535 | time in seconds |
|
76 | Alarm signalization reactivation period | Parameter determines a time period after which an alarm will be turned back on (in case it was turned off by parameter 75 setting). It will also resend commands to 2nd and 3rd association groups as if the alarm was detected again. NOTE In case a time period set in parameter 76 is shorter than the one specified in parameter 75, the device will not quiet the alarm, it will remain active. | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | alarm reactivation inactive | 1 | 65535 | time in seconds |
|
77 | Flood sensor functionality turned off | Allows to turn off the internal flood sensor. Tamper and built in temperature sensor will remain active. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Default flood sensor operation (flood detection, reactions) | 1 | 1 | Built-in flood sensor TURNED OFF (does not change its state in the main controller, does not send alarm notifications nor turn on/off commands to 2nd/3rd association groups with flood state changes. Always visible in the main controller as turned off) |
|
78 | Associations in Z-Wave network security mode | This parameter defines how commands are sent in specified association groups: as secure or non-secure. Parameter is active only in Z-Wave network security mode. It does not apply to 1st “Lifeline “group. | 0 | 1 | 0 | 0 | 7 | From | To | Description |
|---|
0 | 0 | acoustic and visual alarms inactive | 0 | 0 | none of the groups sent as secure | 1 | 1 | 2nd group, Control, sent as secure | 1 | 1 | acoustic alarm inactive, visual alarm active | 2 | 2 | acoustic alarm active, visual alarm inactive | 2 | 2 | 3rd group, Alarm, sent as secure | 3 | 3 | acoustic and visual alarms active | 4 | 4 | 4th group, Tamper, sent as secure |
|
