| 8 | PIR SENSOR OPERATING MODE | The parameter determines the part of day in which the PIR sensor will be active. This parameter influences only the motion reports and associations. Tamper, light intensity and temperature measurements will be still active, regardless of this parameter settings. | 0 | 1 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 0 | PIR sensor always active | | 1 | 1 | PIR sensor active during the day only | | 2 | 2 | PIR sensor active during the night only |
|
| 9 | NIGHT / DAY | The parameter defines the difference between night and day, in terms of light intensity, used in parameter 8. | 0 | 2 | 0 | 0 | 200 | | From | To | Description |
|---|
| 1 | 32767 | lux |
|
| 24 | TAMPER OPERATING MODES | The parameter determines the behaviour of tamper alarm and how it reports. It is an advanced feature serving much more functions than just detection of tampering. | 0 | 1 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 0 | Only tamper (default). | | 2 | 2 | Tamper and orientation in space. Three reports are sent right after tamper alarm cancellation delay time. | | 1 | 1 | Tamper and earthquake detector. Function may be used as a simple seismograph. Two reports including the strength of shock are always sent. First, right after the detection and second (value=0) after tamper alarm cancellation delay time. |
|
| 3 | PIR sensor’s “PULSE COUNTER” | Sets the number of moves required for the PIR sensor to report motion. The higher the value, the less sensitive the PIR sensor. It’s not recommended to modify this parameter settings. | 0 | 1 | 0 | 0 | 1 | | From | To | Description |
|---|
| 0 | 3 | 1 - 4 pulses. Formula to calculate the number of pulses: pulses = (value + 1). |
|
| 25 | TAMPER CANCELLATION REPORTS | | 0 | 1 | 0 | 0 | 1 | | From | To | Description |
|---|
| 0 | 0 | Do not send tamper cancellation report. | | 1 | 1 | Send tamper cancellation report. |
|
| 4 | PIR sensor’s “WINDOW TIME” | Period of time during which the number of moves set in parameter 3 must be detected in order for the PIR sensor to report motion. The higher the value, the more sensitive the PIR sensor. It’s not recommended to modify this parameter setting. | 0 | 1 | 0 | 0 | 2 | | From | To | Description |
|---|
| 0 | 3 | Formula to calculate the time: time [s] = 4 x (value + 1). |
|
| 82 | AMBIENT ILLUMINATION LEVEL BELOW WHICH LED BRIGHTNESS IS SET TO 1% | The parameter is relevant only when the parameter 81 is set to 0. | 0 | 2 | 0 | 0 | 100 | | From | To | Description |
|---|
| 0 | 32767 | lux |
|
| 83 | AMBIENT ILLUMINATION LEVEL ABOVE WHICH LED BRIGHTNESS IS SET TO 100% | The parameter is relevant only when the parameter 81 is set to 0. Available settings: CAUTION: The value of parameter 83 must be higher than the value of parameter 82. | 0 | 2 | 0 | 0 | 1000 | | From | To | Description |
|---|
| 1 | 32767 | Parameter 82 value to 32767 (1-32767 lux). |
|
| 89 | LED INDICATING TAMPER ALARM | Indicating mode resembles a police car (white, red and blue). | 0 | 1 | 0 | 0 | 1 | | From | To | Description |
|---|
| 0 | 0 | LED does not indicate tamper alarm. | | 1 | 1 | LED indicates tamper alarm. |
|
| 40 | ILLUMINATION REPORT THRESHOLD | The parameter determines the change in light intensity level resulting in illumination report being sent to the main controller. | 0 | 2 | 0 | 0 | 200 | | From | To | Description |
|---|
| 0 | 0 | Reports are not sent. | | 1 | 32767 | lux |
|
| 42 | ILLUMINATION REPORTS INTERVAL | Time interval between consecutive illumination reports. The reports are sent even if there are no changes in the light intensity. CAUTION: Frequent reports will shorten the battery life. Parameter value under 5 may result in blocking the temperature reports. | 0 | 2 | 0 | 0 | 3600 | | From | To | Description |
|---|
| 1 | 32767 | seconds | | 0 | 0 | no reports |
|
| 60 | TEMPERATURE REPORT THRESHOLD | The parameter determines the change in level of temperature resulting in temperature report being sent to the main controller. | 0 | 2 | 0 | 0 | 10 | | From | To | Description |
|---|
| 1 | 255 | 0,1-25,5 degrees Celsius | | 0 | 0 | reports are not sent |
|
| 62 | INTERVAL OF TEMPERATURE MEASURING | The parameter determines how often the temperature will be measured. The shorter the time, the more frequently the temperature will be measured, but the battery life will shorten. CAUTION: When parameter value is set to 0, the temperature measurements may be performed at the device wake-up. | 0 | 2 | 0 | 0 | 900 | | From | To | Description |
|---|
| 1 | 32767 | seconds | | 0 | 0 | temperature will not be measured |
|
| 64 | TEMPERATURE REPORTS INTERVAL | The parameter determines how often the temperature reports will be sent to the main controller. CAUTION: Frequent reports will shorten the battery life. Parameter value under 5 may result in blocking the illumination reports. | 0 | 2 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 0 | no reports | | 1 | 32767 | seconds |
|
| 66 | TEMPERATURE OFFSET | The value to be added to the actual temperature, measured by the sensor (temperature compensation). | 0 | 2 | 0 | 0 | 0 | | From | To | Description |
|---|
| -1000 | 1000 | degrees Celsius |
|
| 81 | LED BRIGHTNESS | The parameter determines the brightness of LED when indicating motion. | 0 | 1 | 0 | 0 | 50 | | From | To | Description |
|---|
| 1 | 100 | % | | 0 | 0 | Brightness determined by the ambient lighting - see parameters 82 and 83. |
|
