Name	Garage Door Controller Gen5
Short Description	Aeon Labs Garage Door Controller is a smart and wireless Garage Door Control system, you can control the garage door to open, close, or stop moving via wireless signal on your gateway client or phone application.
Long Description	Aeon Labs Garage Door Controller is a smart and wireless Garage Door Control system, you can control the garage door to open, close, or stop moving via wireless signal on your gateway client or phone application. The Garage Door Controller allows you to configure different alarm sounds to indicate the door’s action. Each action alarm sound can be customized. To change or update new alarm sounds for the Garage Door Controller, connect the Garage Door Controller to your PC host with a USB cable and download your sound files to the flash memory (128 MB) of the Garage Door Controller. It can be included and operated in any Z-Wave network with other Z-Wave certified devices from other manufacturers and/or other applications. All non-battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network. It is also a security Z-Wave device and supports the Over The Air (OTA) feature for the product’s firmware upgrade.
Brand	Aeotec
Product Identifier	ZW062-A
OEM Version	HW: 62 FW: 1.11
Hardware Platform	ZM5101
Z-Wave Version	6.51.06
Library Type	SLAVE_ENHANCED_232
Device Type	Secure Barrier Add-On
Role Type	ROLE_TYPE_SLAVE_ALWAYS_ON
Manufacturer ID	0x0086
Product Type ID	0x0103
Product ID	0x003E
Frequency Plans	US: 916.00MHz, 908.40MHz
Categories	Motor Control
Countries / Regions	United States of America
Controlled Command Classes	Identifier Name Key Version COMMAND_CLASS_SWITCH_BINARY Switch Binary 0x25 1 COMMAND_CLASS_BASIC Basic 0x20 1 COMMAND_CLASS_HAIL Hail 0x82 1
Documents	Category Description File Manual_Primary_Lang Product or Owner's Manual Aeon Labs Garage Door Controller Gen5 manual.pdf
Association Groups	Group Number Maximum Nodes Supported End Point ID Description 2 5 0 When the Garage Door Controller receives the Basic Set, Switch Binary Set,commands from main controller. it will forward the Basic Set, Switch Binary Set to associated nodes in Group 2. 1 5 0 Group 1 is assigned to the Lifeline association group and every device has 5 nodes to associate. When the Garage Door controller is received the commands sent by controller to be turned on or off, the Garage Door controller will send a basic report of its status to the nodes in association group 1. To change what kind of signal is sent to the nodes in group 1, please see the detailed description of configuration parameter 80.
Configuration Parameters	Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 241 Pair the Sensor with Garage Door Controller This parameter is used to pair the Sensor with Garage Door Controller. Note: 1. This procedure should only be used when the complimentary Sensor is missing or inoperable and you have another new Sensor that would be paired with your Garage Door Controller. 2. When the pairing is started, the Network LED will blink slowly, at this time, you just need to press the Temper Switch back of the Sensor once. If the Network LED change to be solid, which means the pairing is successful. Otherwise, repeat the steps. 0 4 0 0 0 From To Description 1431655681 1431655681 Start the Sensor pairing mode. 252 Enable/Disable Lock Configuration This parameter is used to enable/disable Lock all configuration parameters. (0 =disable, 1 = enable) 0 1 0 0 0 From To Description 0 0 All configuration parameters are configurable. 1 1 All configuration parameters are not configurable (Locked). 255 Reset to default factory setting This parameter is used to reset product to default factory setting. (There are just 2 values can be used). 0 4 0 0 0 From To Description 1 1 Reset all configuration parameters to default setting. 1431655765 1431655765 Reset the product to default factory setting and be excluded from the Z-wave network. 40 Configure the alarm mode when the garage door is in closed position. This parameter is used to set the alarm mode when the garage door is in closed position. 0 4 0 0 525314 From To Description 16777216 16777216 Enable the alarm mode. 1 10 Configure the flash frequency of the alarm LED, there are 10 levels can be set. 256 356 Select an alarm sound, there are 4 alarm sounds in the flash memory card can be selected. 65535 65545 Configure the volume of alarm sound, there are 10 levels can be set. 16777215 16777215 Disable the alarm mode. 80 Enable/Disable to send notifications to associated devices to associated devices. This parameter is used to enable/disable to send notifications to associated devices (in Group 1) when the state of Doorbell Gen5’s load is changed. (0=Send nothing, 1=Send hail CC, 2=Send barrier operator report CC). 0 1 0 0 2 From To Description 2 2 Send BARRIER OPERATOR Report Command 0 0 Send Nothing (Disabled) 1 1 Send HAIL Command 43 Start playing or Stop playing the ringtone. This parameter is used to audition or test the product's ringtone. 0 1 0 0 0 From To Description -1 -1 Stop playing the ringtone. 1 100 Start playing the ringtone that you select. 44 Test the volume of the current ringtone This parameter is used to audition or test the product's ringtone volume. 0 1 0 0 0 From To Description 1 10 There are 10 volume levels can be set for testing. 45 Get the environment temperature This parameter is used to get the temperature where near to your Garage Door Controller. 0 2 0 0 0 From To Description 0 500 The available temperature range is 0 to 50 Celsius 47 Define the function of Button- and Button+. This parameter is used to define the function of Button- and Button+. 0 1 0 0 0 From To Description 1 1 Pressing it once, the Button+ and Button- are defined to be the control item of Next and Previous. Press and hold it, the Button+ and Button- are defined to be used to increase and decrease the volume. 0 0 Pressing it once, the Button+ and Button- are defined to be used to increase and decrease the volume. Press and hold it, the Button+ and Button- are defined to be the control item of Next and Previous.
Texts	ID Description Value 1 Inclusion Turn the primary controller of Z-Wave network into inclusion mode, short press the product’s Z-Wave button that you can find on the product's housing. 2 Exclusion Turn the primary controller of Z-Wave network into exclusion mode, short press the product’s Z-Wave button that you can find on the product's housing. 5 Factory Reset Press and hold the Z-Wave button that you can find on the product's housing for 20 seconds and then release. This procedure should only be used when the primary controller is missing or inoperable. 6 Additional Special Features 1. Support ""Over the Air Firmware Updating"" and “Z-Wave Security”. 2. Support alarm sound updating.
Supports NWI	Yes
Supports Explorer Frames	Yes
