Product Recognition
Certification Number	ZC10-17085731
Name	Garage Door Controller Gen5
Short Description	Aeon Labs Garage Door Controller is a smart and wireless Garage Door Control system, you can control the garage door to open, close, or stop moving via wireless signal on your gateway client or phone application.
Long Description	Aeon Labs Garage Door Controller is a smart and wireless Garage Door Control system, you can control the garage door to open, close, or stop moving via wireless signal on your gateway client or phone application. The Garage Door Controller allows you to configure different alarm sounds to indicate the door’s action. Each action alarm sound can be customized. To change or update new alarm sounds for the Garage Door Controller, connect the Garage Door Controller to your PC host with a USB cable and download your sound files to the flash memory (128 MB) of the Garage Door Controller. It can be included and operated in any Z-Wave network with other Z-Wave certified devices from other manufacturers and/or other applications. All non-battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network. It is also a security Z-Wave device and supports the Over The Air (OTA) feature for the product’s firmware upgrade.
Brand	Aeotec
Product Identifier	ZW062-A
OEM Version	HW: 62 FW: 11.11
Hardware Platform	ZM5101
Z-Wave Version	6.51.06
Library Type	SLAVE_ENHANCED_232
Device Type	Barrier Operator
Role Type	ROLE_TYPE_SLAVE_ALWAYS_ON
Manufacturer ID	0x012A
Product Type ID	0x0103
Product ID	0x003E
User Icon	0x1E00
Installer Icon	0x1E00
Frequency Plans	US: 916.00MHz, 908.40MHz
Categories	Motor Control
Countries / Regions	United States of America
Supported Command Classes	Identifier Name Key Version COMMAND_CLASS_POWERLEVEL Powerlevel 0x73 1 COMMAND_CLASS_APPLICATION_STATUS Application Status 0x22 1 COMMAND_CLASS_SWITCH_BINARY Switch Binary 0x25 1 COMMAND_CLASS_BASIC Basic 0x20 1 COMMAND_CLASS_CONFIGURATION Configuration 0x70 1 COMMAND_CLASS_SECURITY Security S0 0x98 1 COMMAND_CLASS_VERSION_V2 Version V2 0x86 2 COMMAND_CLASS_DEVICE_RESET_LOCALLY Device Reset Locally 0x5A 1 COMMAND_CLASS_ZWAVEPLUS_INFO_V2 Z-Wave Plus Info V2 0x5E 2 COMMAND_CLASS_BARRIER_OPERATOR Barrier Operator 0x66 1 COMMAND_CLASS_ASSOCIATION_V2 Association V2 0x85 2 COMMAND_CLASS_ASSOCIATION_GRP_INFO Association Group Info 0x59 1 COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2 Firmware Update Meta-Data V2 0x7A 2 COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2 Manufacturer Specific V2 0x72 2 COMMAND_CLASS_NOTIFICATION_V4 Notification V4 0x71 4
Controlled Command Classes	Identifier Name Key Version COMMAND_CLASS_SWITCH_BINARY Switch Binary 0x25 1 COMMAND_CLASS_BASIC Basic 0x20 1 COMMAND_CLASS_HAIL Hail 0x82 1
Documents	Category Description File Manual_Primary_Lang Product or Owner's Manual Garage Door Controller manual.pdf
Features	Feature Values Firmware Updatable Value Updatable by Consumer by RF Supported Notification Types Value Access Control
Association Groups	Group Number Maximum Nodes Supported End Point ID Description 1 5 0 Z-Wave Plus Lifeline The Hail CC, Barrier operator report CC can be sent to the associated nodes in this group. 2 5 0 Forward the Basic Set, Switch Binary Set commands to associated nodes in Group 2 when the Garage Door Controller receives the Basic Set, Switch Binary Set commands from the main controller.
Configuration Parameters	Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 44 Test the volume of the current ringtone Test the volume of the current ringtone 0 1 0 0 0 From To Description 1 10 the volume level 1 to level 10. 45 Get the environment temperature Get the environment temperature 0 2 0 0 0 From To Description 0 500 Rang is 0 to 500 (0℃ to 50.0℃). 47 Define the function of Button- or Button+ Define the function of Button- or Button+ 0 1 0 0 0 From To Description 0 0 short pressing the “Button +/-” will be used to adjust the volume of sound. Long pressing the “Button +/-” will be used to switch the sound to the next. 1 1 short pressing the “Button +/-” will be used to switch the sound to the next. Long pressing the “Button +/-” will be used to adjust the volume of sound 80 It will send the Hail CC/configuration report CC when the state of garage door is changed It will send the Hail CC/configuration report CC when the state of garage door is changed 0 1 0 0 2 From To Description 1 1 send Hail CC 2 2 send Barrier operator report CC 241 Pair the Sensor with Garage Door Controller Pair the Sensor with Garage Door Controller 0 4 0 0 0 From To Description 1431655681 1431655681 trigger to start the pairing of Sensor 252 Enable/disable to lock the configuration parameters. Enable/disable to lock the configuration parameters. 0 1 0 0 0 From To Description 0 0 Disable 1 1 Enable 43 Start playing or Stop playing the ringtone Start playing or Stop playing the ringtone 0 1 0 0 0 From To Description 1 100 start playing the ringtone that you selected. -1 -1 stop playing ringtone 255 Reset rhe Garage Door Controller Reset rhe Garage Door Controller 0 4 0 0 0 From To Description 1 1 Reset all configuration parameters to factory default settings 1431655765 1431655765 Reset the device to factory default and excluded from the network
Texts	ID Description Value 2 Exclusion Turn the primary controller of Z-Wave network into exclusion mode, short press the product’s Z-Wave button that you can find on the product's housing. 1 Inclusion Turn the primary controller of Z-Wave network into inclusion mode, short press the product’s Z-Wave button that you can find on the product's housing. 6 Additional Special Features 1. Support ""Over the Air Firmware Updating"" and “Z-Wave Security”. 2. Support alarm sound updating. 5 Factory Reset Press and hold the Z-Wave button that you can find on the product's housing for 20 seconds and then release. This procedure should only be used when the primary controller is missing or inoperable.
Supported Notification Types	Notification Type Event / State Access Control (Refer to parameters): State idle
Supports NWI	Yes
Supports Explorer Frames	Yes
