COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3

Multi-Channel Association V3

0x8E

3

COMMAND_CLASS_BATTERY

Battery

0x80

1

COMMAND_CLASS_CONFIGURATION

Configuration

0x70

1

COMMAND_CLASS_CRC_16_ENCAP

CRC16 Encapsulation

0x56

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_WAKE_UP_V2

Wake Up V2

0x84

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_CENTRAL_SCENE_V2

Central Scene V2

0x5B

2

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V3

Firmware Update Meta-Data V3

0x7A

3

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_CRC_16_ENCAP

CRC16 Encapsulation

0x56

1

COMMAND_CLASS_CENTRAL_SCENE_V2

Central Scene V2

0x5B

2

Manual_Primary_Lang

Product or Owner's Manual

Battery Quantity

Battery Type

Color

2

5

0

“Flick UP” is assigned to moving the hand up over the panel (sends Basic Set command frames).

3

5

0

“Flick DOWN” is assigned to moving the hand down over the panel (sends Basic Set command frames).

4

5

0

“Flick LEFT” is assigned to moving the hand from the right to the left side of the panel (sends Basic Set command frames).

1

1

0

“Lifeline” reports the device status and allows for assigning single device only (main controller by default).

5

5

0

“Flick RIGHT” is assigned to moving the hand from the left to the right side of the panel (sends Basic Set command frames) .

6

5

0

“Circular AirWheel” is assigned to circular move of the hand clockwise or counter-clockwise over the panel (sends Switch Multilevel Start/Stop Level Change command frames).

2

Buzzer - acoustic signal settings

Buzzer - acoustic signal settings. NOTE Active acoustic signals can be selected in parameter 4.

0

1

0

0

1

3

LED diode - visual indicator settings

Visual indication of gestures detection.

0

1

0

0

0

4

Buzzer - signalling result of gesture recognition

Acoustic signalling of gesture recognition result (using the built-in buzzer). NOTE Parameter 4 is relevant only if parameter 2 is set to 1.

0

1

0

0

3

5

Powering mode - interval of updating the current mode

This parameter determines how often the device checks if the USB power supply is connected and updates powering mode if needed.

0

2

0

0

4

7

Hold gesture to enter the menu

This parameter allows to choose if the menu can be entered using the Hold gesture. CAUTION After disabling the Hold gesture in parameter 7, menu can be entered by using the B-button only!

0

1

0

0

0

1

Device orientation

Parameter determines orientation of the Swipe in relation to its default position. Required for proper gestures recognition.

0

1

0

0

0

6

Power saving mode (battery mode)

This parameter determines operation of gesture detection when battery powered. When Standby Mode is selected, hold gesture must be performed to exit power saving mode and reactivate normal gesture recognition. The device in Standby Mode consumes the least battery life. When Simple Mode mode is selected, gesture recognition is always active, but only slowly performed gestures will be recognized properly (high battery consumption).

0

1

0

0

0

23

SWITCH OFF control frame value for FLICK DOWN gesture

This parameter allows to set value sent in SWITCH OFF command frame to the association group.

0

2

0

0

0

24

SWITCH ON control frame value for FLICK LEFT gesture

This parameter allows to set value sent in SWITCH ON command frame to the association group.

0

2

0

0

255

25

SWITCH OFF control frame value for FLICK LEFT gesture

This parameter allows to set value sent in SWITCH OFF command frame to the association group.

0

2

0

0

0

31

1st gestures sequence (SLOT 1)

Value containing sequence of gestures. See "Sequences of gestures" on page 12 for more information. NOTE Parameters 31-36 can also be used to manually set a sequence according to details described in "Sequences of gestures" on page 12.

0

2

0

0

0

1

Inclusion

1) Place the Swipe within the direct range of your Z-Wave controller. 2) Set the main controller in (security/non-security) add mode (see the controller’s manual). 3) Move and hold your hand close to the centre of the pad. 4) If the device is battery powered, high pitched beep will signal exiting the Standby Mode. 5) Loud sound sequence will confirm entering the menu, keep holding your hand. 6) After hearing two short beeps, withdraw the hand and perform swiping up gesture to confirm selection (two beeps will confirm validity). 7) Wait for the adding process to end. 8) Successful adding will be confirmed by the Z-Wave controller’s message and 3 short beeps.

2

Exclusion

1) Place the Swipe within the direct range of your Z-Wave controller. 2) Set the main controller in remove mode (see the controller’s manual). 3) Move and hold your hand close to the centre of the pad. 4) If the device is battery powered, high pitched beep will signal exiting the Standby Mode. 5) Loud sound sequence will confirm entering the menu, keep holding your hand. 6) After hearing two short beeps (green indicator colour), withdraw the hand and perform swiping up gesture to confirm selection (two beeps will confirm validity). 7) Wait for the removing process to end. 8) Successful removing will be confirmed by the Z-Wave controller’s message and sequence of 2 short beeps, pause, 1 short beep.

5

Factory Reset

Reset procedure allows to restore the device back to its factory settings, which means all information about the Z-Wave controller and user configuration will be deleted. In order to reset the device: 1) Make sure the device is powered. 2) Move and hold your hand close to the center of the pad. 3) Loud sound sequence will confirm entering the menu, keep holding your hand. 4) Wait for the buzzer to indicate the 3rd menu position (3 short beeps) 5) Withdraw the hand and perform swiping up gesture to confirm selection (two beeps will confirm validity). Please use this procedure only when the network primary controller is missing or otherwise inoperable.

4

Device Wake-Up

The Swipe needs to be woken up to receive information about the new configuration from the Z-Wave controller, like parameters and associations. Use 1st menu position to wake up the device or click the button on the back of the device once. 1) Move and hold your hand close to the center of the pad. 2) Loud sound sequence will confirm entering the menu, keep holding your hand. 3) Wait for the buzzer to indicate the 1st menu position (1 short beep) 4) Withdraw the hand and perform swiping up gesture to confirm selection (two beeps will confirm validity).
