Product Recognition | |
|---|
Certification Number | ZC10-20127003 |
|---|
Name | Heatit Z-Smoke Battery |
|---|
Short Description | The Heatit Z-Smoke Detector is a multifunctional wireless smoke
sensor for smart home systems. With its powerful features, the
sensor is designed to protect the family from potential fire
hazards. With its compact and streamlined design, the Heatit
Z-Smoke Detector blends effortlessly with your home decor and
gives you extra security. |
|---|
Long Description | The Heatit Z-Smoke Detector is a multifunctional wireless smoke
sensor for smart home systems. With its powerful features, the
sensor is designed to protect the family from potential fire
hazards. With its compact and streamlined design, the Heatit
Z-Smoke Detector blends effortlessly with your home decor and
gives you extra security.
The Heatit Z-Smoke Detector is designed to provide the
sensor with more features and capabilities. Therefore, you can
use optional additional features such as a built-in PIR motion
sensor, heat sensor and/or emergency lighting. Heatit Z-Smoke
Detector has a built-in PIR motion sensor. You can choose to use
it to create custom scenes to light up the hallway in the middle
of the night or help users save energy. The built-in emergency
light can also be set up to provide visual alarms and alerts.
The Heatit Z-Smoke Detector uses a cutting-edge reflective
photoelectric sensor in conjunction with an advanced
microprocessor to deliver optimum performance by detecting
developing fires and heat generation. When it comes to security,
there is no room for compromise. |
|---|
Brand | Heatit controls |
|---|
Product Identifier | 4512688 |
|---|
Product Line | Security |
|---|
OEM Version | HW: 255 FW: 4.01 |
|---|
Hardware Platform | ZM5202 |
|---|
Z-Wave Version | 6.81.06 |
|---|
Library Type | SLAVE_ENHANCED_232 |
|---|
Device Type | Notification Sensor |
|---|
Role Type | ROLE_TYPE_SLAVE_SLEEPING_LISTENING |
|---|
Manufacturer ID | 0x019B |
|---|
Product Type ID | 0x0003 |
|---|
Product ID | 0x3602 |
|---|
User Icon | 0x0C01 |
|---|
Installer Icon | 0x0C01 |
|---|
Frequency Plans | EU: 869.85MHz, 868.40MHz |
|---|
Categories | Sensors, Security Systems |
|---|
Countries / Regions | European Union |
|---|
Supported Command Classes | Identifier | Name | Key | Version |
|---|
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4 | Firmware Update Meta-Data V4 | 0x7A | 4 | COMMAND_CLASS_POWERLEVEL | Powerlevel | 0x73 | 1 | COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3 | Multi-Channel Association V3 | 0x8E | 3 | COMMAND_CLASS_BATTERY | Battery | 0x80 | 1 | COMMAND_CLASS_TRANSPORT_SERVICE_V2 | Transport Service V2 | 0x55 | 2 | COMMAND_CLASS_DEVICE_RESET_LOCALLY | Device Reset Locally | 0x5A | 1 | COMMAND_CLASS_ZWAVEPLUS_INFO_V2 | Z-Wave Plus Info V2 | 0x5E | 2 | COMMAND_CLASS_ASSOCIATION_V2 | Association V2 | 0x85 | 2 | COMMAND_CLASS_ASSOCIATION_GRP_INFO | Association Group Info | 0x59 | 1 | COMMAND_CLASS_NOTIFICATION_V8 | Notification V8 | 0x71 | 8 | COMMAND_CLASS_SECURITY_2 | Security S2 | 0x9F | 1 | COMMAND_CLASS_SENSOR_MULTILEVEL_V11 | Sensor Multilevel V11 | 0x31 | 11 | COMMAND_CLASS_VERSION_V3 | Version V3 | 0x86 | 3 | COMMAND_CLASS_SUPERVISION | Supervision | 0x6C | 1 | COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2 | Manufacturer Specific V2 | 0x72 | 2 |
|
|---|
Controlled Command Classes | Identifier | Name | Key | Version |
|---|
COMMAND_CLASS_BASIC_V2 | Basic V2 | 0x20 | 2 |
|
|---|
S2 Classes | S2_UNAUTHENTICATED |
|---|
Documents | Category | Description | File |
|---|
Manual_Primary_Lang | Product Manual | |
|
|---|
Features | Feature | Values |
|---|
Battery Quantity | | Battery Type | | Firmware Updatable | Value |
|---|
Updatable by Consumer by RF |
|
|
|---|
Association Groups | Group Number | Maximum Nodes Supported | End Point ID | Group Name | Profile | Description |
|---|
1 | 1 | 0 | Lifeline | 0x0000 | (Lifeline) Battery CC (COMMAND_CLASS_BATTERY)
Notification CC,V4 (COMMAND_CLASS_NOTIFICATION)
SensorMutilevel CC, V4 (COMMAND_CLASS_SENSOR_MULTILEVEL)
Device Reset Locally CC (COMMAND_CLASS_DEVICE_RESET_LOCALLY) | 2 | 1 | 0 | Smoke Basic set | 0x0000 | 1.When the Smoke Detector is active, it will send Basic Set (0xFF) in Group 2.
2.When the Smoke Detector is restored, it will send Basic Set (0x00) in Group 2. |
|
|---|
Texts | ID | Description | Value |
|---|
1 | Classic Inclusion | 1. Put the Z-Wave gateway or control panel into Inclusion or Learning mode (please refer to the Z-Wave gateway or control panel manual).
2. Within 1.5 seconds, press the Function button 3 times. The Smoke Detector will emit a 2-tone beep and the LED will turn on for ~2 seconds. Refer to the operation manual of the Z-Wave gateway or control panel to complete the learn-in process. | 2 | Classic Exclusion | 1. Put the Z-Wave gateway or control panel into Exclusion mode (please refer to the Z-Wave gateway or control panel manual).
2. Within 1.5 seconds, press the Function button 3 times and the Smoke Detector will be removed from the Z-Wave network. | 5 | Factory Reset Procedure | (Only use factory reset when network Control Panel/Gateway is missing or inoperable).
Press and hold the button of the smoke detector for 20 seconds. Release the button when you hear 3 beeps to perform factory reset. | 4 | Wake-Up Procedure | Role Type : Slave Sleeping Listening |
|
|---|
Supported Notification Types | Notification Type | Event / State |
|---|
Smoke Alarm | Sensor status: Smoke detected | Smoke Alarm | Alarm status: Alarm silenced | Heat Alarm | Heat sensor status: Overheat detected | Heat Alarm | Alarm status: Alarm silenced | Home Security | Cover status: Tampering, product cover removed | Home Security | Motion sensor status: Motion detection |
|
|---|
Supported Multilevel Sensors | Multilevel Sensor Type |
|---|
Air temperature |
|
|---|
Supports NWI | Yes |
|---|
Supports Explorer Frames | Yes |
|---|
Is Flirs | Yes |
|---|
Radio Range Z-Wave (m) | 40 |
|---|
