Product Recognition | |
|---|---|
Certification Number | ZC12-20050065 |
Name | Heatit Z-Temp2 |
Short Description | Heatit Z-Temp2 is a Z-Wave battery-operated thermostat for controlling external relays. |
Long Description | Heatit Z-Temp2 is a battery-operated thermostat designed for use
with water based heating systems. Used in combination with the
Heatit Z-Water regulator you can control your heating system with a
Z-Wave primary controller/gateway with the use of Heatit Z-Water in
combination with one or several Heatit Z-Temp2. |
Brand | Heatit controls |
Product Identifier | Z-Temp2 |
Product Line | Thermostat |
OEM Version | HW: 1 FW: 1.01:00.02 |
Hardware Platform | EFR32Z |
Z-Wave Version | 7.11.1 |
Library Type | SLAVE_ENHANCED_232 |
Device Type | Thermostat - HVAC |
Role Type | ROLE_TYPE_SLAVE_SLEEPING_LISTENING |
Manufacturer ID | 0x019B |
Product Type ID | 0x0004 |
Product ID | 0x0204 |
User Icon | 0x1200 |
Installer Icon | 0x1200 |
Frequency Plans | EU: 869.85MHz, 868.40MHz |
Categories | Thermostats |
Countries / Regions | European Union |
Supported Command Classes | |
S2 Classes | S2_UNAUTHENTICATED, S2_AUTHENTICATED |
Documents | |
Features | |
Association Groups | |
Configuration Parameters | |
Texts | |
Supported Notification Types | |
Supported Multilevel Sensors | |
Supports NWI | Yes |
Supports Explorer Frames | Yes |
Is Flirs | Yes |
Supports SmartStart | Yes |
Radio Range Z-Wave (m) | 40 |
