Product Recognition
Certification Number	ZC10-16055073
Name	Homey
Short Description	Homey is a universal, voice controlled Smart Home controller. It uses 8 different technologies, including Z-Wave, to create a single system out of a multitude of different devices.
Long Description	Homey gets technology out of the way, so when you’re at home you can focus on the things that matter most to you. Switches and remotes aren’t always the best way to control the things around you, so Homey simply listens to your voice. No more pushing buttons or searching through apps. Just say what you want, sit back and let Homey do the work for you. Stay in control and automate everything at home by creating scenarios that join your favorite devices and services together. Homey isn’t just futuristic, but also future proof. Like a smartphone, apps can be downloaded to extend Homey’s functionality to always keep up with new devices and functionalities. Visit www.talkswithhomey.com for an up-to-date overview of supported devices. Monitor and control your home on the go with the Homey app for your smartphone. Know what is going on and keep control of your home, anywhere in the world. All outside connections to Homey are encrypted and secured, and only you decide who has access. Your data is only for you to see because, well, it’s your data.
Brand	Athom
Product Identifier	Homey
OEM Version	HW: 1 FW: 4.05:04.26
Hardware Platform	ZM5304
Z-Wave Version	6.51.06
Library Type	CONTROLLER_STATIC
Device Type	Central Controller
Role Type	ROLE_TYPE_CONTROLLER_CENTRAL_STATIC
Manufacturer ID	0x0244
Product Type ID	0xBA5E
Product ID	0x0001
User Icon	0x0100
Installer Icon	0x0100
Frequency Plans	EU: 869.85MHz, 868.40MHz
Categories	All Controllers, Gateway Controller
Countries / Regions	European Union
Controlled Command Classes	Identifier Name Key Version COMMAND_CLASS_ASSOCIATION_GROUP_INFORMATION_V2 Association Group Information V2 0x59 0 COMMAND_CLASS_SENSOR_MULTILEVEL_V8 Sensor Multilevel V8 0x31 8 COMMAND_CLASS_SWITCH_BINARY_V2 Switch Binary V2 0x25 2 COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3 Multi-Channel Association V3 0x8E 3 COMMAND_CLASS_BATTERY Battery 0x80 1 COMMAND_CLASS_BASIC Basic 0x20 1 COMMAND_CLASS_CONFIGURATION Configuration 0x70 1 COMMAND_CLASS_CRC_16_ENCAP CRC16 Encapsulation 0x56 1 COMMAND_CLASS_SECURITY Security S0 0x98 1 COMMAND_CLASS_VERSION_V2 Version V2 0x86 2 COMMAND_CLASS_WAKE_UP_V2 Wake Up V2 0x84 2 COMMAND_CLASS_ZWAVEPLUS_INFO_V2 Z-Wave Plus Info V2 0x5E 2 COMMAND_CLASS_ASSOCIATION_V2 Association V2 0x85 2 COMMAND_CLASS_MULTI_CHANNEL_V4 Multi-Channel V4 0x60 4 COMMAND_CLASS_METER Meter 0x32 1 COMMAND_CLASS_MANUFACTURER_SPECIFIC Manufacturer Specific 0x72 1
Documents	Category Description File Manual_Primary_Lang Product or Owner's Manual athomhomeymanualzwave.docx
Association Groups	Group Number Maximum Nodes Supported End Point ID Description 1 5 0 Z-Wave Plus Lifeline
Texts	ID Description Value 23 Controller Inclusion To add a device to Homey, press the large ‘+’ in a dotted field. If applicable, you can first move to the relevant room on the left side of the screen. After pressing the plus, follow the on-screen instructions: 1) Choose which device you want to add, 2) Execute 24 Controller Exclusion A device can be removed from the Z-Wave settings page. Navigate to Settings (via my.athom.com) and select 'Z-Wave’. Then, click the ‘Remove node’ button under ‘Network’ and follow the on-screen instructions. 5 Factory Reset To Reset Homey to factory defaults, place Homey upside down. After a few seconds, Homey will initiate a countdown (both visually in the LED ring and verbally trough voice) of 15 seconds. After the countdown had ended, browse on a computer, laptop or tablet to setup.athom.com to initiate a new setup. PLEASE USE THE RESET PROCEDURE ONLY IF YOU EXPERIENCE SEVERE DIFFICULTIES WITH HOMEY'S OPERATING SYSTEM OR WHEN ADVISED TO DO SO BY ATHOM SUPPORT. 6 Additional Special Features Homey Does not only include Z-Wave, but also many other technologies, making you able to combine Z-Wave devices with many other wireless and smart devices. This way, they can interact with each other in scenarios, are controllable from a single smartphone app, and can be controlled by voice through Homey! 3 Learn Mode (adding another controller) To add Homey to your current Z-Wave network, start a controller shift on your current controller, navigate to Settings (via my.athom.com) and select 'Z-Wave’. Then, click the ‘Inclusion’ button under ‘Advanced Network Settings’ when prompted by the controller initializing. This will put Homey in learn mode.
Supports NWI	Yes
Supports Explorer Frames	Yes
