4 | Door lock audio volume | Setting for audio volume of notifications on door lock operations. This is a set only parameter, if changed locally this config parameter does not change. | 0 | 1 | 0 | 0 | 5 | From | To | Description |
|---|
0 | 6 | Sound volume level 0 to 6 |
|
1 | Door lock and away mode | Away mode off or on Auto or Manual Lock mode In auto Lock mode the door Locks Three Seconds after closing the door. In manual Lock mode the door Locks when pressing O/C button or activating touchpanel. When away mode is on the inside O/C button is deactivated. | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | Away mode off - Manual lock mode | 1 | 1 | Away mode off - Auto lock mode | 2 | 2 | Away mode on - Manual lock mode | 3 | 3 | Away mode on - Auto lock mode |
|
3 | Hinge direction (Right or Left) | Direction of hinges on door. To find your correct settings look at the mounted door lock outside. If the door hinges are on the right side of the door correct setting is "Right". If the door hinges are on the left side of the door correct setting is "Left". | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Right hinged door | 1 | 1 | Left hinged door |
|
5 | ReLock mode | ReLock mode is factory default on. ReLock is the security function relocking the door lock 7 seconds after a valid unlock if the door is not opened. When ReLock is off, the door lock will remain unlocked untill a new lock door operation (i.e. pressing O/C-button, activating touch panel or closing the door if auto lock mode). | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | ReLock mode off | 1 | 1 | ReLock mode on |
|
6 | Service PIN Mode | The service PIN on ID Lock 150 will be enabled or disabled according to this configuration setting. By default the Service PIN Mode is 0=Deactivated. It can be set to either 1, 2, 5 or 10 times, 12 hours or 24 hours. This is a set only parameter, if changed locally this config parameter does not change. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Service PIN deactivated | 1 | 1 | Service PIN valid 1 time | 2 | 2 | Service PIN valid 2 times | 3 | 3 | Service PIN valid 5 times | 4 | 4 | Service PIN valid 10 times | 8 | 8 | Service PIN valid 12 hours | 9 | 9 | Service PIN valid 24 hours |
|
7 | Door lock model | This configuration is only available through the configuration get command. If the configuration report is 65(101), door lock model type is ID Lock 101. If the configuration report is 96(150), door lock model type is ID Lock 150. ID Lock 101 cannot have user PINs or individually deleted RFID keyfobs. ID Lock 101 cannot have Service PIN Mode (Mode on ID-101 is always on). ID Lock 101 cannot be remote configured on volume, hinge direction. ID Lock 101 does not have the ReLock function (Mod on ID-101 is always on). This is a read-only parameter, it cannot be changed. | 0 | 1 | 0 | 0 | 96 | From | To | Description |
|---|
65 | 65 | ID Lock 101 | 96 | 96 | ID Lock 150 |
|
