COMMAND_CLASS_SWITCH_ALL

Switch All

0x27

1

COMMAND_CLASS_CENTRAL_SCENE

Central Scene

0x5B

1

COMMAND_CLASS_WAKE_UP_V2

Wake Up V2

0x84

2

COMMAND_CLASS_SCENE_ACTIVATION

Scene Activation

0x2B

1

Manual_Primary_Lang

Product or Owner's Manual

1

5

0

Z-Wave Plus Lifeline

23

Controller Inclusion

To “Include” into (adding into) an existing network: Put the Z-Wave™ Gateway or Controller into learn mode to add the keyfob into your controller. To get in to “inclusion” mode, the distance between sensor and controller is suggested to be within one meter.

24

Controller Exclusion

To “Exclude” from (removing from) an existing network: Put the Z-Wave™ Gateway or Controller into learn mode to remove the keyfob into/from your controller. To get in to “exclusion” mode, the distance between sensor and controller is suggested to be within one meter.

3

Learn Mode (adding another controller)

* Keyfob should not include any node * Under Control Mode: Press button 1 and 4 together till the red LED flashes to include into other Z-Wave network. * Under Setup Mode: Press button 3 and 4 together till the red LED flashes to include into other Z-Wave network.  It will send NWI NIF info. * Keyfob will return to sleep after 5 seconds if no inclusion nor exclusion.

5

Factory Reset

Press 4 buttons together for 10 seconds. The LED colors will turn red after 2 seconds for 2 seconds and turn green for another 2 seconds. Keyfob will send “Device Reset Locally Notification” command and reset to the factory default. (Red LED flashes fast means reset completely). Remark: This is to be used only in the case of primary controller being inoperable or otherwise unavailable.
