COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_SWITCH_ALL

Switch All

0x27

1

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_CONFIGURATION

Configuration

0x70

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_SWITCH_MULTILEVEL_V2

Switch Multilevel V2

0x26

2

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_SWITCH_COLOR

Switch Color

0x33

1

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2

Firmware Update Meta-Data V2

0x7A

2

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

Manual_Primary_Lang

Product or Owner's Manual

Color

Firmware Updatable

Switch Load Capacity Watts

1

1

0

Set Configuration parameter 0x50 0: nothing. 1: Send the Basic Report. 2. Send Device Reset Locally CC

80

Enable to send notifications to associated devices (Group 1) when the state of LED Bulb is changed.

Enable to send notifications to associated devices (Group 1) when the state of LED Bulb is changed. 0 = Nothing. 1= Basic CC report.

0

1

0

0

1

82

The user can configure the parameter to adjust the color component Cold White.

The user can configure the parameter to adjust the color component Cold White. Value rang = Cold White (0x1388 (5000k) ~ 0x1964 (6500k))

0

2

0

0

6500

2

Enable/Disable Strobe over Custom Color.

Enable/Disable Strobe over Custom Color. 0 = Disable. 1 = Enable. Others = Ignore.

0

1

0

0

0

3

Set the rate of change to next color in Custom Mode.

Set the rate of change to next color in Custom Mode. Value1 ~ Value4: Value Range = 5 - 8640000 (50 - 86400000ms)

0

1

0

0

50

4

Set color that LED Bulb blinks in (Blink Mode)

Set color that LED Bulb blinks in (Blink Mode) -128 to 127 corresponds with the unsigned values 0 to 255 or hex values 0x00 to 0xFF

0

1

0

0

1

81

The user can configure the parameter to adjust the color component Warm White.

The user can configure the parameter to adjust the color component Warm White. Value range =Warm White(0x0A8C(2700k) ~ 0x1387 (4999k))

0

2

0

0

2700

1

User custom mode for LED animations.

User custom mode for LED animations. 0 = Disable custom mode. 1= Blink Colors in order mode. 2=Randomized blink color mode

0

1

0

0

0

2

Exclusion

Remove for exclusion 1. Assuming led bulb was added to controller. 2. Triggered by OFF -> ON -> OFF -> ON -> OFF -> ON (between 0.5-2 seconds each time). 3. LED Solid Purple/Violet Color (0xEE82EE) during the unpairing process. (Timeout is 10 seconds).  Failure: Blinks between 100% White and Red 0x0000FF color for 3 seconds (at a rate of 200ms per flash), Once 3 seconds have passed, the LED should return to the last color ( memory status(color cc set)) of LED Bulb.  Success: Blinks between 100% White and Blue 0x0000FF color for 3 seconds (at a rate of 200ms per flash). Once 3 seconds have passed, the LED should return to a Warm White LED at 100%.

5

Factory Reset

Reset the Device. 1. Assuming led bulb was added to controller and was power on. 2. RGBW bulb re-power 6 times (between 0.5-2 seconds each time). Note: ON -> OFF -> ON -> OFF -> ON -> OFF -> ON -> OFF -> ON -> OFF -> ON -> OFF -> ON 3. If the 6th power on, the led bulb change to Yellow color(into pairing process ), which means that the reset factory settings are successf. Using this action in case of the primary controller is missing or inoperable.

1

Inclusion

Add for inclusion 1. Ensure the led bulb has been excluded outside the network. 2. Triggered by OFF ->ON (between 0.5-2 seconds each time) 3. LED solid yellow Color (0xFFFF00) during the pairing(Timeout is 10 seconds).  Failure: Blinks between 100% White and Red 0x0000FF color for 3 seconds (at a rate of 200ms per flash), Once 3 seconds have passed, the LED should return to a Warm White LED at 100%  Success: Blinks between 100% White and Green 0x00FF00 color for 3 seconds (at a rate of 200ms per flash). Once 3 seconds have passed, the LED should return to a Warm White LED at 100%.
