COMMAND_CLASS_SWITCH_MULTILEVEL

Switch Multilevel

0x26

1

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4

Firmware Update Meta-Data V4

0x7A

4

COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_CONFIGURATION

Configuration

0x70

1

COMMAND_CLASS_TRANSPORT_SERVICE_V2

Transport Service V2

0x55

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_BASIC_V2

Basic V2

0x20

2

COMMAND_CLASS_SECURITY_2

Security S2

0x9F

1

COMMAND_CLASS_VERSION_V3

Version V3

0x86

3

COMMAND_CLASS_SUPERVISION

Supervision

0x6C

1

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

Manual_Primary_Lang

Product Manual

1

5

0

Lifeline

Z-Wave Plus Lifeline

1

Dim Level

When value = 0, the brightness level will resume to full brightness when the Smart Bulb is turned ON every time by manual switch (or when power is restored after a power failure). When value = 1, the brightness level will maintain same dim level as the last setting when the Smart Bulb is turned ON again by manual switch (ow when power is restored after a power failure). When value = 2, restoring power to the light bulb will always keep last lamp status.

1

1

0

2

2

9

Dim Level

When the value is low, dimming brightness is gradual. When the value is high, dimming brightness is rapid.

1

1

1

99

99

10

Dimming/Brightening Step Timing

When the value is low, the step timing is quick. When the value is high, the step timing is slow.

1

1

0

10

10

8

Where to find S2 DSK on product

If prompted by the controller to enter the S2 security code, refer to the QR code/security number on the side of the box or the QR code label on the product (see Figure 1).

1

Classic Inclusion

1. Follow the instructions for your Z-Wave certified controller to remove a device from the Z-Wave network. 2. Once the controller is ready to remove your device, turn bulb OFF, then ON three times. The smart bulb flashes twice when removed from the network.

2

Classic Exclusion

Adding your device to a Z-Wave network 1. When initially powered, the bulb is in SmartStart inclusion mode. If your hub supports SmartStart, scan the QR code. 2. To change to classic inclusion mode, turn bulb OFF, then ON three times. The bulb rapidly flashes four times to indicate classic mode. 3. To change back to SmartStart inclusion mode, turn the bulb OFF, then ON three times. The bulb rapidly flashes six times to indicate SmartStart mode. NOTE: The bulb attempts to connect in either inclusion

5

Factory Reset Procedure

To return your smart bulb to factory defaults Starting with the bulb on, cycle the wall switch OFF/ON four times. 1. Turn the switch off, pause one second, then turn back ON. 2. Repeat three times (four times total). 3. The smart bulb flashes twice when reset.
