7 | Default Level(Local) | Default level for the strip when it is powered on from the local switch. A setting of 0 means that the switch will return to the level that it was on before it was turned off. 0 - Previous | 2 | 1 | 0 | 99 | 0 | From | To | Description |
|---|
0 | 0 | Returns lightstrip to the previous level prior to being turned off | 1 | 99 | Percent level to turn the lightstrip to when turned on (1 = 1%, 2 = 2%, etc) |
|
1 | Number of Pixels | When individually addressable LEDs are used, this parameter tells the controller the number of pixels that are attached. 0 - Automatic recognition of pixels. 1..130 - Manually set the number of pixels. | 2 | 1 | 0 | 130 | 0 | From | To | Description |
|---|
0 | 0 | Automatic Recognition of Pixels | 1 | 130 | Manual input of Pixels (1 = 1 Pixel, 2 = 2 Pixels, etc) |
|
2 | Dimming Speed | This changes the speed in which the lightstrip dims up or down. A setting of 0 should turn the light immediately on or off (almost like an on/off switch). Increasing the value should slow down the transition speed. 0 - Instant, 1 - Fast .. 98 - Slow | 2 | 1 | 0 | 98 | 3 | From | To | Description |
|---|
0 | 0 | Instant on | 1 | 98 | Speed of dimming up or down (1 = fast, 98 = slow) |
|
4 | Minimum Level | The minimum level that the strip can be dimmed to. Useful when the user has an LED strip that does not turn on or flickers at a lower level. | 2 | 1 | 1 | 45 | 1 | From | To | Description |
|---|
1 | 45 | Percent value of the minimum dim level (1 = 1%, 2 = 2%, etc) |
|
17 | Active power reports | The power level change that will result in a new power report being sent. The value is a percentage of the previous report. 0 = disabled. | 2 | 1 | 0 | 100 | 10 | From | To | Description |
|---|
0 | 0 | Disabled | 1 | 100 | Set the percentage level change of the previous report (1 = 1%, 2 = 2%, etc) |
|
10 | State Power Restored | The state the switch should return to once power is restored after power failure. 0 - Off. 1 - Default Color / Level (Parameter 9). 2 - Previous | 2 | 1 | 0 | 2 | 2 | From | To | Description |
|---|
0 | 0 | Off | 1 | 1 | Returns to the default color / level as set in Parameter 9 | 2 | 2 | Returns to the previous setting before loss of power |
|
24 | Custom Effect Parameter 3 | A custom effect with up to 4 actions can be turned on with correct input for parameters 22-24, 30. This parameter controls the duration of those actions. See website for details. https://inovelli.com/lzw45/parameters | 2 | 4 | 0 | 1010580540 | 0 | From | To | Description |
|---|
0 | 1010580540 | See website for further instructions: https://inovelli.com/lzw45/parameters |
|
31 | Pixel Effect | Turn on an effect that utilizes the individually addressable LEDs. Byte 0 = Effect, Byte 1 = Level | 2 | 2 | 0 | 32767 | 0 | From | To | Description |
|---|
0 | 32767 | See website for further instructions: https://inovelli.com/lzw45/parameters |
|
51 | Button Delay | The 700ms delay that occurs after pressing the physical button to turn the switch on/off is removed. Consequently this also removes the following scenes: 2x, 3x, 4x, 5x tap. Still working are the 1x tap, held, released, and the level up/down scenes. | 2 | 1 | 0 | 1 | 1 | From | To | Description |
|---|
0 | 0 | Yes - Disable 700ms delay | 1 | 1 | No - Do not disable 700ms delay |
|
3 | Ramp Rate | This changes the speed in which the lightstrip turns on or off. For example, when a user sends the switch a basicSet(value: 0xFF) or basicSet(value: 0x00), this is the speed in which those actions take place. A setting of 0 should turn the light immediately on or off (almost like an on/off switch). Increasing the value should slow down the transition speed. A setting of 99 should keep this in sync with parameter 2. 0 - Instant. 1 - Fast .. 98 - Slow. 99 - Keep in sync with parameter 2 | 2 | 1 | 0 | 99 | 99 | From | To | Description |
|---|
0 | 0 | Instant on | 1 | 99 | Speed of turning on/off (1 = fast, 99 = slow) |
|
5 | Maximum Level | The maximum level that the strip can be dimmed to. Useful when the user has an LED strip that reaches its maximum level before the dimmer value of 99. | 2 | 1 | 55 | 99 | 99 | From | To | Description |
|---|
55 | 99 | Percent value of the maximum dim level (55 = 55%, 56 = 56%, etc) |
|
6 | Auto Off Timer | Automatically turns the strip off after this many seconds. When the strip is turned on a timer is started that is the duration of this setting. When the timer expires, the strip is turned off. 0 - Auto off is disabled | 2 | 2 | 0 | 32767 | 0 | From | To | Description |
|---|
0 | 0 | Auto-off is disabled | 1 | 32767 | Amount of seconds until the lightstrip turns off automatically (1 = 1 second, 2 = 2 seconds, etc) |
|
8 | Default Level (Z-Wave) | Default level for the dimmer when it is powered on from a Z-Wave command (i.e. BasicSet(0xFF). A setting of 0 means that the switch will return to the level that it was on before it was turned off. 0 - Previous | 2 | 1 | 0 | 99 | 0 | From | To | Description |
|---|
0 | 0 | Returns lightstrip to the previous level prior to being turned off | 1 | 99 | Percent level to turn the lightstrip to when turned on (1 = 1%, 2 = 2%, etc) |
|
9 | Default Color&Temp | Byte(3-2): Values between 2700-6500 represent a color temperature. Byte(1-0): Values between 1-360 represent the color on the Hue color wheel. The value of 361 represents a random color and a value of 0 represents the previous color. | 2 | 4 | 0 | 6500 | 0 | From | To | Description |
|---|
0 | 0 | Returns the lightstrip to the previous color when turned on | 1 | 360 | Represents the values of the hue color wheel | 2700 | 6500 | Represents the values of color temperature (Kelvins) where 2700 is warm white and 6500 is cool white |
|
23 | Custom Effect Parameter 2 | A custom effect with up to 4 actions can be turned on with correct input for parameters 22-24, 30. This parameter controls the level of those actions. See website for details. https://inovelli.com/lzw45/parameters | 2 | 4 | 0 | 1667457891 | 0 | From | To | Description |
|---|
0 | 1667457891 | See website for further instructions: https://inovelli.com/lzw45/parameters |
|
