3 | Motion detection - pulse counter | This parameter determines the number of moves required for the PIR sensor to report motion. The higher the
value, the less sensitive the PIR sensor is.
It is not recommended to modify this parameter settings! | 1 | 1 | 0 | 3 | 1 | From | To | Description |
|---|
0 | 3 | Motion detection - pulse counter |
|
4 | Motion detection - window time | Period of time during which the number of moves set in parameter 3 must be detected in order for the PIR sensor
to report motion. The higher the value, the more sensitive the PIR sensor is.
It is not recommended to modify this parameter setting! | 1 | 1 | 0 | 3 | 2 | From | To | Description |
|---|
0 | 3 | Motion detection - window time |
|
6 | Motion detection - operating mode | This parameter determines in which part of day the PIR sensor will be active.
This parameter influences only the motion reports and associations. Tamper, light intensity and temperature measurements will be still active, regardless of this parameter sett | 1 | 1 | 0 | 2 | 0 | From | To | Description |
|---|
0 | 2 | operating mode |
|
7 | Motion detection - night/day | This parameter defines the difference between night and day in terms of light intensity, used in parameter 8. | 1 | 2 | 1 | 32767 | 200 | From | To | Description |
|---|
1 | 32767 | Motion detection - night/day |
|
8 | BASIC command class configuration | This parameter determines the command frames sent to 2nd association group (assigned to PIR sensor).
Values of BASIC ON and BASIC OFF command frames can be modified with dedicated parameters (14 and 16). | 1 | 1 | 0 | 2 | 0 | From | To | Description |
|---|
0 | 2 | BASIC command class configuration |
|
9 | BASIC ON command frame value | The command frame sent at the moment of motion detection. Further motion detections, during the cancellation
time, will not result in sending the association. | 1 | 2 | 0 | 255 | 255 | From | To | Description |
|---|
0 | 255 | BASIC ON command frame value |
|
10 | BASIC OFF command frame value | The command frame sent at the moment of motion alarm cancellation, after cancellation delay time specified in
parameter 6. | 1 | 2 | 0 | 255 | 0 | From | To | Description |
|---|
0 | 255 | BASIC OFF command frame value |
|
11 | Associations in Z-Wave network Security Mode | This parameter defines how commands are sent in specified association groups: as secure or non-secure. Parameter is active only in Z-Wave network security mode. It does not apply to 1st group “Lifeline" | 1 | 1 | 0 | 8 | 0 | From | To | Description |
|---|
0 | 8 | Associations in Z-Wave network Security Mode |
|
17 | Tamper - backward compatible broadcast mode | The parameter determines whether the backward compatible tamper alarm frame will or will not be sent in
broadcast mode. Alarm frames sent in broadcast mode can be received by all of the devices within range (if they
accept such frames), but not repeated by them. This parameter provides backward compatibility with controllers
not supporting Z-Wave Plus. | 1 | 1 | 0 | 1 | 0 | From | To | Description |
|---|
0 | 1 | Tamper - backward compatible broadcast mode |
|
23 | Temperature offset | The value to be added to the actual temperature, measured by the sensor (temperature compensation). | 1 | 2 | -1000 | 1000 | 0 | From | To | Description |
|---|
-1000 | 1000 | Temperature offset |
|
24 | Visual LED indicator - signalling mode | This parameter determines the way in which visual indicator behaves after motion has been detected.
Flashlight Mode - visual indicator glows in white for 10 seconds. If value of parameter 80 is set to 11, each detected motion extends the glowing by next 10 seconds. | 1 | 1 | 0 | 24 | 10 | From | To | Description |
|---|
0 | 24 | Visual LED indicator - signalling mode |
|
25 | Visual LED indicator - brightness | This parameter determines the brightness of the visual LED indicator when indicating motion. | 1 | 1 | 0 | 100 | 50 | From | To | Description |
|---|
0 | 100 | Visual LED indicator - brightness |
|
