Product Recognition | |
|---|
Certification Number | ZC10-19056485 |
|---|
Name | Motion Sensor |
|---|
Short Description | This Smart Motion Sensor adopts automatic threshold adjustment technology to enhance the stability of the detector, efficiently decrease false alarms. Automatic temperature compensation technology can efficiently prevent detectors from the sensitivity decrease resulted from the temperature variation. |
|---|
Long Description | This Smart Motion Sensor adopts automatic threshold adjustment technology to enhance the stability of the detector, efficiently decrease false alarms. Automatic temperature compensation technology can efficiently prevent detectors from the sensitivity decrease resulted from the temperature variation.
It’s suitable to be used for safety protection of residential, villas, factories, shopping malls, warehouses, office
buildings, banks, computer room and other places. |
|---|
Brand | CLEVERIO |
|---|
Product Identifier | 51111 |
|---|
OEM Version | HW: 255 FW: 1.37 |
|---|
Hardware Platform | ZM5202 |
|---|
Z-Wave Version | 6.51.06 |
|---|
Library Type | SLAVE_ROUTING |
|---|
Device Type | Notification Sensor |
|---|
Role Type | ROLE_TYPE_SLAVE_SLEEPING_REPORTING |
|---|
Manufacturer ID | 0x041C |
|---|
Product Type ID | 0x8001 |
|---|
Product ID | 0x1000 |
|---|
User Icon | 0x0C07 |
|---|
Installer Icon | 0x0C07 |
|---|
Frequency Plans | EU: 869.85MHz, 868.40MHz |
|---|
Categories | Sensors |
|---|
Countries / Regions | European Union |
|---|
Supported Command Classes | Identifier | Name | Key | Version |
|---|
COMMAND_CLASS_POWERLEVEL | Powerlevel | 0x73 | 1 | COMMAND_CLASS_BATTERY | Battery | 0x80 | 1 | COMMAND_CLASS_SENSOR_BINARY_V2 | Sensor Binary V2 | 0x30 | 2 | COMMAND_CLASS_VERSION_V2 | Version V2 | 0x86 | 2 | COMMAND_CLASS_WAKE_UP_V2 | Wake Up V2 | 0x84 | 2 | COMMAND_CLASS_DEVICE_RESET_LOCALLY | Device Reset Locally | 0x5A | 1 | COMMAND_CLASS_ZWAVEPLUS_INFO_V2 | Z-Wave Plus Info V2 | 0x5E | 2 | COMMAND_CLASS_ASSOCIATION_V2 | Association V2 | 0x85 | 2 | COMMAND_CLASS_ASSOCIATION_GRP_INFO | Association Group Info | 0x59 | 1 | COMMAND_CLASS_MANUFACTURER_SPECIFIC | Manufacturer Specific | 0x72 | 1 | COMMAND_CLASS_NOTIFICATION_V4 | Notification V4 | 0x71 | 4 |
|
|---|
Documents | Category | Description | File |
|---|
Manual_Primary_Lang | Product or Owner's Manual | |
|
|---|
Features | Feature | Values |
|---|
Battery Type | | Supported Notification Types | | Color | | Communications Protocol | | Battery Quantity | | Sensors | Value |
|---|
Motion/No Motion (Binary) |
|
|
|---|
Association Groups | Group Number | Maximum Nodes Supported | End Point ID | Description |
|---|
3 | 5 | 0 | Association group 3: Root Device group(Notification)
1-Report status of people passing by, no people passing by, tamper alarm and tamper recovery through lifeline.
2- When the Device detects new event of people passing by or no people passing by, tamper alarm and tamper recovery, the device will be triggered.
| 1 | 5 | 0 | Association group 1: Lifeline association group
Include command classe: Battery report, Notification report, and Device Reset Locally notification, Binary report.
| 2 | 5 | 0 | Association group 2: Root Device group(Binary Sensor)
Binary Sensor Command Class:Compatible with 300 series.
1-Report status of people passing by, no people passing by, tamper alarm and tamper recovery via lifeline.
2- When the Device detects new event of people passing by or no people passing by, tamper alarm and tamper recovery, the device will be triggered.
|
|
|---|
Texts | ID | Description | Value |
|---|
1 | Inclusion | -Press Func_Button 3 time in the motion sensor, Green LED is Blinking 3 times within 1 second.
-If Inclusion Process is successful, Green LED will turn off. | 2 | Exclusion | -Press Func_Button 3 times quickly.
-If Exclusion Process is successful, Green LED is Blinking 6 times, then turn off. | 5 | Factory Reset | -Long press Func_Button while installing batteries
-Device Reset Locally notification is Transmitted
-Please use this procedure only when the network primary controller is missing or otherwise inoperable. |
|
|---|
Supported Notification Types | Notification Type | Event / State |
|---|
Access Control | (Refer to parameters): State idle |
|
|---|
Supported Multilevel Sensors | Multilevel Sensor Type |
|---|
General purpose |
|
|---|
Supports NWI | Yes |
|---|
Supports Explorer Frames | Yes |
|---|
Radio Range Z-Wave (m) | 40 |
|---|
