66 | Temperature offset | The value to be added to the actual temperature, measured by the sensor (temperature compensation). | 0 | 2 | 0 | 0 | 0 | From | To | Description |
|---|
-1000 | 1000 | (-100 - 100°C, 0.1°C step) |
|
81 | Visual LED indicator - brightness | This parameter determines the brightness of the visual LED indicator when indicating motion. | 0 | 1 | 0 | 0 | 50 | From | To | Description |
|---|
0 | 0 | brightness determined by the illuminance(parameters 82 and 83) | 1 | 100 | (1-100%) |
|
83 | Visual LED indicator - illuminance for high indicator brightness | Light intensity level above which brightness of visual indicator is set to 100%. | 0 | 2 | 0 | 0 | 1000 | From | To | Description |
|---|
82 | 32767 | (in lux) |
|
3 | Motion detection - pulse counter | This parameter determines the number of moves required for the PIR sensor to report motion. The higher the value, the less sensitive the PIR sensor is. It is not recommended to modify this parameter settings! | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | 1 pulse | 1 | 1 | 2 pulse | 2 | 2 | 3 pulse | 3 | 3 | 4 pulse |
|
4 | Motion detection - window time | Period of time during which the number of moves set in parameter 3 must be detected in order for the PIR sensor to report motion. The higher the value, the more sensitive the PIR sensor is. It is not recommended to modify this parameter setting! | 0 | 1 | 0 | 0 | 2 | From | To | Description |
|---|
0 | 0 | 4 seconds | 1 | 1 | 8 seconds | 2 | 2 | 12 seconds | 3 | 3 | 16 seconds |
|
8 | Motion detection - operating mode | This parameter determines in which part of day the PIR sensor will be active. This parameter influences only the motion reports and associations. Tamper, light intensity and temperature measurements will be still active, regardless of this parameter settings. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | PIR sensor always active | 1 | 1 | PIR sensor active during the day only | 2 | 2 | PIR sensor active during the night only |
|
9 | Motion detection - night/day | This parameter defines the difference between night and day in terms of light intensity, used in parameter 8. | 0 | 2 | 0 | 0 | 200 | From | To | Description |
|---|
1 | 32767 | (1-32767 lux) |
|
24 | Tamper - operating modes | This parameter determines function of the tamper and sent reports. It is an advanced feature serving much more functions than just detection of tampering. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | tamper only | 1 | 1 | tamper and earthquake detector | 2 | 2 | tamper and orientation in space |
|
25 | Tamper - alarm cancellation | This parameter allows to disable cancellation of the tamper alarm. | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | do not send tamper cancellation report | 1 | 1 | send tamper cancellation report |
|
42 | Illuminance report - interval | Time interval between consecutive illuminance reports. The reports are sent even if there is no change in the light intensity. | 0 | 2 | 0 | 0 | 3600 | From | To | Description |
|---|
0 | 0 | periodical reports are not sent | 1 | 32767 | (in seconds) |
|
60 | Temperature report - threshold | This parameter determines the change in measured temperature that will result in new temperature report being sent to the main controller. | 0 | 2 | 0 | 0 | 10 | From | To | Description |
|---|
0 | 0 | reports are not sent | 1 | 255 | (0.1-25.5°C, 0.1°C step) |
|
62 | Temperature measuring - interval | Time interval between consecutive temperature measurements. The shorter the time, the more frequently the temperature will be measured, but the battery life will shorten. | 0 | 2 | 0 | 0 | 900 | From | To | Description |
|---|
0 | 0 | temperature is not measured | 1 | 32767 | (in seconds) |
|
64 | Temperature report - interval | Time interval between consecutive temperature reports. The reports are sent even if there is no change in the temperature. | 0 | 2 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | periodical reports are not sent | 1 | 32767 | (in seconds) |
|
82 | Visual LED indicator - illuminance for low indicator brightness | Light intensity level below which brightness of visual indicator is set to 1%. | 0 | 2 | 0 | 0 | 100 | From | To | Description |
|---|
0 | 83 | (in lux) |
|
89 | Visual LED indicator - tamper alarm | This parameter allows to enable/disable indicating tamper alarm (flashing white, red and blue) | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | tamper alarm is not indicated | 1 | 1 | tamper alarm is indicated |
|
