41 | Repositioning Status Report | Used to Get repositioning Status. | 1 | 1 | 0 | 1 | 0 | From | To | Description |
|---|
0 | 0 | Repositioning complete | 1 | 1 | in repositioning |
|
42 | Calibration Lock | Used to enable/disable calibration lock from different ways. | 1 | 1 | 0 | 2 | 1 | From | To | Description |
|---|
0 | 0 | Disable calibration | 1 | 1 | Enable Action Button/ Command Calibration | 2 | 2 | Enable Action Button/ Command/S1/S2 Calibration |
|
80 | Switch Status Report Selection | Choose which report to send when switch status change | 1 | 1 | 0 | 2 | 2 | From | To | Description |
|---|
0 | 0 | No Report | 1 | 1 | Basic Report | 2 | 2 | Switch Multilevel Report |
|
120 | Switch Type of External Switch 1 | Used to set Switch type of External Switch 1,and reports will return automatically during identify. | 1 | 1 | 0 | 4 | 0 | From | To | Description |
|---|
0 | 0 | Unidentified mode when no identify is set, and indicate identify fails when in identify. | 1 | 1 | 2-state switch mode | 2 | 2 | 3 way switch mode | 3 | 3 | Push Button mode | 4 | 4 | Enter automatic identification mode(The blue led will fast blink) |
|
121 | Switch Type of External Switch 1 | Used to set Switch type of External Switch 1,and reports will return automatically during identify. | 1 | 1 | 0 | 4 | 0 | From | To | Description |
|---|
0 | 0 | Unidentified mode when no identify is set, and indicate identify fails when in identify. | 1 | 1 | 2-state switch mode | 2 | 2 | 3 way switch mode | 3 | 3 | Push Button mode | 4 | 4 | Enter automatic identification mode(The blue led will fast blink) |
|
248 | Function Setting of External Switch S1&S2 | Used to Enable/Disable function of External Switch S1&S2. Note : This value can be combine, e.g. set to 3(1+2=3),means networking function and Reset function are both enable. | 1 | 1 | 1 | 2 | 1 | From | To | Description |
|---|
1 | 1 | Enable network function, inclusion/exclusion | 2 | 2 | Enable reset to factory default function |
|
255 | Reset Function | Used to reset configuration parameter value to default value or reset to factory default settings. Note： Parameter 0x16, 0x22, 0x23, 0x24, 0x25, 0x27, 0x28 will not reset to default value by this command. | 1 | 4 | 0 | 1431655765 | 0 | From | To | Description |
|---|
0 | 0 | Reset all configuration parameters to default settings | 1431655765 | 1431655765 | reset to factory default settings and removed from the z-wave network |
|
85 | Extern Button Mode Setting | Extern Button Mode Setting Note: when setting value to 2, we advice not to set only one external switch to push button, do remember to change the controller channel before operating push button, or the curtain level will be wrong. | 1 | 1 | 0 | 2 | 0 | From | To | Description |
|---|
0 | 0 | S1/S2 map to Z-Wave Button | 1 | 1 | S1 = Open or Stop, S2 = Close or Stop Note:Operation will not change the curtain mode, including press and hold ,short press. | 2 | 2 | 1） When configuration 0x78/79 = 03： Press and hold S1 :blade folds to 180° Press and hold S2： Blade folds to 0° Short press S1： Blinds go downwards Short press S2： Blinds go upwards Note: The device will change its curtain mode if it does not match the current mode. 2） When Configuration 0x78/79 = others： S1 = Open or Stop,S2 = Close or Stop ,operation will not change the curtain mode. |
|
