COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_PROTECTION_V2

Protection V2

0x75

2

COMMAND_CLASS_APPLICATION_STATUS

Application Status

0x22

1

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_CONFIGURATION

Configuration

0x70

1

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3

Multi Channel Association V3

0x8E

3

COMMAND_CLASS_CRC_16_ENCAP

CRC-16 Encapsulation

0x56

1

COMMAND_CLASS_SECURITY

Security 0

0x98

1

COMMAND_CLASS_MULTI_CHANNEL_V4

Multi Channel V4

0x60

4

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_SWITCH_BINARY

Binary Switch

0x25

1

COMMAND_CLASS_METER_V3

Meter V3

0x32

3

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_NOTIFICATION_V5

Notification V5

0x71

5

COMMAND_CLASS_CENTRAL_SCENE_V2

Central Scene V2

0x5B

2

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V3

Firmware Update Meta-Data V3

0x7A

3

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_SWITCH_MULTILEVEL_V3

Switch Multilevel V3

0x26

3

COMMAND_CLASS_NOTIFICATION_V5

Notification V5

0x71

5

Manual_Primary_Lang

Product Manual

1

1

0

Lifeline

0x0001

"Lifeline" reports the device status and allows for assigning single device only (main controller by default).

2

5

0

On/Off (S1)

0x2001

“On/Off (S1)” is assigned to S1 input terminal (uses Basic command class).

3

5

0

Dimmer (S1)

0x2001

"Dimmer (S1)" is assigned to S1 input terminal (uses Switch Multilevel command class).

4

5

0

On/Off (S2)

0x2002

“On/Off (S2)” is assigned to S2 input terminal (uses Basic command class).

5

5

0

Dimmer (S2)

0x2002

"Dimmer (S2)" is assigned to S2 input terminal (uses Switch Multilevel command class).

1

Restore state after power failure

This parameter determines if the device will return to state prior to the power failure after power is restored.

1

1

0

1

1

2

First channel - operating mode

This parameter allows to choose operating for the 1st channel controlled by the S1 switch.

1

1

0

5

0

3

First channel - reaction to switch for delay/auto ON/OFF modes

This parameter determines how the device in timed mode reacts to pushing the switch connected to the S1 terminal.

1

1

0

2

0

5

First channel - pulse time for flashing mode

This parameter allows to set time of switching to opposite state in flashing mode

1

2

0

32000

5

6

Second channel - operating mode

This parameter allows to choose operating for the 1st channel controlled by the S2 switch.

1

1

0

5

0

7

Second channel - reaction to switch for delay/auto ON/OFF modes

This parameter determines how the device in timed mode reacts to pushing the switch connected to the S2 terminal.

1

1

0

2

0

8

Second channel - time parameter for delay/auto ON/OFF modes

This parameter allows to set time parameter used in timed modes.

1

2

0

32000

50

9

Second channel - pulse time for flashing mode

This parameter allows to set time of switching to opposite state in flashing mode.

1

2

1

32000

5

10

Switch type

This parameter defines as what type the device should treat the switch connected to the S1 and S2 terminals.

1

1

0

2

0

11

Flashing mode - reports

This parameter allows to define if the device sends reports during the flashing mode

1

1

0

1

0

17

S1 switch - Switch OFF value sent to 2nd and 3rd association groups

This parameter defines value sent with Switch OFF command to devices associated in 2nd and 3rd association group.

1

2

0

255

0

23

S2 switch - Double Click value sent to 4th and 5th association groups

This parameter defines value sent with Double Click command to devices associated in 4th and 5th association group.

1

2

0

255

99

24

Reaction to General Alarm

This parameter determines how the device will react to General Alarm frame.

1

1

0

3

3

25

Reaction to Flood Alarm

This parameter determines how the device will react to Flood Alarm frame.

1

1

0

3

2

31

First channel - energy reports

This parameter determines the minimum change in consumed energy that will result in sending new energy report to the main controller.

1

2

0

32000

100

4

First channel - time parameter for delay/auto ON/OFF modes

This parameter allows to set time parameter used in timed modes.

1

2

0

32000

50

2

Classic Exclusion

To remove the device from the Z-Wave network: 1. Place On/Off-Control within the direct range of your Z-Wave controller. 2. Identify the S1 switch. 3. Set the main controller in remove mode (see the controller’s manual). 4. Quickly, three times press the S1 switch. 5. Wait for the removing process to end. 6. Successful removing will be confirmed by the Z-Wave controller’s message.

5

Factory Reset Procedure

Resetting On/Off-Control 1. Switch off the mains voltage (disable the fuse). 2. Remove On/Off-Control from the wall switch box. 3. Switch on the mains voltage. 4. Press and hold the B-button to enter the menu. 5. Wait for the visual LED indicator to glow yellow. 6. Quickly release and click the B-button again. 7. After few seconds the device will be restarted, which is signalled with the red LED indicator colour

1

Classic Inclusion

To add the device to the Z-Wave network manually: 1. Place On/Off-Control within the direct range of your Z-Wave controller. 2. Identify the S1 switch. 3. Set the main controller in (security/non-security) add mode (see the controller’s manual). 4. Quickly, three times press the S1 switch. 5. Wait for the adding process to end. 6. Successful adding will be confirmed by the Z-Wave controller’s message.

Electric meter

Import

Electric Meter Consumption

Heat Alarm

Heat sensor status: Overheat detected

Power Management

Over-current status: Over-current detected
