COMMAND_CLASS_SENSOR_BINARY

Sensor Binary

0x30

1

COMMAND_CLASS_ASSOCIATION_GROUP_INFORMATION

Association Group Information V1

0x59

0

COMMAND_CLASS_NO_OPERATION

No Operation

0x00

1

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3

Multi-Channel Association V3

0x8E

3

COMMAND_CLASS_CONTROLLER_REPLICATION

Controller Replication

0x21

1

COMMAND_CLASS_BATTERY

Battery

0x80

1

COMMAND_CLASS_SWITCH_BINARY

Switch Binary

0x25

1

COMMAND_CLASS_CRC_16_ENCAP

CRC16 Encapsulation

0x56

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_WAKE_UP_V2

Wake Up V2

0x84

2

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_BARRIER_OPERATOR

Barrier Operator

0x66

1

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_MULTI_CHANNEL_V4

Multi-Channel V4

0x60

4

COMMAND_CLASS_MANUFACTURER_SPECIFIC

Manufacturer Specific

0x72

1

COMMAND_CLASS_NOTIFICATION_V4

Notification V4

0x71

4

Manual_Primary_Lang

Product or Owner's Manual

Firmware Updatable

Battery Quantity

Battery Type

Sensors

Color

1

5

0

Z-Wave Plus Lifeline

2

Exclusion

To exclude a Z-Wave device that has been included with Piper, go to the app's Settings from the Dashboard, select ""Z-Wave Accessories"", ""Remove"", then ""Start"". Press the button on the Z-Wave accessory you want to remove, and it will be excluded from Piper.

1

Inclusion

The Smart Switch is used to control and automate lights and appliances through Piper with no installation required. Once you have finished setting up Piper, follow these instructions to add a Smart Switch to it: Plug the switch into an electrical outlet that is within 50 feet of where Piper is located. Plug your light or appliance into the switch and make sure that the light or appliance is turned on. You may have to press the button on the plug-in module once to get your light or appliance to turn on. On the Piper app dashboard, tap the “Settings” button in the top right Tap “Z-Wave Accessories”, “Add”, then “Start” Once you’re prompted to press the button on the Z-Wave device, press the button on the switch. Once Piper and smart switch have been included, give it a name (like “living room lamp”) and press save. The switch is now ready to work with Piper! It will now be visible in the security rules as an action and under the “Controls” page to automate it.

3

Learn Mode (adding another controller)

Z-Wave Learn Mode The Z-Wave learn mode procedure can be used to add Piper to any other existing Z-Wave network. Additionally, Piper can use the Z-Wave learn mode procedure to receive Z-Wave network information from another Z-Wave controller. To enter Z-Wave Learn Mode, navigate to the Wireless Accessories screen (Settings->Wireless Accessories). On the Wireless Accessories screen, tap “Advanced Options”. The resulting screen will display the option to “Add Piper to Z-Wave Network”. Tapping this button and following onscreen instructions, will allow the user to add Piper to an existing Z-Wave network. The same button applies for removing Piper from a Z-Wave network.

5

Factory Reset

Z-Wave Network Reset The Z-Wave network reset procedure performs a default factory reset on Piper’s Z-Wave controller component, which clears all user and Z- Wave network settings. A new Z-Wave network will be established. Afterwards, any previously existing Z-Wave devices must be reset and then added to the new network via the Piper app. The Reset Z-Wave option is located under Settings->Wireless Accessories->Advanced Options Please use this procedure only when the network primary controller is missing or otherwise inoperable
