COMMAND_CLASS_SENSOR_BINARY

Sensor Binary

0x30

1

COMMAND_CLASS_ASSOCIATION

Association

0x85

1

COMMAND_CLASS_SWITCH_MULTILEVEL

Switch Multilevel

0x26

1

COMMAND_CLASS_ASSOCIATION_GROUP_INFORMATION

Association Group Information V1

0x59

0

COMMAND_CLASS_NODE_NAMING

Node Naming

0x77

1

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION

Multi-Channel Association V1

0x8E

0

COMMAND_CLASS_MULTI_CHANNEL

Multi-Channel V1

0x60

0

COMMAND_CLASS_CONTROLLER_REPLICATION

Controller Replication

0x21

1

COMMAND_CLASS_BATTERY

Battery

0x80

1

COMMAND_CLASS_WAKE_UP

Wake Up

0x84

1

COMMAND_CLASS_SWITCH_BINARY

Switch Binary

0x25

1

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_CRC_16_ENCAP

CRC16 Encapsulation

0x56

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_ZWAVEPLUS_INFO

Z-Wave Plus Info

0x5E

1

COMMAND_CLASS_BARRIER_OPERATOR

Barrier Operator

0x66

1

COMMAND_CLASS_NOTIFICATION

Notification V1

0x71

0

COMMAND_CLASS_MANUFACTURER_SPECIFIC

Manufacturer Specific

0x72

1

COMMAND_CLASS_VERSION

Version

0x86

1

Manual_Primary_Lang

Product or Owner's Manual

1

5

0

Z-Wave Plus Lifeline

24

Controller Exclusion

To remove a Z-Wave device that has been added with Piper, go to the app's Settings from the Dashboard, select ""Z-Wave Accessories"", ""Remove"", then ""Start"". Press the button on the Z-Wave accessory you want to remove, and it will be removed from Piper.

23

Controller Inclusion

Smart Switch Example: Plug the switch into an electrical outlet that is within 50 feet of where Piper is located. Plug your light or appliance into the switch and make sure that the light or appliance is turned on. You may have to press the button on the Z-Wave module once to get your light or appliance to turn on. On the Piper app dashboard, tap the “Settings” button in the top right Tap “Z-Wave Accessories”, “Add”, then “Start” Once you’re prompted to press the button on the Z-Wave device, press the button on the switch. Once Piper and the Z-Wave module have added, give it a name (like “living room lamp”) and press save. The switch is now ready to work with Piper! It will now be visible in the security rules as an action and under the “Controls” page to automate it.

5

Factory Reset

The Z-Wave network reset procedure performs a default factory reset on Piper’s Z-Wave controller component, which clears all user and Z- Wave network settings. A new Z-Wave network will be established. Afterwards, any previously existing Z-Wave devices must be reset and then added to the new network via the Piper app. The Reset Z-Wave option is located under Settings->Wireless Accessories->Advanced Options

3

Learn Mode (adding another controller)

The Z-Wave learn mode procedure can be used to add Piper to any other existing Z-Wave network. Additionally, Piper can use the Z-Wave learn mode procedure to receive Z-Wave network information from another Z-Wave controller. To enter Z-Wave Learn Mode, navigate to the Wireless Accessories screen (Settings->Wireless Accessories). On the Wireless Accessories screen, tap “Advanced Options”. The resulting screen will display the option to “Add Piper to Z-Wave Network”. Tapping this button and following onscreen instructions, will allow the user to add Piper to an existing Z-Wave network. The same button applies for removing Piper from a Z-Wave network.
