Product Recognition | — |
|---|---|
Certification Number | ZC08-13060010 |
Name | PIR Sensor |
Long Description | ZP 3102 Z-Wave Motion Sensor
(Temperature Sensor Build-In)
Features:
* Passive Infrared Sensor (PIR)
* 2~10 meter Motion Range
* 120 Degree Horizontal Angle Coverage
* Temperature Function
* Low battery detection
* Panasonic CR123A Battery
* Tamper Switch
* 100ft line of sight
* LED Status Indicator
* Operating temp: -15oC~40oC
* Working Voltage: 3V
* Dimensions: 84*62*50mm
* Frequency Available: US/EU/JP/IN/BR Version Available
* On Japan Telec Certification Process
* Taiwan NCC Approved |
Brand | Vision |
Product Identifier | ZP3102JP |
OEM Version | v04 |
Hardware Platform | ZM4101 |
Z-Wave Version | 6.11.01 |
Library Type | SLAVE_ENHANCED |
Device Type | Not Z-Wave Plus |
Manufacturer ID | 0x0109 |
Product Type ID | 0x2002 |
Product ID | 0x0204 |
Frequency Plans | JP: 922.50MHz, 923.90MHz, 926.30MHz |
Categories | Sensors |
Countries / Regions | Japan |
Controlled Command Classes | |
Documents | |
Radio Range Z-Wave (m) | 40 |
