82 | Set the time of LED state when it is in Night light mode | Set the time of LED state when it is in Night light mode | 0 | 4 | 0 | 0 | 1774619 | From | To | Description |
|---|
0 | 59 | time of OFF state (minute) | 256 | 279 | time of OFF state (hour) | 65536 | 65595 | time of ON state (minute) | 16777216 | 16777239 | time of ON state (hour) |
|
90 | Enable/disable the parameter 91 and 92 | Enable/disable the parameter 91 and 92. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Disable | 1 | 1 | Enable |
|
91 | Induce an automatic report | The value here represents minimum change in wattage (in terms of wattage) to induce a Meter Report | 0 | 2 | 0 | 0 | 25 | From | To | Description |
|---|
0 | 32767 | The threshold can be set from 0 to 32767 watt. |
|
101 | To set which report would be sent in Report group 1 | To set which report would be sent in Report group 1 | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
1 | 1 | Send Meter Report of Voltage | 2 | 2 | Send Meter Report of Current | 4 | 4 | Send Meter Report of Watt | 8 | 8 | Send Meter Report of kWh |
|
80 | To set which notification would be sent to the associated nodes in association group 1 | To set which notification would be sent to the associated nodes in association group 1 when the state of output load is changed. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Nothing | 2 | 2 | Basic Report CC | 1 | 1 | Hail CC |
|
102 | To set which report would be sent in Report group 2 | To set which report would be sent in Report group 2 | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
1 | 1 | Send Meter Report of Voltage | 2 | 2 | Send Meter Report of Current | 4 | 4 | Send Meter Report of Watt | 8 | 8 | Send Meter Report of kWh |
|
103 | To set which report would be sent in Report group 3 | To set which report would be sent in Report group 3 | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
1 | 1 | Send Meter Report of Voltage | 2 | 2 | Send Meter Report of Current | 4 | 4 | Send Meter Report of Watt | 8 | 8 | Send Meter Report of kWh |
|
111 | Set the time interval of sending Report | Set the time interval of sending Report | 0 | 4 | 0 | 0 | 3 | From | To | Description |
|---|
1 | 2147483647 | Interval Seconds |
|
112 | Set the time interval of sending Report | Set the time interval of sending Report | 0 | 4 | 0 | 0 | 600 | From | To | Description |
|---|
1 | 2147483647 | Interval Seconds |
|
113 | Set the time interval of sending Report | Set the time interval of sending Report | 0 | 4 | 0 | 0 | 600 | From | To | Description |
|---|
1 | 2147483647 | Interval Seconds |
|
243 | Pin code | This parameter is used to get the Pin code of Plug. | 0 | 2 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 65535 | The available range of the Pin code is 0 to 65535. |
|
252 | Enable/disable Configuration Locked | Enable/disable Configuration Locked | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Disable | 1 | 1 | Enable |
|
255 | Reset the Plug | Reset the Plug to factory default. | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
1 | 1 | Reset all configuration parameters to default. | 1431655765 | 1431655765 | Reset the Plug to factory default |
|
81 | Configure the state of LED | Configure the state of LED when it is in Energy mode, Momentary indicate mode or Night light mode. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Energy mode. The LED will follow the status (on/off). | 1 | 1 | Momentary indicate mode. When the state of Switch’s load changed, The LED will follow the status (on/off) of its load, but the LED will turn off after 5 seconds if there is no any switch action. | 2 | 2 | Night light mode. The LED will remain the state that is set via the Multilevel Switch Set CC or Color Switch Set CC. |
|
3 | Current Overload Protection. | Current Overload Protection. Output load will be closed after 2 minutes if the current overruns (US: 16.5A, AU: 10.5A, EU: 14A). | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | Disabled | 1 | 1 | Enabled |
|
92 | Induce an automatic report | The value here represents minimum change in wattage percent (in terms of percentage) to induce a Meter Report | 0 | 1 | 0 | 0 | 5 | From | To | Description |
|---|
0 | 100 | The threshold can be set from 0 to 100%. |
|
