1 | On Off Status After Power Failure | Set the on off status for the RGBW Dimmer after power failure. | 1 | 1 | 0 | 2 | 0 | From | To | Description |
|---|
0 | 0 | forced to OFF (regardless of state prior to power outage) | 1 | 1 | remem-bers and restores on/off status after power failure | 2 | 2 | forced to ON (regard-less of state prior to power outage) |
|
156 | Double Click ON Trigger for Associated Devices | Set the status or brightness level triggering other associated devices in your network if the dimmer is turned ON with a double click. Each of the 4 available bytes refers to one channel, starting with IN1 and ending with IN4. This setting applies to basic set and switch multilevel commands sent to associated devices in the appropriate association group. | 1 | 4 | 0 | 255 | 99 | From | To | Description |
|---|
0 | 99 | custom brightness level | 255 | 255 | ON |
|
150 | RGBW / HSB Wall Switch Mode | Choose how switches connected to the input terminals control your LED strip. In the default RGBW mode, each switch connected to each input terminal controls the RGBW channels separately (so IN1 for red, IN2 for green, etc) with a single click for ON/OFF, double click to full brightness, and press-and-hold to dim (momentary switches only). In the HSB mode, IN1 controls hue, IN2 – saturation, IN3 – brightness, IN4 – white with single click for last set value or value 0, double click to max value, and press-and-hold to set custom value. | 1 | 1 | 0 | 1 | 0 | From | To | Description |
|---|
0 | 0 | RGBW mode (default) | 1 | 1 | HSB mode |
|
23 | Switch / Input Type for IN4 | Choose the input / switch type you want to connect to the IN4 terminal. | 1 | 1 | 0 | 4 | 2 | From | To | Description |
|---|
0 | 0 | analog sensor with no pull-up | 1 | 1 | analog sensor with pull-up | 2 | 2 | momentary switch (default) | 3 | 3 | toggle switch (state changes whenever the switch is toggled) | 4 | 4 | toggle switch (light on when the switch is toggled up, light off when the switch is toggled down) |
|
65 | Energy Report Threshold | Choose how you want your RGBW Dimmer to report energy use (kWh) to your hub. The number entered as value corresponds to decimal values in energy usage change. So if 10 is entered by default, the RGBW Dimmer will report any change in energy use over 0.1 kWh. Energy reports are sent in at least 30-second intervals. | 1 | 2 | 0 | 500 | 10 | From | To | Description |
|---|
0 | 0 | disabled (it will not report energy use based on value change) | 1 | 500 | 0.01 - 5 kWh |
|
151 | Physical Ramp Rate | Adjust the ramp rate for your RGBW dimmer (fade-in / fade-out effect for on / off operation). Values correspond to the number of seconds it take for the dimmer to reach full brightness or turn off when operated from the connected wall switch. | 1 | 2 | 0 | 254 | 3 | From | To | Description |
|---|
0 | 0 | instant on/off | 1 | 127 | seconds | 128 | 254 | 1 - 127 minutes |
|
63 | Analog Sensor Voltage Reporting / Trigger Threshold | Choose how you want your RGBW Dimmer to report voltage changes from the connected analog sensors and trigger status change on the output. The number entered as value corresponds to decimal values in voltage change. So if 5 is entered by default, the RGBW Dimmer will report any change in voltage of the connected sensor over 0.5 V. This setting is only in effect if at least one of Parameters 20 – 23 is set to value 0 or 1 (input is set to analog sensor mode). | 1 | 2 | 0 | 100 | 5 | From | To | Description |
|---|
0 | 0 | disabled (it will not report voltage based on value change) | 1 | 100 | 0.1 – 10 V |
|
154 | Single Click ON Trigger for Associated Devices | Set the status or brightness level triggering other associated devices in your network if the dimmer is turned ON with a single click. Each of the 4 available bytes refers to one channel, starting with IN1 and ending with IN4. This setting applies to basic set and switch multilevel commands sent to associated devices in the appropriate association group. | 1 | 4 | 0 | 255 | 255 | From | To | Description |
|---|
0 | 99 | custom brightness level | 255 | 255 | ON |
|
152 | Z-Wave Ramp Rate | Adjust the ramp rate for your RGBW dimmer when operated remotely from the Z-Wave hub. | 1 | 2 | 0 | 254 | 3 | From | To | Description |
|---|
0 | 0 | instant on/off | 1 | 127 | seconds | 128 | 254 | 1 - 127 minutes |
|
155 | Single Click OFF Trigger for Associated Devices | Set the status or brightness level triggering other associated devices in your network if the dimmer is turned OFF with a single click. Each of the 4 available bytes refers to one channel, starting with IN1 and ending with IN4. This setting applies to basic set and switch multilevel commands sent to associated devices in the appropriate association group. | 1 | 4 | 0 | 255 | 0 | From | To | Description |
|---|
0 | 99 | custom brightness level | 255 | 255 | ON |
|
157 | Preset Programs | Enable one of the preset animated color programs to set the mood with a click. | 1 | 1 | 0 | 10 | 0 | From | To | Description |
|---|
0 | 0 | preset programs disabled (default) | 6 | 6 | fireplace | 7 | 7 | storm | 8 | 8 | rainbow | 9 | 9 | polar lights | 10 | 10 | police (strobing red, white, and blue) |
|
