COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4

Firmware Update Meta-Data V4

0x7A

4

COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_SWITCH_BINARY

Switch Binary

0x25

1

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_CONFIGURATION

Configuration

0x70

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_TRANSPORT_SERVICE_V2

Transport Service V2

0x55

2

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_SWITCH_MULTILEVEL_V3

Switch Multilevel V3

0x26

3

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_METER_V3

Meter V3

0x32

3

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_SECURITY_2

Security S2

0x9F

1

COMMAND_CLASS_SUPERVISION

Supervision

0x6C

1

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

Manual_Primary_Lang

Product or Owner's Manual

Firmware Updatable

Supported Meter Type

Window Covering Control Features

1

1

0

Z-Wave Plus Lifeline

2

External switch Protection

External switch Protection: 0: Enable external switch 1: Disable external switch

0

1

0

0

0

3

When the door is opened, set the delay time for automatic closing.

When the door is opened, set the delay time for automatic closing. 0: Disable automatic closing 1 - 32767: The door will be closed automatically in 1 - 32767sec

0

2

0

0

0

1

Positioning Calibration

Positioning Calibration: 0: Disable 1: Executing calibration

0

1

0

0

0

4

When the door is open, set the delay time for automatic notification

When the door is open, set the delay time for automatic notification 0: Disable automatic notification 1 - 32767: The notification will be sent automatically in 1 - 32767sec

0

2

0

0

0

5

Set the operation mode

Set the operation mode: 0: Roller Shutter 1: Venetian (up/down and slate rotation)

0

1

0

0

0

6

Set the angle of blinds

Angles of blinds 0：0∘ 1：30∘ 2：60∘ 3：90∘ 4：120∘ 5：150∘ 6：180∘

0

1

0

0

0

8

Set the delay time to start the motor up to the blade

Set the delay time to start the motor up to the blade: 0: No offset time 1 - 127: 0.1 - 12.7 sec

0

1

0

0

0

9

Set the delay time to start the motor down to the blade

Set the delay time to start the motor down to the blade. 0: No offset time 1 - 127: 0.1 – 12.7 sec

0

1

0

0

0

10

Set the power changed percentage to send the power report

Set the power changed percentage to send the power report. 0: Disabled 1 - 100: 1% - 100%

0

1

0

0

0

11

Set the time interval of reporting watts in seconds

Set the time interval of reporting watts in seconds. 0: Disable 60 - 32767: 60 - 32767sec

0

2

0

0

300

1

Inclusion

1. Put the Z-Wave Controller into inclusion mode, and press the pairing button 3 times in 2 seconds to include the module. 2. Put the Z-Wave Controller into inclusion mode, and press the “external swtich1” or “external swtich2” 3 times in 2 seconds to include the module.

2

Exclusion

1. Put the Z-Wave Controller into exclusion mode, and press the pairing button 3 times in 2 seconds to exclude the device. 2. Put the Z-Wave Controller into inclusion mode, and press the “external swtich1” or “external swtich2” 3 times in 2 seconds to include the module.

5

Factory Reset

1. Press the pairing button 3 times in 2 seconds and press and hold the pairing button for more than 5 seconds at the 3rd time. 2. The module is excluded and restores to factory default setting. 3. Then the module will be in auto-inclusion mode for 2 minutes. Please use this procedure only when the network primary controller is missing or otherwise inoperable.

Electric meter

Import

Electric Meter Consumption
