COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_PROTECTION_V2

Protection V2

0x75

2

COMMAND_CLASS_APPLICATION_STATUS

Application Status

0x22

1

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_CONFIGURATION

Configuration

0x70

1

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3

Multi Channel Association V3

0x8E

3

COMMAND_CLASS_SECURITY_2

Security 2

0x9F

1

COMMAND_CLASS_CRC_16_ENCAP

CRC-16 Encapsulation

0x56

1

COMMAND_CLASS_SECURITY

Security 0

0x98

1

COMMAND_CLASS_MULTI_CHANNEL_V4

Multi Channel V4

0x60

4

COMMAND_CLASS_SENSOR_MULTILEVEL_V11

Multilevel Sensor V11

0x31

11

COMMAND_CLASS_TRANSPORT_SERVICE_V2

Transport Service V2

0x55

2

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_SWITCH_BINARY

Binary Switch

0x25

1

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4

Firmware Update Meta Data V4

0x7A

4

COMMAND_CLASS_NOTIFICATION_V8

Notification V8

0x71

8

COMMAND_CLASS_CENTRAL_SCENE_V3

Central Scene V3

0x5B

3

COMMAND_CLASS_SUPERVISION

Supervision

0x6C

1

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

COMMAND_CLASS_ASSOCIATION_GRP_INFO_V2

Association Group Information V2

0x59

2

COMMAND_CLASS_BASIC

Basic

0x20

1

Manual_Primary_Lang

Product Manual

1

1

0

Lifeline

0x0001

“Lifeline” reports the device status and allows for assigning single device only (main controller by default).

2

5

0

On/Off (IN1)

0x2001

“On/Off (IN1)” is assigned to IN1 input terminal (uses Basic command class).

3

5

0

On/Off (IN2)

0x2002

“On/Off (IN2)” is assigned to IN2 input terminal (uses Basic command class).

5

Input 1 - sent scenes

This parameter defines which actions result in sending scene ID and attribute assigned to them (see 9: Activating scenes). Parameter is relevant only if parameter 20 is set to 2 or 3.

1

1

0

8

0

7

Input 1 - value sent to 2nd association group when activated

This parameter defines value sent to devices in 2nd association group when IN1 input is triggered (using Basic Command Class). Parameter is relevant only if parameter 20 is set to 0 or 1 (alarm mode).

1

2

0

255

255

8

Input 1 - value sent to 2nd association group when deactivated

This parameter defines value sent to devices in 2nd association group when IN1 input is deactivated (using Basic Command Class). Parameter is relevant only if parameter 20 is set to 0 or 1 (alarm mode).

1

2

0

255

0

9

Input 2 - value sent to 3rd association group when activated

This parameter defines value sent to devices in 3rd association group when IN2 input is triggered (using Basic Command Class). Parameter is relevant only if parameter 21 is set to 0 or 1 (alarm mode).

1

2

0

255

255

1

Input 1 - operating mode

This parameter allows to choose mode of 1st input (IN1). Change it depending on connected device.

1

1

0

5

2

2

Input 2 - operating mode

This parameter allows to choose mode of 2nd input (IN2). Change it depending on connected device.

1

1

0

5

2

3

Inputs orientation

This parameter allows reversing operation of IN1 and IN2 inputs without changing the wiring. Use in case of incorrect wiring.

1

1

0

1

0

4

Outputs orientation

This parameter allows reversing operation of OUT1 and OUT2 inputs without changing the wiring. Use in case of incorrect wiring.

1

1

0

1

0

6

Input 2 - sent scenes

This parameter defines which actions result in sending scene ID and attribute assigned to them (see 9: Activating scenes). Parameter is relevant only if parameter 21 is set to 2 or 3.

1

1

0

8

0

10

Input 2 - value sent to 3rd association group when deactivated

This parameter defines value sent to devices in 3rd association group when IN2 input is deactivated (using Basic Command Class). Parameter is relevant only if parameter 21 is set to 0 or 1 (alarm mode).

1

2

0

255

10

11

Input 1 - sensitivity

This parameter defines the inertia time of IN1 input in alarm modes. Adjust this parameter to prevent bouncing or signal disruptions. Parameter is relevant only if parameter 20 is set to 0 or 1 (alarm mode).

1

2

1

100

60

17

Output 1 - auto off

This parameter defines time after which OUT1 will be automatically deactivated.

1

2

0

27000

0

23

External sensors - minimal change to report

This parameter defines minimal change (from the last reported) of external sensors values (DS18B20 or DHT22) that results in sending new report. Parameter is relevant only for connected DS18B20 or DHT22 sensors.

1

2

0

255

5

24

External sensors - periodical reports

This parameter defines reporting period of analog inputs value. Periodical reports are independent from changes in value (parameter 67). Parameter is relevant only for connected DS18B20 or DHT22 sensors.

1

2

0

32400

0

8

Where to find S2 DSK on product

You can find QR Code on product label which is located on device

2

Classic Exclusion

To remove the device from the Z-Wave network: 1. Power the device. 2. Set the main controller into remove mode (see the controller’s manual). 3. Quickly, triple click button on the device housing or switch connected to IN1 or IN2. 4. LED will start blinking yellow, wait for the removing process to end. 5. Successful removing will be confirmed by the Z-Wave controller’s message

5

Factory Reset Procedure

7.4 - Resetting to factory defaults Reset procedure allows to restore the device back to its factory settings, which means all information about the Z-Wave controller and user configuration will be deleted. Note. Resetting the device is not the recommended way of removing the device from the Z-Wave network. Use reset procedure only if the primary controller is missing or inoperable. Certain device removal can be achieved by the procedure of removing described. 1. Press and hold the button to enter the menu. 2. Release button when the device glows yellow. 3. Quickly click the button to confirm. 4. After few seconds the device will be restarted, which is signalled with the red colour

1

Classic Inclusion

5.1 - Adding manually To add the device to the Z-Wave network manually: 1. Power the device. 2. Set the main controller in (Security/non-Security Mode) add mode (see the controller’s manual). 3. Quickly, triple click button on the device housing or switch connected to IN1 or IN2. 4. If you are adding in Security S2 Authenticated, scan the DSK QR code or input the 5-digit PIN code (label on the bottom of the box). 5. LED will start blinking yellow, wait for the adding process to end. 6. Successful adding will be confirmed by the Z-Wave controller’s message.

Home Security

Sensor status: Intrusion

System

HW status: System hardware failure

System

HW status: System hardware failure (manufacturer proprietary failure code provided)

Power
