| 1 | Standby Power setting and function enable/disable | Total 4 byte : 3 byte + 1 byte - 3 Byte : Standby Power Setting ( 0x000000 (0.00 Watt) ~ 0x493E0 (3000.00 Watt) ) - 1 Byte : Standby Power Function Enable/Disable ( 0x00 or 0x01) Default - 3 byte : 0.00W( 0x000000) / 1byte : 0 (0x00) For example, if Standby Power Function is "Enable" and the usage of Electricity is over the Standby Power Setting value, “Smart Plug” cut off the power Supply. | 0 | 4 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 3000 | 0.00 Watt ~ 3000.00 Watt |
|
| 2 | Periodic Measurement Value Transmission | Start or Stop for the periodically measured value transmission of the Power usage Default : 1 (0x01) - Function Enable Value - 0 (0x00) : Disable - 1 (0x01) : Enable | 0 | 1 | 0 | 0 | 1 | | From | To | Description |
|---|
| 0 | 1 | Disale/Enable |
|
| 3 | Start / Stop Power accumulation Usage Calculation | Start / Stop Power accumulation Usage Calculation Default : 1 (0x01) - Function Enable Value - 0 (0x00) : Disable(Stop) - 1 (0x01) : Enable(Start) Enable / Disable | 0 | 1 | 0 | 0 | 1 | | From | To | Description |
|---|
| 0 | 1 | Disable/Enable |
|
| 4 | Report when the connected Device is being used or not. | Report when the connected Device is being used or not. (User can know the Device's using status) Default : 1 (0x00) - Function Disable Value - 0 (0x00) : Disable(Stop) - 1 (0x01) : Enable(Start) ※ if not set up the standby power, it does not function. | 0 | 1 | 0 | 0 | 1 | | From | To | Description |
|---|
| 0 | 1 | Disable/Enable |
|
| 5 | This sets the periodic measurement value transmission rate. | This sets the periodic measurement value transmission rate. The rate set is in increments of 10 minutes. For example, if setting value = 2, Transmission Time interval = 2 * 10 = 20 minutes. Default : 6 ( 60min ) Value - 1(0x01) : 10 min ~ 144 (0x90) : 1440 min | 0 | 1 | 0 | 0 | 6 | | From | To | Description |
|---|
| 1 | 144 | 10min~1440min |
|
