101 | To set which report need to be sent. | This parameter is used to configure which reports need to be sent in Report Group 1. The values corresponding to the first four bits of the parameter value may be combined to create different combinations of reports that you wish to have sent. For example, instantaneous Current is the value 2 and instantaneous Watts is the value 4, so setting parameter 101 to a value of 6 will result in both instantaneous Current and instantaneous Watts to be reported. See the full description of the parameter values for other possible settings. | 0 | 4 | 0 | 0 | 4 | From | To | Description |
|---|
8 | 8 | Report Accumulated kWh | 2 | 2 | Report Instantaneous Current (Amperes) | 4 | 4 | Report Instantaneous Watts | 1 | 1 | Report Instantaneous Voltage |
|
90 | Enable/Disable the function of parameter 91 and 92. | This parameter is used to Enable/Disable the function of parameter 91 and 92 (1=Enabled, 0=Disabled). | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | Configuration Parameters 91 and 92 are Disabled | 1 | 1 | Configuration Parameters 91 and 92 are Enabled |
|
3 | Current Overload Protection | This parameter is used for the overload protection, which means the load will be disconnected after 2 minutes when the current more than 16.2A. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Overload Protection Disabled | 1 | 1 | Overload Protection is Enabled |
|
92 | Induce an automatic report | This parameter is used to induce an automatic report when the change of the current power is more/less than the threshold in percentage. | 0 | 1 | 0 | 0 | 5 | From | To | Description |
|---|
0 | 100 | The threshold can be set from 0 to 100 percent. |
|
111 | Set the interval time of sending report. | This parameter is used to set the interval time of sending report in Report Group 1. (The unit of time is second). | 0 | 4 | 0 | 0 | 300 | From | To | Description |
|---|
0 | 268435456 | Interval Seconds |
|
112 | Set the interval time of sending report. | This parameter is used to set the interval time of sending report in Report Group 2. (The unit of time is second). | 0 | 4 | 0 | 0 | 600 | From | To | Description |
|---|
0 | 268435456 | Interval Seconds |
|
113 | Set the interval time of sending report. | This parameter is used to set the interval time of sending report in Report Group 3. (The unit of time is second). | 0 | 4 | 0 | 0 | 600 | From | To | Description |
|---|
0 | 268435456 | Interval Seconds |
|
252 | Enable/Disable Lock Configuration | This parameter is used to enable/disable Lock all configuration parameters. (0 =disable, 1 = enable) | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | All configuration parameters are configurable. | 1 | 1 | All configuration parameters are not configurable (Locked). |
|
254 | Device Tag | This parameter is used to save the device tag, which will be written/ assigned in factory/ manufacturer. | 0 | 2 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 32767 | Device Tag |
|
255 | Reset to default factory setting | This parameter is used to reset product to default factory setting. (There are just 2 values can be used). | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
1431655765 | 1431655765 | Reset the product to default factory setting and be excluded from the Z-wave network. | 1 | 1 | Resets all configuration parameters to default setting. |
|
102 | To set which report need to be sent. | This parameter is used to configure which reports need to be sent in Report Group 2. The values corresponding to the first four bits of the parameter value may be combined to create different combinations of reports that you wish to have sent. For example, instantaneous Current is the value 2 and instantaneous Watts is the value 4, so setting parameter 102 to a value of 6 will result in both instantaneous Current and instantaneous Watts to be reported. See the full description of the parameter values for other possible settings. | 0 | 4 | 0 | 0 | 8 | From | To | Description |
|---|
4 | 4 | Report Instantaneous Watts | 8 | 8 | Report Accumulated kWh | 1 | 1 | Report Instantaneous Voltage | 2 | 2 | Report Instantaneous Current (Amperes) |
|
103 | To set which report need to be sent. | This parameter is used to configure which reports need to be sent in Report Group 3. The values corresponding to the first four bits of the parameter value may be combined to create different combinations of reports that you wish to have sent. For example, instantaneous Current is the value 2 and instantaneous Watts is the value 4, so setting parameter 103 to a value of 6 will result in both instantaneous Current and instantaneous Watts to be reported. See the full description of the parameter values for other possible settings. | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
1 | 1 | Report Instantaneous Voltage | 2 | 2 | Report Instantaneous Current (Amperes) | 4 | 4 | Report Instantaneous Watts | 8 | 8 | Report Accumulated kWh |
|
200 | Partner ID | This parameter is used to configure the partner ID. (0== Aeon Labs Standard Product, 1~255== others). | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Aeon Labs Standard Product | 1 | 255 | Partner ID of Partner Product |
|
2 | Make Smart Switch blink | This parameter is used for customer to control the product’s load (e. g incandescent light) to blink with a certain time when you set this parameter and send this command to the load. | 0 | 2 | 0 | 0 | 3850 | From | To | Description |
|---|
0 | 255 | Specify the time that Smart Switch should blink, in seconds. | 256 | 32767 | Specifies the cycle of on/off, the unit of it is 0.1 second. |
|
91 | Induce an automatic report | This parameter is used to induce an automatic report when the change of the current power is more/less than the threshold in wattage. | 0 | 2 | 0 | 0 | 25 | From | To | Description |
|---|
0 | 32767 | The threshold can be set from 0 to 32767 watt. |
|
80 | Enable/Disable to send notifications to associated devices to associated devices. | This parameter is used to Enable/Disable to send notifications to associated devices (in Group 1) when the state of Smart Switch Gen5’s load is changed. (0=Send nothing, 1=Send hail CC, 2=Send basic report CC). | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Send Nothing (Disabled) | 1 | 1 | Send HAIL Command | 2 | 2 | Send BASIC Report Command |
|
