43 | Outdoor Temperature Timeout | Number of minutes before the outdoor timeout is considered timed out. This parameter is used for balance point. | 0 | 2 | 0 | 0 | 1440 | From | To | Description |
|---|
0 | 32767 | Minutes |
|
58 | Relay Harvest Interval | | 0 | 1 | 0 | 0 | 4 | From | To | Description |
|---|
0 | 0 | Off | 2 | 2 | 4 Milliseconds | 3 | 3 | 8 Milliseconds | 5 | 5 | 32 Milliseconds | 4 | 4 | 16 Milliseconds |
|
59 | Minimum Battery Reporting Interval | | 0 | 1 | 0 | 0 | 6 | From | To | Description |
|---|
0 | 127 | Hours |
|
25 | Configurable Terminal Settings | Control the function of the configurable terminals, Z1 and Z2. Z1 is the first byte. Z2 is the second byte. | 0 | 2 | 0 | 0 | 0 | From | To | Description |
|---|
1 | 1 | W3 | 2 | 2 | Humidifier | 0 | 0 | None | 3 | 3 | Dehumidifier |
|
4 | Heat Fuel Type | Fuel type of heat source. | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | Fossil | 1 | 1 | Electric |
|
1 | HVAC Type | HVAC System Type | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
1 | 1 | Heat Pump | 0 | 0 | Normal |
|
2 | Number of Heat Stages | Number of heat stages if normal or the number of auxiliary heat stages if heat pump | 0 | 1 | 0 | 0 | 2 | From | To | Description |
|---|
0 | 3 | Number of Heat Stages |
|
3 | Number of Cool Stages | Number of cool stages if normal or the number of heat pump stages if heat pump | 0 | 1 | 0 | 0 | 2 | From | To | Description |
|---|
0 | 2 | Number of Cool Stages |
|
17 | Maximum Cool Setpoint | NOTE: Temperature parameters take the form of 4-byte Z-Wave temperature commands where byte 1 is the (precision|scale|size) and bytes 2 and 3 are the 16-bit signed temperature value. Byte 4 is unused. | 0 | 4 | 0 | 0 | 95 | From | To | Description |
|---|
50 | 95 | Maximum Cool Setpoint |
|
23 | Temperature Display Units | | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | Celsius | 1 | 1 | Fahrenheit |
|
41 | Remote Temperature ACK Failure Limit | If the thermostat fails to get an acknowledges for the specified value, it will revert to the local thermistor. | 0 | 1 | 0 | 0 | 3 | From | To | Description |
|---|
0 | 127 | Retries |
|
42 | Remote Temperature Display Enable | If enabled thermostat will show remote temperature on the UI. If disabled the thermostat will show the local temperature on the UI. | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | Disabled | 1 | 1 | Enabled |
|
46 | Dehumidify by AC Offset | The thermostat can use the AC to dehumidify. If the ambient temperature is within the offset and the relative humidity is above the dehumidify setpoint, the thermostat will use the AC to dehumidify. | 0 | 4 | 0 | 0 | 3 | From | To | Description |
|---|
0 | 10 | Farhenheit |
|
48 | PIR Enable | If enabled, the thermostat will wake up the screen when motion is detected. This feature is only available when the thermostat is powered by C-Wire. | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | Disabled | 1 | 1 | Enabled |
|
49 | Display Options | Bitmask to control various display features. - Bit 0 - Display humidity along with setpoint when not in off mode. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Do not show Humidity | 1 | 1 | Show Humidity |
|
50 | System Configuration | Read Only System Configuration | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
-2147483648 | 2147483647 | No Change - Read-Only Parameter |
|
51 | Thermostat Reset | Remote reset of the thermostat. Must write the magic value (0x03B6). This is the same as power cycling the thermostat. It does not reset any parameters. | 0 | 2 | 0 | 0 | 2870 | From | To | Description |
|---|
2870 | 2870 | Magic Value |
|
52 | Vent Options | | 0 | 1 | 0 | 0 | 4 | From | To | Description |
|---|
0 | 0 | Disabled | 3 | 3 | Only activate vent when the thermostat operating state is cooling | 4 | 4 | Only activate vent when the thermostat operating state is heating or cooling | 2 | 2 | Only activate vent when the thermostat operating state is heating. | 1 | 1 | Always activate regardless of thermostat operating state |
|
53 | Vent Circulation Period | | 0 | 2 | 0 | 0 | 60 | From | To | Description |
|---|
0 | 0 | Disabled | 10 | 1440 | Minutes |
|
54 | Vent Circulation Duty Cycle | | 0 | 1 | 0 | 0 | 25 | From | To | Description |
|---|
0 | 100 | Duty Cycle |
|
55 | Vent Maximum Outdoor Temperature | Vent is disabled if outdoor temperature exceeds this value. Setting this value to -1 disables the limit. | 0 | 4 | 0 | 0 | -1 | From | To | Description |
|---|
-1 | -1 | Disabled | 0 | 99 | Fahrenheit |
|
56 | Vent Minimum Outdoor Temperature | Vent is disabled if outdoor temperature exceeds this value. Setting this value to -1 disables the limit. | 0 | 4 | 0 | 0 | -1 | From | To | Description |
|---|
-1 | -1 | Disabled | 0 | 99 | Fahrenheit |
|
60 | Humidity Control Swing | | 0 | 1 | 0 | 0 | 5 | From | To | Description |
|---|
1 | 100 | Percent Relative Humidity |
|
62 | Z-Wave Send Fail Limit | If thermostat experiences successive Z-Wave Transmit ACK failures exceeding the limit, the thermostat will not attempt any more unsolicited association reports until it receives a successful acknowledge for an association report. If this value is zero, the ACK failure limit is disabled. | 0 | 1 | 0 | 0 | 10 | From | To | Description |
|---|
0 | 0 | Disabled | 1 | 127 | Send Failures |
|
63 | Z-Wave Listen Before Talk Threshold | Set the listen before talk threshold on the thermostat. The threshold controls at what RSSI level the Z-Wave radio will refuse to transmit because of noise. Each step corresponds to a 1.5dB power step. Byte 0 is the LBT threshold for channel 0 and Byte 1 is the LBT threshold for channel 1. | 0 | 2 | 0 | 0 | 2046 | From | To | Description |
|---|
0 | 32767 | Listen before talk threshold |
|
61 | Minimum Humidity Reporting Threshold | | 0 | 1 | 0 | 0 | 5 | From | To | Description |
|---|
0 | 100 | Percent Relative Humidity |
|
65 | Humidify Options | | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | Always humidify regardless of thermostat operating state | 1 | 1 | Only humidify when the thermostat operating state is heating, when in heat mode, or when heating in auto mode. When the thermostat is in any other mode, the thermostat will humidify whenever it is necessary. |
|
45 | Heat Pump Expire | Number of minutes of running heat pump before the thermostat turns off the heat pump and only uses auxiliary heat. Setting this value to zero will disable the expiry. | 0 | 2 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 2880 | Minutes |
|
5 | Calibration Temp | Used to adjust the ambient room temperature reading up or down to a more accurate value. NOTE: Temperature parameters take the form of 4-byte Z-Wave temperature commands where byte 1 is the (precision|scale|size) and bytes 2 and 3 are the 16-bit signed temperature value. Byte 4 is unused. | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
-10 | 10 | Calibration Temperature |
|
