COMMAND_CLASS_NO_OPERATION

No Operation

0x00

1

COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_APPLICATION_STATUS

Application Status

0x22

1

COMMAND_CLASS_CRC_16_ENCAP

CRC16 Encapsulation

0x56

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

COMMAND_CLASS_SENSOR_MULTILEVEL_V5

Sensor Multilevel V5

0x31

5

COMMAND_CLASS_THERMOSTAT_OPERATING_STATE_V2

Thermostat Operating State V2

0x42

2

COMMAND_CLASS_DOOR_LOCK_V2

Door Lock V2

0x62

2

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3

Multi-Channel Association V3

0x8E

3

COMMAND_CLASS_BATTERY

Battery

0x80

1

COMMAND_CLASS_SWITCH_BINARY

Switch Binary

0x25

1

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_CRC_16_ENCAP

CRC16 Encapsulation

0x56

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_SENSOR_BINARY_V2

Sensor Binary V2

0x30

2

COMMAND_CLASS_THERMOSTAT_FAN_MODE_V3

Thermostat Fan Mode V3

0x44

3

COMMAND_CLASS_THERMOSTAT_FAN_STATE_V2

Thermostat Fan State V2

0x45

2

COMMAND_CLASS_THERMOSTAT_MODE_V2

Thermostat Mode V2

0x40

2

COMMAND_CLASS_THERMOSTAT_SETPOINT_V2

Thermostat Setpoint V2

0x43

2

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_WAKE_UP_V2

Wake Up V2

0x84

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_BARRIER_OPERATOR

Barrier Operator

0x66

1

COMMAND_CLASS_SWITCH_MULTILEVEL_V3

Switch Multilevel V3

0x26

3

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_METER_V3

Meter V3

0x32

3

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_MULTI_CHANNEL_V4

Multi-Channel V4

0x60

4

COMMAND_CLASS_SWITCH_COLOR_V2

Switch Color V2

0x33

2

COMMAND_CLASS_NOTIFICATION_V5

Notification V5

0x71

5

COMMAND_CLASS_CONFIGURATION_V2

Configuration V2

0x70

2

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

Manual_Primary_Lang

Product or Owner's Manual

Gateway Has Preferred Partners

Sensors

Supported Notification Types

Z-Wave Scene Type

Color

Communications Connections

Controller Supports Multiple Networks

Controller Supports Multiple Z-Wave Interfaces

Firmware Updatable

1

4

0

Z-Wave Plus Lifeline

23

Controller Inclusion

To Include/Add a Z-Wave device: 1 On the dashboard, tap Add device. 2 Tap under ADD DEVICE MANUALLY. 3 Select a category of the device to register. Alternatively, enter the device’s name in the search input field and tap ADD next to your device. 4 Follow the on-screen instructions to complete the registration. • The Samsung SmartThings Hub feature may not be available depending on the region. Visit www.samsung.com for details. • Refer to the other devices’ user manuals for instructions on how to pair with them. • To learn more about the Samsung SmartThings Hub feature, visit support.smartthings.com.

24

Controller Exclusion

To Exclude/Remove a Z-Wave device: 1 On the SmartThings screen, tap Devices. 2 Tap ALL DEVICES and scroll up or down to select a location. 3 Tap  → Edit and use the following options. REMOVE a Device:Remove a Device. If you reset the Wi-Fi hub, you should exclude the Z-Wave device and reconnect (re-include) it. For instructions on how to put the Z-Wave device into Exclusion Mode, please refer to the device manufacturer's user manual.

3

Learn Mode (adding another controller)

Because the Hub is a certified Z-Wave device, you can add it to another Z-Wave network. Note that adding a Hub to a different Z-Wave network will disconnect it from any previously connected Z-Wave devices, and they will have to be put through the exclusion process before being added to the network again. SmartThings strongly discourages adding the Hub to another Z-Wave network. We cannot offer support for disconnected Z-Wave devices or the inability to add devices through the Hub as a result of including the Hub into another Z-Wave network. Here are the steps to put the Hub into learn mode to receive network information from another Z-Wave controller: 1 Prepare the other Z-Wave controller to copy its network information to the Hub. This may be called include, add, transfer, copy, or replicate mode 2 In the SmartThings app, Tap the menu 3 Tap the Devices 4 Tap SmartThigns hub Card 5 Tap Include or Exclude Hub from an Existing Z-Wave Network This will start learn mode on the Hub. It may take longer to receive all the network info and load all the devices. Check the other controller for confirmation of whether the transfer was successful.

5

Factory Reset

If the Wi-Fi hub freezes or hangs, disconnect the adapter from the Wi-Fi hub and reconnect it. Close the SmartThings app completely on your mobile device and restart it. If your Wi-Fi hub is frozen and unresponsive, insert a pin into the Reset hole for more than 8 seconds. If the tips above do not solve the problem, contact a Samsung Service Center. If this controller is the primary controller for your network, resetting it will result in the nodes in your network being orphaned and it will be necessary after the reset to exclude and re-include all of the nodes in the network. If this controller is being used as a secondary controller in the network, use this procedure to reset this controller only in the event that the network primary controller is missing or otherwise inoperable
