Product Recognition
Certification Number	ZC10-16105267
Name	SS302-KR
Short Description	SS302 is an USB dongle which connects to the OTG port of any Android host device. It turns the Android device into a Z-Wave controller.
Long Description	SS302 is an USB dongle which connects to the OTG port of any Android host device. It turns the Android device into a Z-Wave controller.
Brand	Enblink
Product Identifier	SS302-KR
OEM Version	HW: 1 FW: 1.00
Hardware Platform	ZM5101
Z-Wave Version	6.51.06
Library Type	CONTROLLER_STATIC
Device Type	Central Controller
Role Type	ROLE_TYPE_CONTROLLER_CENTRAL_STATIC
Manufacturer ID	0x014D
Product Type ID	0x0003
Product ID	0x0302
User Icon	0x0100
Installer Icon	0x0100
Frequency Plans	KR: 920.90MHz, 921.70MHz, 923.10MHz
Categories	All Controllers, Computer Controller Interfaces
Countries / Regions	Republic of Korea
Controlled Command Classes	Identifier Name Key Version COMMAND_CLASS_USER_CODE User Code 0x63 1 COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3 Multi-Channel Association V3 0x8E 3 COMMAND_CLASS_TIME_PARAMETERS Time Parameters 0x8B 1 COMMAND_CLASS_CRC_16_ENCAP CRC16 Encapsulation 0x56 1 COMMAND_CLASS_SECURITY Security S0 0x98 1 COMMAND_CLASS_VERSION_V2 Version V2 0x86 2 COMMAND_CLASS_ASSOCIATION_V2 Association V2 0x85 2 COMMAND_CLASS_MULTI_CHANNEL_V4 Multi-Channel V4 0x60 4 COMMAND_CLASS_MANUFACTURER_SPECIFIC Manufacturer Specific 0x72 1 COMMAND_CLASS_SCHEDULE_ENTRY_LOCK_V2 Schedule Entry Lock V2 0x4E 2
Documents	Category Description File Manual_Primary_Lang Product or Owner's Manual Manual.pdf
Features	Feature Values Color Value White Communications Connections Value USB (Universal Serial Bus)
Association Groups	Group Number Maximum Nodes Supported End Point ID Description 1 5 0 Z-Wave Plus Lifeline
Texts	ID Description Value 3 Learn Mode (adding another controller) In setting app, enter into following menu. ""Advanced Z-Wave > Join/Leave"" 23 Controller Inclusion In mobile app, enter into following menu. ""PhoneApp > Device Management > Menu (Inclusion) > Z-Wave"" 24 Controller Exclusion In mobile app, enter into following menu. ""PhoneApp > Device Management > Menu (RESET)"" 5 Factory Reset In setting app, enter into following menu. ""About Enblink > Factory reset"". If this controller is the primary controller for your network, resetting it will result in the nodes in your network being orphaned and it will be necessary after the reset to exclude and re-include all of the nodes in the network. If this controller is being used as a secondary controller in the network, use this procedure to reset this controller only in the event that the network primary controller is missing or otherwise inoperable.
Supports NWI	Yes
Supports Explorer Frames	Yes
