COMMAND_CLASS_SENSOR_MULTILEVEL_V5

Sensor Multilevel V5

0x31

5

COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_THERMOSTAT_FAN_MODE

Thermostat Fan Mode

0x44

1

COMMAND_CLASS_THERMOSTAT_OPERATING_STATE_V2

Thermostat Operating State V2

0x42

2

COMMAND_CLASS_BATTERY

Battery

0x80

1

COMMAND_CLASS_THERMOSTAT_FAN_STATE

Thermostat Fan State

0x45

1

COMMAND_CLASS_BASIC

Basic

0x20

1

COMMAND_CLASS_THERMOSTAT_MODE_V3

Thermostat Mode V3

0x40

3

COMMAND_CLASS_THERMOSTAT_SETPOINT_V3

Thermostat Setpoint V3

0x43

3

COMMAND_CLASS_TRANSPORT_SERVICE_V2

Transport Service V2

0x55

2

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_SECURITY_2

Security S2

0x9F

1

COMMAND_CLASS_SUPERVISION

Supervision

0x6C

1

COMMAND_CLASS_CONFIGURATION_V2

Configuration V2

0x70

2

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V3

Firmware Update Meta-Data V3

0x7A

3

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

COMMAND_CLASS_MULTI_CMD

Multi-Command

0x8F

1

COMMAND_CLASS_ANTITHEFT_V2

Anti-Theft V2

0x5D

2

Adv_Manual

Advanced Information Product Manual

Manual_Primary_Lang

Product Installation and Operation Guide

Battery Type

Battery Quantity

Firmware Updatable

Thermostat HVAC Systems Supported

Thermostat Modes

Thermostat Power Source

1

5

0

Lifeline

0x0001

Z-Wave Lifeline

4

5

0

Heat Control

0x2002

A basic set of 0xFF is sent out when a heat call starts and 0x00 is sent when a heat call ends.

2

5

0

Heat Control

0x2002

A basic set of 0xFF is sent out when a cool call starts and 0x00 is sent when a cool call ends.

11

H Delta Stage 1 ON

The amount of degrees from the heat setpoint that will trigger the stage 1 heat to turn on.

1

1

1

6

1

43

Remote Sensor 1 Node Number

Used to set the node ID for the remote sensor you want to use temperature from.

1

2

0

255

0

3

Change Over Type

Select whether your change over valve switches with heat or with cool call.

1

1

0

1

0

174

CPU Runtime

Used for reading out the number of seconds the CPU has been running when on battery.

1

4

0

1073741823

0

46

Parameter 25

Used to read out the last known temperature sent to us from the node set in configuration parameter 43.

1

1

0

127

0

48

Internal Sensor Temp Offset

Used to set a calibration offset to the internal temperature sensor.

1

1

-7

7

0

49

R1 Sensor Temp Offset

Used to set a calibration offset to the remote temperature sensor.

1

1

-7

7

0

171

Number of Heat Call Starts

Used for reading out the number of heat calls that have started.

1

4

0

1073741823

0

172

Number of Cool Call Starts

Used for reading out the number of cool calls that have started.

1

4

0

1073741823

0

173

Reboot Count

Used for reading out the number of times the thermostat has rebooted.

1

4

0

1073741823

0

175

Autosend Wakeup Count

Used for reading out the number of times the thermostat has woken up to send autosends.

1

4

0

1073741823

0

179

Battery Bank Voltage

Returns the current measured remaining battery level as a percentage.

1

1

0

100

0

4

2nd Stage Heat Enable

Enable if your system has a second heat stage.

1

1

0

1

0

5

Aux Heat Enable

Enable if your system has an auxillary heat stage.

1

1

0

1

1

1

System Type

Used to select the HVAC system.

1

1

0

1

0

2

Fan Type

Select the fan type that your HVAC system has.

1

1

0

1

0

6

2nd Stage Cool Enable

Enable if your system has a second cool stage.

1

1

0

1

0

7

C/F Type

Used to put the thermostat in Celsius or Fahrenheit mode.

1

1

0

1

1

8

MOT

Used to set the Minimum Off Time that the heat pump compressor must be off before starting another call.

1

1

5

9

5

9

MRT

Used to set the Minimum Run Time that the heat pump compressor must be on before ending a call.

1

1

3

9

3

17

C Delta Stage 1 ON

The amount of degrees from the cool setpoint that will trigger the stage 1 cool to turn on.

1

1

1

6

1

24

Display Lock

When set the display is locked.

1

1

0

1

0

170

Send Autosends with ACKs

Used to enable or disable sending the ACK request with an autosend.

1

1

0

1

1

61

Fan Purge Heat

Amount of time to keep fan on after a heat call to blow out the residual heat left in the vents.

1

1

0

90

0

62

Fan Purge Cool

Amount of time to keep fan on after a cool call to blow out the residual cold air left in the vents.

1

1

0

90

0

176

UI Wakeup Count

Used for reading out the number of times the thermostat has been woken up due to a button press.

1

4

0

1073741823

0

181

Battery Stat Shutdown Threshold

Set the percent battery level at which the thermostat will shut itself down.

1

1

0

50

0

222

Runtime Stage 2 Heat

Used for reading out the stage 2 heat runtime in seconds.

1

4

0

1073741823

0

184

Battery Midlevel Indicator Threshold

Set the percent battery level at which the thermostat will indicate mid battery.

1

1

50

80

50

221

Runtime Stage 1 Heat

Used for reading out the stage 1 heat runtime in seconds.

1

4

0

1073741823

0

185

Batter Report Timer

Used to set the amount of days between each battery report.

1

1

0

10

1

225

Runtime Stage 2 Cool

Used for reading out the stage 2 cool runtime in seconds.

1

4

0

1073741823

0

231

Status Display

Used to select what you want to be shown on the status line of the display.

1

1

0

1

1

187

Periodic Temp Send Interval

Used to set how many minutes between temperature report autosends.

1

1

0

120

0

224

Runtime Stage 1 Cool

Used for reading out the stage 1 cool runtime in seconds.

1

4

0

1073741823

0

186

Temp Delta Autosend Threshold

Used to set how many degrees change in temperature from the last autosend before sending another autosend.

1

1

1

5

1

223

Runtime Aux Heat

Used for reading out the aux heat runtime in seconds.

1

4

0

1073741823

0

194

RH Delta Autosend Threshold

Used to set how much change in percent RH from the last autosend before sending another autosend.

1

1

1

50

5

227

Runtime Standby

Used for reading out the Standby time in seconds.

1

4

0

1073741823

0

195

Periodic RH Send Interval

Used to set how many minutes between RH report autosends.

1

1

0

120

0

226

Runtime Fan Only

Used for reading out the fan only runtime in seconds.

1

4

0

1073741823

0

2

Classic Exclusion

Removing the thermostat from a Z-Wave network. It may be necessary to remove and/or reinstall the thermostat from a Z-Wave network if the thermostat has been previously installed on another network. Follow the instructions supplied with your Z-Wave system to remove/uninstall a Z-Wave device. When the system instructs you to press and release the Z-Wave button on the thermostat, follow these steps: 1. Press and hold the FAN button for 3 seconds until the Menu screen is displayed. 2. Press the UP arrow button to scroll to the “ZWAVE” menu. 3. Press “Select” to select the ZWAVE screen. 4. The display will show “REMOVE” in the text line. 5. Press “Select” to perform the remove action. 6. “WAIT” will be displayed in the text line. The remove operation is in process. 7. “SUCCESS” will be display when the reset is completed. 8. Press “Done” to exit back to the thermostat screen. 9. Thermostat is now ready to be added to the wireless network.

4

Wake-Up Procedure

Thermostat Battery Operation: If the thermostat is installed in a Z-Wave network while powered by batteries, it will be enrolled as a Z-Wave FLiRs type device. This is a power saving mode that conserves the batteries by keeping the radio asleep most of the time. However, in this mode, the thermostat does not act as a repeater/router in the Z-Wave network.

8

Where to find S2 DSK on product

The SmartStart QR code can be found on the back of the thermostat, side of the package, or also inserted as an insert card/sticker. The sticker contains the full DSK string. It’s important that if you plan to use DSK that you keep this label in a safe place you’ll remember.

5

Factory Reset Procedure

Factory Reset Please use this procedure only when the Z-Wave Primary Controller is missing or otherwise inoperable. To reset the TBZ500’s Z-Wave parameters to Factory Settings (both Z-Wave and HVAC settings): 1. Remove power from the TBZ500. 2. Restore power to the TBZ500. 3. When “TBZ500” appears on the screen, hold down the MODE and FAN buttons at the same time. 4. Release the buttons when RESET appears on the Status Line. 5. Once the TBZ500 resets the Z-Wave and HVAC settings, a DONE confirmation message will appear on the screen before the thermostat self-reboots.

1

Classic Inclusion

Classic Inclusion 1. Follow the instructions provided with your system for enrolling the thermostat. 2. Press and hold the FAN button on the Thermostat until the screen changes to the Menu screen. 3. Press the UP button until ZWAVE is shown in the Status Display line then press Select. 4. INSTALL should be shown on the status line. 5. When instructed by your system installation to add the thermostat to the network press the “Select” button to install. Wait until SUCCESS or FAILED is shown on the status display. 6. Press Done on the Thermostat to exit the ZWAVE screen. 7. Press Done on the Thermostat again to exit the Menu screen. 8. Once enrolled on your system’s network, continue to follow the instructions provided to complete the enrollment and naming of the thermostat. 9. The indicator should be shown on the Thermostat Main screen indicating the thermostat has successfully been enrolled into the Z-Wave network.

Air temperature

Humidity

Motion Direction
