Product Recognition | |
|---|---|
Certification Number | ZC10-20056913 |
Name | Universal module with 3 In 3 Out |
Short Description | The Universal Module is used to translate wired products into wireless Z-WaveTM protocol, integrating
them into the Z-Wave network of a smarthome environment. It has 3 sets of input terminals and 3 sets of
relay output. |
Long Description | The Universal Module is used to translate wired products into wireless Z-WaveTM protocol, integrating
them into the Z-Wave network of a smarthome environment. It has 3 sets of input terminals and 3 sets of
relay output. Through the Universal Module, the Z-Wave Controller can read the input signal from wired
sensors and control the output of wired actuators. This product can be operated in any Z-Wave network
with other Z-Wave certified devices from other manufactures. All mains operated nodes within the
network will act as repeater regardless of vender to increase reliability of the network. |
Brand | Everspring |
Product Identifier | SA301-1 |
Product Line | Z-Wave Plus 500 Series |
OEM Version | HW: 1 FW: 1.01:00.01 |
Hardware Platform | SD3502 |
Z-Wave Version | 6.81.06 |
Library Type | SLAVE_ENHANCED_232 |
Device Type | Notification Sensor |
Role Type | ROLE_TYPE_SLAVE_ALWAYS_ON |
Manufacturer ID | 0x0060 |
Product Type ID | 0x0016 |
Product ID | 0x0001 |
User Icon | 0x0C07 |
Installer Icon | 0x0C07 |
Frequency Plans | EU: 869.85MHz, 868.40MHz |
Categories | Sensors, All Lighting Devices, On/Off Switches/Devices |
Countries / Regions | European Union |
Supported Command Classes | |
Controlled Command Classes | |
S2 Classes | S2_UNAUTHENTICATED, S2_AUTHENTICATED |
Documents | |
Features | |
Association Groups | |
Configuration Parameters | |
Texts | |
Supported Notification Types | |
Supported Multilevel Sensors | |
Supports NWI | Yes |
Supports Explorer Frames | Yes |
Supports SmartStart | Yes |
Radio Range Z-Wave (m) | 40 |
