Product Recognition | |
|---|
Certification Number | ZC10-20026864 |
|---|
Name | Valves Controller with Water Meter |
|---|
Short Description | This valves controller PAB04 is a security enabled wireless switch, based on Z-Wave Plus technology. Connect PAB04 with an external water meter which can output pulse signals. PAB04 is able to detect instance water flow and the accumulated water. |
|---|
Long Description | This valves controller PAB04 is a security enabled wireless switch, based on Z-Wave Plus technology. Z-Wave Plus TM enabled devices displaying the Z-Wave Plus TM logo can also be used with it regardless of the manufacturer, and can also be used in other manufacturer’s Z-Wave TM enabled networks. Remote On/Off control of the connected valve is possible with other manufacturer’s wireless Controller. Each switch is designed to act as a repeater. Repeaters will re-transmit the RF signal to ensure that the signal is received by its intended destination by routing the signal around obstacles and radio dead spots. Because PAB04 supports Security Command Class, it can learn with Secured controller. Its functionality and supported command classes is identical when included as a secure and non-secure device.
Connect PAB04 with an external water meter which can output pulse signals. PAB04 is able to detect instance water flow and the accumulated water. |
|---|
Brand | Philio |
|---|
Product Identifier | PAB04-1 |
|---|
Product Line | Philio Z-Wave Products |
|---|
OEM Version | HW: 1 FW: 1.01 |
|---|
Hardware Platform | SD3502 |
|---|
Z-Wave Version | 6.81.03 |
|---|
Library Type | SLAVE_ENHANCED_232 |
|---|
Device Type | On/Off Power Switch |
|---|
Role Type | ROLE_TYPE_SLAVE_ALWAYS_ON |
|---|
Manufacturer ID | 0x013C |
|---|
Product Type ID | 0x0001 |
|---|
Product ID | 0x0076 |
|---|
User Icon | 0x0700 |
|---|
Installer Icon | 0x0700 |
|---|
Frequency Plans | EU: 869.85MHz, 868.40MHz |
|---|
Categories | All Lighting Devices, On/Off Switches/Devices |
|---|
Countries / Regions | European Union |
|---|
Supported Command Classes | Identifier | Name | Key | Version |
|---|
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4 | Firmware Update Meta-Data V4 | 0x7A | 4 | COMMAND_CLASS_POWERLEVEL | Powerlevel | 0x73 | 1 | COMMAND_CLASS_SWITCH_BINARY | Switch Binary | 0x25 | 1 | COMMAND_CLASS_BASIC | Basic | 0x20 | 1 | COMMAND_CLASS_CONFIGURATION | Configuration | 0x70 | 1 | COMMAND_CLASS_SECURITY | Security S0 | 0x98 | 1 | COMMAND_CLASS_TRANSPORT_SERVICE_V2 | Transport Service V2 | 0x55 | 2 | COMMAND_CLASS_DEVICE_RESET_LOCALLY | Device Reset Locally | 0x5A | 1 | COMMAND_CLASS_ZWAVEPLUS_INFO_V2 | Z-Wave Plus Info V2 | 0x5E | 2 | COMMAND_CLASS_ASSOCIATION_V2 | Association V2 | 0x85 | 2 | COMMAND_CLASS_SENSOR_MULTILEVEL_V9 | Sensor Multilevel V9 | 0x31 | 9 | COMMAND_CLASS_ASSOCIATION_GRP_INFO | Association Group Info | 0x59 | 1 | COMMAND_CLASS_SECURITY_2 | Security S2 | 0x9F | 1 | COMMAND_CLASS_VERSION_V3 | Version V3 | 0x86 | 3 | COMMAND_CLASS_SUPERVISION | Supervision | 0x6C | 1 | COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2 | Manufacturer Specific V2 | 0x72 | 2 | COMMAND_CLASS_METER_V2 | Meter V2 | 0x32 | 2 |
|
|---|
S2 Classes | S2_UNAUTHENTICATED |
|---|
Documents | Category | Description | File |
|---|
Manual_Primary_Lang | Product Manual | |
|
|---|
Features | Feature | Values |
|---|
Color | | Firmware Updatable | Value |
|---|
Updatable by Consumer by RF |
|
|
|---|
Association Groups | Group Number | Maximum Nodes Supported | End Point ID | Group Name | Profile | Description |
|---|
1 | 5 | 0 | Lifeline | 0x0001 | The Switch can be set to send reports to associated Z-Wave devices. It supports one association group with 5 nodes support for Grouping 1. For group 1, Lifeline, the Switch will report its latest status to Z-Wave Controller. Grouping 1 Lifeline supports SWITCH_BINARY_REPORT、METER_REPORT、SENSOR_MULTILEVEL_REPORT and RESET_LOCALLY_NOTIFICATION.
|
|
|---|
Configuration Parameters | Parameter Number | Name | Description | Format | Size | Min Value | Max Value | Default Value | Parameter Values |
|---|
1 | Unit of Accumulated Water Flow | If the setting is configured for accumulated cubic meters (set value =2), PAB04 will report its accumulated water flow every 1 hour to Group1 nodes. The default setting value is KL. | 1 | 1 | 1 | 2 | 2 | From | To | Description |
|---|
1 | 1 | 1 : US Gallon | 2 | 2 | 2. KL |
| 2 | Threshold of Accumulated Water Flow | When the accumulated water is over the threshold of accumulated water flow, PAB04 will send meter report of its Accumulated water flow (KL or US gallon) to Group1 nodes. For example : If the threshold of accumulated water flow is set as 1KL. PAB04 will send meter report whenever it detects the accumulated water flow crossing over 1KL、2KL、3KL、‧‧‧etc. | 1 | 2 | 0 | 255 | 1 | From | To | Description |
|---|
0 | 0 | 0 : Disable accumulated meter report | 1 | 255 | 1~255 : 1~255 US Gallon or KL |
| 3 | Differential of Instant Water Flow | When the variation of instant water flow is over the differential, PAB04 will send Multilevel Sensor report (Liter/h) to group1 nodes. In order to avoid too frequent report, it will not report when the instant water flow vary lower than the configured percentage of one liter. | 1 | 1 | 0 | 100 | 10 | From | To | Description |
|---|
0 | 0 | 0 : Disable instant water flow Report | 1 | 100 | 1~100 : 1% ~ 100% |
| 4 | Pulse count per liter | The calculation of accumulated water flow and instant water flow is based on this value of the attached meter. Check the specification of the water meter, you can find Pulse Frequency. For example : 7.5Q, Q is flow rate in L/min. Then the pulse count per liter will be 450, this value is count from 7.5 (L/min) multiply 60 seconds. | 1 | 2 | 1 | 32767 | 450 | From | To | Description |
|---|
1 | 32767 | 450 Pulse/L |
| 5 | Relay Control mode | If the relay control mode is set as 0 (NC), it will turn on the valve by closing the relay contact. If the relay control mode is set as 1 (NO), it will turn on the valve by opening the relay contact. | 1 | 1 | 0 | 1 | 0 | From | To | Description |
|---|
0 | 0 | 0 : NC | 1 | 1 | 1 : NO |
| 6 | Periodic Auto Report Timer | The auto report timer define how long will PAB04 report the meter report of accumulated water flow. At the same time it also sand the Multilevel Sensor report of instant water flow and Switch Binary Report of the state of the connected valve. | 1 | 2 | 0 | 1440 | 60 | From | To | Description |
|---|
0 | 0 | 0 ： Disable Periodic Auto Report | 1 | 1440 | 1~1440 ：1min ~ 1440 min |
|
|
|---|
Texts | ID | Description | Value |
|---|
8 | Where to find S2 DSK on product | 1.Product has a DSK string. For example：41810-20735-05418-54177-08777-14431-45473-10737. User can find QR code and DSK string on our product package and product.
2.SmartStart enabled products can be added into a Z-Wave network by scanning the Z-Wave QR Code on the product, with a controller providing SmartStart inclusion. No further action is required and the SmartStart product will be added automatically to the closest network within 10 minutes of being switched on in the network vicinity. | 1 | Classic Inclusion | Add(Inclusion) :
1. Put your Z-Wave controller into inclusion mode by following the instructions provided by the controller manufacturer.
2. Pressing On/Off button three times within 2 seconds will enter inclusion mode. | 2 | Classic Exclusion | Remove(Exclusion) :
1. Put your Z-Wave controller into exclusion mode by following the instructions provided by the controller manufacturer.
2. Pressing On/Off button three times within 2 seconds will enter exclusion mode. | 5 | Factory Reset Procedure | Reset :
1. Pressing On/Off button three times within 2 seconds will enter inclusion mode.
2. Within 1 second, press On/Off button again for 5 seconds.
3. IDs are excluded. |
|
|---|
Supported / Controlled Meter Types | Meter Type | Rate Type | Description |
|---|
Water meter | Import | Water Meter Consumption |
|
|---|
Supported Multilevel Sensors | Multilevel Sensor Type |
|---|
Water flow |
|
|---|
Supports NWI | Yes |
|---|
Supports Explorer Frames | Yes |
|---|
Supports SmartStart | Yes |
|---|
Radio Range Z-Wave (m) | 40 |
|---|
